- Page 1 HGT 835 Handheld Control Panel Date of creation: 07.01.2014 Version date: 16.08.2018 Article number: 01-245-835-E...
- Page 2 (print, photocopy, microfilm or in any other process) without the express permission. We reserve the right to make changes in the content without notice. The SIGMATEK GmbH & Co KG is not responsi- ble for technical or printing errors in the handbook and assumes no responsibility for damages that occur through...
- Page 3 HGT 835 8.4" Handheld Control Panel HGT 835 The HGT 835 Control Panel is an intelligent handheld control panel used for programming and visualization of automated processes. Process diagnosis, operating and monitoring functions are thereby simplified. A touch screen serves as the input medium for process data and parameters. The output is shown on an 8.4"...
-
Page 4: Table Of Contents
8.4“ HANDHELD CONTROL PANEL HGT 835 Contents Essential Components ............4 Basic Safety Guidelines ............5 Symbols Used ................5 General Safety Guidelines ............7 Designated Use ................8 Residual Risks ................11 Safety of the Machine or Equipment ........12 Conformity with EU Standards .......... - Page 5 8.4" HANDHELD CONTROL PANEL HGT 835 Key Switch ................... 21 Confirmation Switch ..............22 Emergency Stop................23 Storage Media ................ 24 Wiring Guidelines ..............24 ESD Protection ................24 USB Interface Connections ..........24 Accessory Wall-Mount ............25 10 Cleaning the Touch Screen ..........26 11 Recommended Cable Shielding ...........
-
Page 6: Essential Components
8.4“ HANDHELD CONTROL PANEL HGT 835 Essential Components • 8.4" SVGA TFT color display with background lighting • 8.4" Touch screen • Confirmation switch (mounted on the rear side), 2-channel configuration • Key switch (mounted top-center), two channel wiring. •... -
Page 7: Basic Safety Guidelines
8.4" HANDHELD CONTROL PANEL HGT 835 Basic Safety Guidelines Symbols Used For warning, danger messages and informational notes, the following symbols are used in the operator documentation: DANGER DANGER Identifies an immediate danger with high risk, which can lead to immediate death or serious injury if not avoided. - Page 8 8.4“ HANDHELD CONTROL PANEL HGT 835 This symbol identifies important or additional infor- mation regarding the operation of the safety modules. Ce symbole indique des informations importantes ou supplémentaires concernant le fonctionnement des modules de sécurité particuliers. INFORMATION Provides user tips, informs of special features and identifies especially important information in the text.
-
Page 9: General Safety Guidelines
The technical documentation should be included in the sale, rental or transfer of the product. Please read the corresponding data sheets and operating instructions thor- oughly before handling Safety modules. SIGMATEK is not liable for damages caused through non-compliance with these instructions or respective regula- tions. -
Page 10: Designated Use
8.4“ HANDHELD CONTROL PANEL HGT 835 Designated Use The Safety functions implemented in the Safety modules are designed for use with safety- related applications in a PLC control and meet the required conditions for safe operation in SIL 3 or SIL CL 3 according to EN 62061 and in compliance with PL e. Cat. 4 in accordance with EN ISO 13849-1. - Page 11 8.4" HANDHELD CONTROL PANEL HGT 835 For your own safety and the safety of others, the safety modules should be used for their designated purpose only. Correct EMC installation is also included under designated use. Utilisez les modules de sécurité pour votre sécurité et celle des autres uniquement d’une façon appropriée.
- Page 12 8.4“ HANDHELD CONTROL PANEL HGT 835 In addition, the Safety Guidelines in the other sections of these instruc- tions must be observed. These instructions are visibly emphasized by symbols. Veillez à bien respecter les consignes de sécurité dans les autres sec- tions de ce manuel.
-
Page 13: Residual Risks
8.4" HANDHELD CONTROL PANEL HGT 835 Residual Risks In the risk assessment defined by the 2006/42/EG guideline (machine guideline), the machine manufacturer must include the possible resid- ual risks posed by Safety modules. These include: Unwanted movements of driven machine components Unwanted temperatures, emissions of gas, particles, smell and light. -
Page 14: Safety Of The Machine Or Equipment
8.4“ HANDHELD CONTROL PANEL HGT 835 Safety of the Machine or Equipment Strict compliance with the safety guidelines is required, otherwise all warranties and claims are invalid: Observe all on-site rules and regulations for accident prevention and occupa- tional safety. -
Page 15: Safety-Relevant Parameters
8.4" HANDHELD CONTROL PANEL HGT 835 Safety-relevant Parameters The use of the specified parameters requires a risk analysis of the end application. Input module Safety parameters (*) HGT 835 = 1.07E-11 (1/h) included Safe CPU (SCP XXX) MTTF = 306 years DC = 99.9 %... -
Page 16: Technical Data
(buffering approximately 10 days) Cooling passive (fanless) The Safety Interface must be used exclusively with the SIGMATEK SCP XXX! The status of the safety-related inputs (confirmation switch, key switch, emergency stop switch) is sent to the SCP XXX. L'interface de sécurité doit uniquement être utilisée avec le SIGMATEK SCP XXX! L'état des entrées de sécurité... -
Page 17: Electrical Requirements
8.4" HANDHELD CONTROL PANEL HGT 835 The function of the key switch, confirmation switch and emergency stop switch must be tested at least once per month. L'interrupteur à clé, l'interrupteur de confirmation et de l'interrupteur d'arrêt d'urgence doivent être vérifiés au moins une fois par mois! -
Page 18: Terminal
8.4“ HANDHELD CONTROL PANEL HGT 835 Terminal Dimensions 217.4 x 187.7 X 72 mm (W x H x D) (without Emergency Stop switch / key switch) Material housing: PC/ASA color: RAL7024 Weight typically, circa 0.95 kg without connector cable Environmental Conditions Storage temperature -10 ... -
Page 19: Display
8.4" HANDHELD CONTROL PANEL HGT 835 Display 8.4” TFT LCD color display Type Resolution SVGA 800 x 600 Pixel Color depth 18-bit RGB (262K colors) LCD mode TN / normal white LCD Polarizer transmissive Pixel size 0.213 x 0.213 mm Active surface 170.40 x 127.80 mm... -
Page 20: Mechanical Dimensions
8.4“ HANDHELD CONTROL PANEL HGT 835 Mechanical Dimensions Wall Mounting Page 18 16.08.2018... -
Page 21: Interfaces
8.4" HANDHELD CONTROL PANEL HGT 835 Interfaces Rear Connectors X1: USB Interface 2.0 Type A Function +5 V It should be noted that many of the USB devices on the market do not comply with USB specifications; this can lead to device malfunctions. It is also possible that these devices will not be detected at the USB port or function correctly. - Page 22 As required by EN ISO 13850, section 4.1 and EN 60204-1, section 10.7.1, it must be impossible to confuse a functioning handheld control panel with a non-functioning one. Note on the Emergency Stop function: A non-connected HGT 835 does not have to be visibly sealed! LED status...
-
Page 23: Key Switch
8.4" HANDHELD CONTROL PANEL HGT 835 Key Switch The key switch is two-stage and read via the SCP XXX connected to the Safety Interface. In the SCP XXX the "HBG0811_K" module is used; inputs 5 and 6 are assigned to the key switch. -
Page 24: Confirmation Switch
8.4“ HANDHELD CONTROL PANEL HGT 835 Confirmation Switch The confirmation switch is three-stage. If the switch is not pressed or pressed only partially, it is inactive. The switch is active when simply pressed (middle stage). In the SCP XXX the "HBG0811_K"... -
Page 25: Emergency Stop
8.4" HANDHELD CONTROL PANEL HGT 835 Emergency Stop The Emergency Stop is two-stage. In the SCP XXX the "HBG0811_K" module is with the inputs 3 and 4. 16.08.2018 Page 23... -
Page 26: Storage Media
8.4“ HANDHELD CONTROL PANEL HGT 835 Storage Media It is recommended that only storage media provided by SIGMATEK (CompactFlash cards, microSD cards etc.) be used. The number of read and write actions have a significant influence on the lifespan of the storage media. -
Page 27: Accessory Wall-Mount
8.4" HANDHELD CONTROL PANEL HGT 835 Accessory Wall-Mount The corresponding wall-mount is available from SIGMATEK under the article number 01-245-835-Z1. 16.08.2018 Page 25... -
Page 28: 10 Cleaning The Touch Screen
8.4“ HANDHELD CONTROL PANEL HGT 835 10 Cleaning the Touch Screen CAUTION! Before cleaning the touch screen, the HGT must be turned off in order to prevent triggering functions or commands unintentionally! The HGT touch screen can only be cleaned using a soft damp cloth. To dampen the cloth, a screen cleaning solution such as antistatic foam cleaner, water with detergent or alcohol is recommended. -
Page 29: 11 Recommended Cable Shielding
8.4" HANDHELD CONTROL PANEL HGT 835 11 Recommended Cable Shielding For applications in which the bus is operated outside the control cabinet, the correct shield- ing is required. Especially when for structural reasons, the bus line must be placed next to sources of strong electromagnetic interference. - Page 30 8.4“ HANDHELD CONTROL PANEL HGT 835 Documentation Changes Change Affected Chapter Note date page(s) 29.09.2014 3.2 Electrical Requirements Added Supply Voltage (UL) and notice in grey box 3.7 Miscellaneous Added Standard 29.12.2014 4.1 Wall Mounting Added Wall Mounting 09.03.2015 9 Accessory Wall-Mount Added Accessory Wall-Mount 12.03.2015...
