- Page 1 HGT 835 Handheld Control Panel Instruction Manual Date of creation: 07.01.2014 Version date: 07.06.2024 Article number: 01-245-835-E...
- Page 2 (print, photocopy, microfilm or in any other process) without the express permission. We reserve the right to make changes in the content without notice. The SIGMATEK GmbH & Co KG is not responsi- ble for technical or printing errors in the handbook and assumes no responsibility for damages that occur through...
- Page 3 HGT 835 8.4" Handheld Control Panel HGT 835 The HGT 835 Control Panel is an intelligent handheld control panel used for programming and visualization of automated processes. Process diagnosis, operating and monitoring functions are thereby simplified. A touch screen serves as the input medium for process data and parameters. The output is shown on an 8.4"...
-
Page 4: Table Of Contents
8.4“ HANDHELD CONTROL PANEL HGT 835 Contents Essential Components ............5 Introduction ................6 Target Group/Purpose of this Operating Manual ...... 6 Important Reference Documentation ......... 6 Contents of Delivery ..............6 Basic Safety Guidelines ............7 Symbols Used ................7 Disclaimer .................. - Page 5 8.4" HANDHELD CONTROL PANEL HGT 835 Technical Data ............... 19 Performance Data ............... 19 Electrical Requirements ............. 20 Terminal ..................21 Environmental Conditions ............21 Display ..................22 Terminal Requirements .............. 22 Miscellaneous ................22 Mechanical Dimensions ............23 Wall Mounting ................23 Interfaces ................
- Page 6 8.4“ HANDHELD CONTROL PANEL HGT 835 11.1 Connection from the Control Cabinet to the HGT ....30 12 Transport/Storage ..............31 13 Storage ...................31 14 Maintenance ................32 14.1 Cleaning and Disinfecting the Touch Screen ......32 14.2 Service ..................33 14.3 Repair ...................
-
Page 7: Essential Components
8.4" HANDHELD CONTROL PANEL HGT 835 Essential Components • 8.4" SVGA TFT color display with background lighting • 8.4" Touch screen • Confirmation switch (mounted on the rear side), 2-channel configuration • Key switch (mounted top-center), two channel wiring. •... -
Page 8: Introduction
General knowledge of automation technology is required. Further help and training information, as well as the appropriate accessories can be found on our website www.sigmatek-automation.com. Our support team is happily available to answer your questions. Please see our website for our hotline number and business hours. -
Page 9: Basic Safety Guidelines
8.4" HANDHELD CONTROL PANEL HGT 835 Basic Safety Guidelines Symbols Used The following symbols are used in the operator documentation for warning and danger messages, as well as informational notes: DANGER Danger indicates that death or serious injury will occur, if the specified measures are not taken. - Page 10 8.4“ HANDHELD CONTROL PANEL HGT 835 Danger for ESD-sensitive components. Les signes de danger pour les composants sensibles aux décharges élec- trostatiques. Page 8 07.06.2024...
-
Page 11: Disclaimer
Please thoroughly read the corresponding documents and this operating manual before handling a product. SIGMATEK GmbH & Co KG is not liable for damages caused through, non-compliance with these instructions or applicable regulations. 07.06.2024... -
Page 12: General Safety Directives
2006/42/EG directives is correct. As long as the machine with which the product should be used does not comply with the directive, oper- ating this product is prohibited. Operate the unit with devices and accessories approved by SIGMATEK only. Page 10... - Page 13 8.4" HANDHELD CONTROL PANEL HGT 835 CAUTION Handle the device with care and do not drop or let fall. Prevent foreign bodies and fluids from entering the device. The device must not be opened, otherwise it could be damaged! Manipulez l’appareil avec précaution et ne le laissez pas tomber.
- Page 14 8.4“ HANDHELD CONTROL PANEL HGT 835 The module complies with EN 61131-2. In combination with a machine, the machine builder must comply with EN 60204-1 standards. For your own safety and that of others, compliance with the environmental conditions is essential.
-
Page 15: Designated Use
8.4" HANDHELD CONTROL PANEL HGT 835 Designated Use The Safety functions implemented in the product are designed for use with safety applica- tions in a PLC control and meet the required conditions for safe operation according to SIL 3, HFT 1 in compliance with EN IEC 62061 and according to PL e, Kat. 4 in compliance with EN ISO 13849-1. -
Page 16: Software/Training
8.4“ HANDHELD CONTROL PANEL HGT 835 Non-designated use consists of: • any changes made to the module or the use of damaged modules. • use of the module inconsistent with the technical margins de- scribed in this operating manual or the specifications defined in the technical data. -
Page 17: Standards And Directives
8.4" HANDHELD CONTROL PANEL HGT 835 Standards and Directives Residual Risks CAUTION The following residual risks for the product must be included in the system integrator's risk assessment: • Release of non-environmentally safe substances, emissions and unusual temperatures • Hazardous contact voltages •... -
Page 18: Regular Technical Inspection Of Safety-Related Switches
8.4“ HANDHELD CONTROL PANEL HGT 835 Regular Technical Inspection of Safety-Related Switches CAUTION According to the Machinery Directive, mechanical and electromechanical safety-relevant components (e.g. relays, switches, etc.) must be regularly tested for correct functioning. Emergency stop switch: at least 1x/month... -
Page 19: Functional Safety Standards
Safety of machinery - Emergency stop function - Princi- ples for design 4.4.2 EU Conformity Declaration EU Declaration of Conformity The product HGT 835 conforms to the following European directives: • 2006/42/EG Machine Directive • 2014/30/EU Electromagnetic Compatibility (EMC Directive) •... -
Page 20: Type Plate
8.4“ HANDHELD CONTROL PANEL HGT 835 Type Plate HW: Hardware version SW: Software version Page 18 07.06.2024... -
Page 21: Technical Data
4 Gbyte is not allowed and will result in a massive reduction of the microSD card's lifetime. The Safety Interface must be used exclusively with the SIGMATEK SCP XXX! The status of the safety-related inputs (confirmation switch, key switch, emergency stop switch) is sent to the SCP XXX. -
Page 22: Electrical Requirements
8.4“ HANDHELD CONTROL PANEL HGT 835 Electrical Requirements Supply voltage typically +24 V DC (PELV) minimum +24 V DC (PELV) maximum +30 V DC (PELV) Supply voltage (UL) +24-30 V DC (NEC Class 2 or LVLC) Protection class Current consumption typically 0.35 A... -
Page 23: Terminal
8.4" HANDHELD CONTROL PANEL HGT 835 Terminal Dimensions 217.4 x 187.7 X 72 mm (W x H x D) (without Emergency Stop switch / key switch) Material housing: PC/ASA color: RAL7024 Weight typically, circa 0.95 kg without connector cable Environmental Conditions Storage temperature -10 ... -
Page 24: Display
8.4“ HANDHELD CONTROL PANEL HGT 835 Display 8.4” TFT LCD color display Type Resolution SVGA 800 x 600 Pixel Color depth 18-bit RGB (262K colors) LCD mode TN / normal white LCD Polarizer transmissive Pixel size 0.213 x 0.213 mm Active surface 170.40 x 127.80 mm... -
Page 25: Mechanical Dimensions
8.4" HANDHELD CONTROL PANEL HGT 835 Mechanical Dimensions Wall Mounting 07.06.2024 Page 23... -
Page 26: Interfaces
8.4“ HANDHELD CONTROL PANEL HGT 835 Interfaces Rear Connectors X1: USB Interface 2.0 Type A Function +5 V It should be noted that many of the USB devices on the market do not comply with USB specifications; this can lead to device malfunctions. It is also possible that these devices will not be detected at the USB port or function correctly. - Page 27 8.4" HANDHELD CONTROL PANEL HGT 835 X2: M16 Cable Connector Wire color Function Yellow Safety Interface-H Green Safety Interface-L Black Safety Interface shield +24 V DC Black Shield ETH shield White ETH_TX+ VAR_RX+ Blue VAR_RX- Pink VAR_TX+ Gray VAR_TX- Yellow...
-
Page 28: Key Switch
8.4“ HANDHELD CONTROL PANEL HGT 835 Key Switch The key switch is two-stage and read via the SCP XXX connected to the Safety Interface. In the SCP XXX the "HBG0811_K" module is used; inputs 5 and 6 are assigned to the key switch. -
Page 29: Confirmation Switch
8.4" HANDHELD CONTROL PANEL HGT 835 Confirmation Switch The confirmation switch is three-stage. If the switch is not pressed or pressed only partially, it is inactive. The switch is active when simply pressed (middle stage). In the SCP XXX the "HBG0811_K"... -
Page 30: Emergency Stop
8.4“ HANDHELD CONTROL PANEL HGT 835 Emergency Stop The Emergency Stop is two-stage. In the SCP XXX the "HBG0811_K" module is with the inputs 3 and 4. Page 28 07.06.2024... -
Page 31: Assembly/Installation
8.4" HANDHELD CONTROL PANEL HGT 835 Assembly/Installation Check Contents of Delivery Ensure that the contents of the delivery are complete and intact. See chapter Contents of Delivery. On receipt and before initial use, check the device for damage. If the device is damaged, contact our customer service and do not install the device in your system. -
Page 32: Recommended Cable Shielding
8.4“ HANDHELD CONTROL PANEL HGT 835 11 Recommended Cable Shielding For applications in which the bus is operated outside the control cabinet, the correct shield- ing is required. Especially when for structural reasons, the bus line must be placed next to sources of strong electromagnetic interference. -
Page 33: Transport/Storage
8.4" HANDHELD CONTROL PANEL HGT 835 12 Transport/Storage This device contains sensitive electronics. During transport and storage, high mechanical stress must therefore be avoided. For storage and transport, the same values for humidity and vibration as for operation must be maintained! Temperature and humidity fluctuations may occur during transport. -
Page 34: Maintenance
8.4“ HANDHELD CONTROL PANEL HGT 835 14 Maintenance During maintenance as well as servicing, observe the safety instructions from chapter 3. 14.1 Cleaning and Disinfecting the Touch Screen CAUTION Before cleaning and disinfecting the touch screen, it must first be deactivat- ed;... -
Page 35: Service
8.4" HANDHELD CONTROL PANEL HGT 835 14.2 Service This product was constructed for low-maintenance operation. 14.3 Repair In the event of a defect/repair, send the device with a detailed error descrip- tion to the address listed at the beginning of this document. -
Page 36: Storage Media
8.4“ HANDHELD CONTROL PANEL HGT 835 15 Storage Media It is recommended to use only the storage media approved by SIGMATEK (CompactFlash cards, microSD cards, etc.). The number of read and write accesses have a significant influence on the service life of the storage media. -
Page 37: Accessory Wall-Mount
8.4" HANDHELD CONTROL PANEL HGT 835 16 Accessory Wall-Mount The corresponding wall-mount is available from SIGMATEK under the article number 01-245-835-Z5. 07.06.2024 Page 35... -
Page 38: Disposal
8.4“ HANDHELD CONTROL PANEL HGT 835 17 Disposal Should you need to dispose of the device, the national regula- tions for disposal must be followed. The device appliance must not be disposed of as household waste. Page 36 07.06.2024... -
Page 39: Documentation Changes
8.4" HANDHELD CONTROL PANEL HGT 835 Documentation Changes Change Affected Chapter Note date page(s) 29.09.2014 3.2 Electrical Requirements Added Supply Voltage (UL) and notice in grey box 3.7 Miscellaneous Added Standard 29.12.2014 4.1 Wall Mounting Added Wall Mounting 09.03.2015 9 Accessory Wall-Mount Added Accessory Wall-Mount 12.03.2015... - Page 40 8.4“ HANDHELD CONTROL PANEL HGT 835 08.09.2020 3.2 Electrical Requirements Protection class added 3.4 Environmental Conditions Added for Protection Type (only with all protective caps fitted) 30.09.2020 9 Accessory Wall-Mount Article number changed 18.11.2020 3.1 Performance Data Footnote cores (programming) added 26.02.2021...
