Summary of Contents for SIGMATEK HGT 1051
- Page 1 HGT 1051 Handheld Operating Panel Operating Manual Date of creation: 23.02.2018 Version date: 17.12.2019 Article number: 01-245-1051-E...
- Page 2 (print, photocopy, microfilm or in any other process) without the express permission. We reserve the right to make changes in the content without notice. The SIGMATEK GmbH & Co KG is not responsi- ble for technical or printing errors in the handbook and assumes no responsibility for damages that occur through...
- Page 3 10.1" HANDHELD CONTROL PANEL HGT 1051 10.1" Handheld Control Panel HGT 1051 The HGT 1051 is an intelligent handheld control panel used for programming and visualization of automated processes. Process diagnostics, operat- ing and monitoring functions are thereby simplified. An emergency stop, key and confirmation switch are implemented as a Safety application.
-
Page 4: Table Of Contents
10.1“ HANDHELD CONTROL PANEL HGT 1051 Contents Essential Components ............4 Basic Safety Guidelines ............5 Symbols Used ................5 General Safety Guidelines ............7 Designated Use ................8 Residual Risks ................11 Safety of the Machine or Equipment ........12 Conformity with EU Guidelines .......... - Page 5 10.1" HANDHELD CONTROL PANEL HGT 1051 Rear Connectors ................. 20 Key Switch ................... 23 Confirmation Switch ..............24 Emergency Stop................25 Storage Media ................ 26 Wiring Guidelines ..............27 ESD Protection ................27 USB Interface Connections ............27 Cleaning the Touch Screen ..........28 Recommended Cable Shielding ...........
-
Page 6: Essential Components
10.1“ HANDHELD CONTROL PANEL HGT 1051 Essential Components • 10.1" WXGA TFT color display with LED backlighting • 10.1“ projected capacitive touch screen • Confirmation switch (mounted on the rear side), 2-channel configuration • Key switch (mounted top-center), two channel wiring. -
Page 7: Basic Safety Guidelines
10.1" HANDHELD CONTROL PANEL HGT 1051 Basic Safety Guidelines Symbols Used For warning, danger messages and informational notes, the following symbols are used in the operator documentation: DANGER DANGER Identifies an immediate danger with high risk, which can lead to immediate death or serious injury if not avoided. - Page 8 10.1“ HANDHELD CONTROL PANEL HGT 1051 This symbol identifies important or additional infor- mation regarding the operation of the safety modules. Ce symbole indique des informations importantes ou supplémentaires concernant le fonctionnement des modules de sécurité particuliers. INFORMATION Provides user tips, informs of special features and identifies especially important information in the text.
-
Page 9: General Safety Guidelines
The technical documentation should be included in the sale, rental or transfer of the product. Please read the corresponding data sheets, operating instructions and oper- ator instructions thoroughly before handling Safety modules. SIGMATEK is not liable for damages caused through non-compliance with these instruc- tions or respective regulations. -
Page 10: Designated Use
10.1“ HANDHELD CONTROL PANEL HGT 1051 Designated Use The Safety functions implemented in the Safety modules are designed for use with safety- related applications in a PLC control and meet the required conditions for safe operation in SIL 3 or SIL CL 3 according to EN 62061 and in compliance with PL e. Cat. 4 in accordance with EN ISO 13849-1. - Page 11 10.1" HANDHELD CONTROL PANEL HGT 1051 For your own safety and the safety of others, the safety modules should be used for their designated purpose only. Correct EMC installation is also included under designated use. Utilisez les modules de sécurité pour votre sécurité et celle des autres uniquement d’une façon appropriée.
- Page 12 10.1“ HANDHELD CONTROL PANEL HGT 1051 In addition, the Safety Guidelines in the other sections of these instruc- tions must be observed. These instructions are visibly emphasized by symbols. Veillez à bien respecter les consignes de sécurité dans les autres sec- tions de ce manuel.
-
Page 13: Residual Risks
10.1" HANDHELD CONTROL PANEL HGT 1051 Residual Risks In the risk assessment defined by the 2006/42/EG guideline (machine guideline), the machine manufacturer must include the possible resid- ual risks posed by Safety modules. These include: Unwanted movements of driven machine components Unwanted temperatures, emissions of gas, particles, smell and light. -
Page 14: Safety Of The Machine Or Equipment
Strict compliance with the safety guidelines is required, otherwise all warranties and claims are invalid: Observe all on-site rules and regulations for accident prevention and occupa- tional safety. Conformity with EU Guidelines The HGT 1051 was constructed in compliance with the following European Union guide- lines: 2006/42/EG Machine Guideline 2014/35/EU... -
Page 15: Safety-Relevant Parameters
10.1" HANDHELD CONTROL PANEL HGT 1051 Safety-Relevant Parameters The use of the specified parameters requires a risk analysis of the end application. Input Module Safety Parameters(*) HGT 1051 = 1.07E-11 (1/h) Including Safe CPU (SCP XXX) MTTF = 306 years DC = 99.9 %... -
Page 16: Technical Data
(buffered circa 10 days via gold foil capacitor) Cooling passive (fanless) The Safety interface must be used exclusively with the SIGMATEK SCP XXX! The status of the Safety-related inputs (confirmation switch, key switch, emergency stop switch) is sent to the SCP XXX. -
Page 17: Electrical Requirements
10.1" HANDHELD CONTROL PANEL HGT 1051 The function of the key switch, confirmation switch and emergency stop switch must be tested at least once per month. L'interrupteur à clé, l'interrupteur de confirmation et de l'interrupteur d'arrêt d'urgence doivent être vérifiés au moins une fois par mois! -
Page 18: Terminal
10.1“ HANDHELD CONTROL PANEL HGT 1051 Terminal Dimensions 226 x 264 x 76 mm (W x H x D) (without emergency/key switch) Material housing: PC/ASA color: RAL7024 Weight 1.1 kg without connector cable Environmental Conditions Storage temperature -10 ... +60 °C Environmental temperature 0 ... -
Page 19: Display
10.1" HANDHELD CONTROL PANEL HGT 1051 Display 10.1” TFT LCD color display Type Resolution WXGA 800 x 1280 pixels Color depth 24-bit RGB LCD mode normal black LCD polarizer transmissive Pixel size 0.1695 x 0.1695 mm Backlighting Contrast typically 800: 1 Brightness typically 300 cd/m²... -
Page 20: Mechanical Dimensions
10.1“ HANDHELD CONTROL PANEL HGT 1051 Mechanical Dimensions Page 18 17.12.2019... -
Page 21: Wall Mount
10.1" HANDHELD CONTROL PANEL HGT 1051 Wall Mount Using the corresponding wall mount, the panel can be attached to the provided holder (A1) on the back (see dimensions for counter piece) An additional option consists of using the magnetic feet on the panel to hang it onto a mag- netic surface. -
Page 22: Interface Connections
10.1“ HANDHELD CONTROL PANEL HGT 1051 Interface Connections Rear Connectors X1: USB Interface 2.0 Type A Function +5 V Page 20 17.12.2019... - Page 23 10.1" HANDHELD CONTROL PANEL HGT 1051 It should be noted that many of the USB devices on the market do not comply with USB specifications; this can lead to device malfunctions. This can lead to malfunc- tion of the device. It is also possible that these devices will not be detected at the USB port or function correctly.
- Page 24 As required by EN ISO 13850, section 4.1 and EN 60204-1, section 10.7.1, it must be ensured that no confusion between a functioning and non- functioning handheld control panel is possible. Note on the Emergency Stop function: A non-connected HGT 1051 does not have to be visibly sealed! LED Status...
-
Page 25: Key Switch
10.1" HANDHELD CONTROL PANEL HGT 1051 Key Switch The key switch is two-stage and read via the SCP XXX connected to the Safety interface. In the SCP XXX the "HBG0811_K" module is used; inputs 5 and 6 are assigned to the key switch. -
Page 26: Confirmation Switch
The switch is active when simply pressed (middle stage). In the SCP XXX the "HBG0811_K" module is used; inputs 1 and 2 are assigned to the confirmation switch. With the "HGT1051" hardware class, it is possible on the HGT 1051 among other things, to evaluate the Safety number of the connected SCP XXX. -
Page 27: Emergency Stop
10.1" HANDHELD CONTROL PANEL HGT 1051 Emergency Stop The Emergency Stop is two-stage. In the SCP XXX the "HBG0811_K" module is with the inputs 3 and 4. 17.12.2019 Page 25... -
Page 28: Storage Media
10.1“ HANDHELD CONTROL PANEL HGT 1051 Storage Media It is recommended that only storage media provided by SIGMATEK (CompactFlash cards, microSD cards etc.) be used. The number of read and write actions have a significant influence on the lifespan of the storage media. -
Page 29: Wiring Guidelines
10.1" HANDHELD CONTROL PANEL HGT 1051 Wiring Guidelines ESD Protection Typically, USB devices (keyboard, mouse...) are not equipped with shielded cables. These devices are disrupted by ESD and in some instances, no longer function. Before any device is connected to, or disconnected from the terminal, the potential should be equalized (by touching the control cabinet or ground terminal). -
Page 30: Cleaning The Touch Screen
10.1“ HANDHELD CONTROL PANEL HGT 1051 Cleaning the Touch Screen CAUTION! Before cleaning the touch screen, the HGT must be turned off in order to prevent triggering functions or commands unintentionally! Attention! Avant de nettoyer l'écran tactile, le HGT doit d'abord être éteint afin d’éviter un dé- clanchement involontaire des commandes! The HGT touch screen can only be cleaned using a soft damp cloth. -
Page 31: Recommended Cable Shielding
10.1" HANDHELD CONTROL PANEL HGT 1051 Recommended Cable Shielding For applications in which the bus is operated outside the control cabinet, the correct shield- ing is required. Especially when for structural reasons, the bus line must be placed next to sources of strong electromagnetic interference. - Page 32 10.1“ HANDHELD CONTROL PANEL HGT 1051 Documentation Changes Change date Affected page(s) Chapter Note 16.08.2018 3.1 Performance Data Note corrected 02.11.2018 4.1 Wall Mount Graphic 25.06.2019 4.1 Wall Mount Dimension added 17.12.2019 9.1 Connection from the Graphics extended Control Cabinet Page 30 17.12.2019...
