Colposcope can be positioned easily with the help of a suspension arm within
Prima CS:
a vertical travel range of 500mm. It can be maneuvered easily with the help
of a 980mm long pentographic arm as per user & patient comfort. When not in
use, colposcope can be folded easily over the main body to store compactly.
Binocular Head
Eyepieces
Joystick
Potentiometer Knob
Microscope ArmLocking knob
5
6128000-795
User's Manual Prima C/ Prima CS COLPOSCOPE
Binocular Head Locking Screw
Fine Focusing Knob
CMO
Magnification Knob
Tilt Locking Knob
Suspension arm hydraulic movement knob
Suspension arm
Wheels
Suspension arm apring
Tension Adjustment
Prima C/ Prima CS
Swivel Arm Cover
Column
Base
Printed on Oct, 2016
Issue 2.0
