Unit specifications (B)
MODEL No.
POWER SOURCE
PERFORMANCE
Capacity
Air circulation (Hi)
ELECTRICAL RATINGS
Voltage rating
Available voltage range
Running amperes
Max. running amperes *
Power input
Max. power input
Power factor
Max. starting amperes
FEATURES
Controls
Defrost control
Service function
Refrigerant amount at shipment
Refrigerant control
Power level
Operation sound (Hi)
Pressure level
External finish
Color (Approximate value)
Refrigerant tubing
Limit of tubing length
Limit of elevation difference
between the 2 units
Liquid tube
Refrigerant tube
diameter
Gas tube
Refrigerant tubing kit / Joint kit
DIMENSIONS & WEIGHT
Height
Unit dimensions Width
Depth
Net weight
Shipping weight
Shipping volume
Rated conditions
Cooling : Indoor air temperature 80°F DB / 67°F WB ; Outdoor air temperature 95°F DB
Heating : Indoor air temperature 70°F DB ; Outdoor air temperature 47°F DB / 43°F WB
* Full-load conditions at Indoor / Outdoor capacity ratio 100%
Cooling : Indoor air temperature 89°F DB / 73°F WB ; Outdoor air temperature 109°F DB / 78°F WB
1
* Outdoor unit model name beginning with letters "JCHXR"
Refer to the Section 1 "Salt-Ait Damage Resistant Specifications".
JOHNSON CONTROLS
Outdoor Unit
BTU / h
kW
CFM
V
V
A
A
kW
kW
%
A
lbs. (kg)
dB-A
ft. (m)
ft. (m)
in. (mm)
in. (mm)
in. (mm)
in. (mm)
in. (mm)
lbs. (kg)
lbs. (kg)
3 3
ft (m )
JCHX05252N, JCHXR05252N*
208 - 230 V / 1ø / 60 Hz
Cooling
52,900
15.5
3,530
208 230
187 - 253
23.5 21.9
28.0 28.0
4.57 4.57
5.72 5.72
93 91
Approx. 1 Approx. 1
Microprocessor
Reverse cycle, microprocessor control
Sensor temp. recall function
Past service warnings recall function
R410A - 7.7 (3.5)
Electronic expansion valve
Galvanized steel plate with powder paint
Munsell code 1Y 8.5 /0.5
492 (150)
Outdoor unit is higher than indoor unit : 164 (50)
Outdoor unit is lower than indoor unit : 131 (40)
3/8 (9.52)
3/4 (19.05)
Optional
Unit dimensions
48-7/16 (1230)
37 (940)
13-13/32 (340)
229 (104)
247 (112)
19.8 (0.56)
DATA SUBJECT TO CHANGE WITHOUT NOTICE
1
Heating
60,000
17.6
208 230
187 - 253
23.5 21.9
– –
4.58 4.58
– –
94 91
Approx. 1 Approx. 1
68
52
Package dimensions
52-13/32 (1331)
40 (1016)
16-11/32 (415)
18
