J**ZT SERIES W/SMART EQUIPMENT™
3 - 5 Ton
60 Hertz
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Preceding Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Limitations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Rigging And Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Side Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Compressors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Power And Control Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Optional Electric Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Optional Gas Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Options/Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Economizer Sequences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Dry Bulb Changeover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Single Enthalpy Changeover . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Dual Enthalpy Changeover . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Auto . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
1 Unit Shipping Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Condenser Covering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Compressor Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4 Component Location (JA3ZT Shown) . . . . . . . . . . . . . . . . . . 7
5 Unit 4 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6 Center of Gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
7 JA3 thru JA5ZT Physical Dimensions . . . . . . . . . . . . . . . . . . 9
8 JA3 thru JA5ZT Unit Bottom Duct Openings . . . . . . . . . . . . 11
9 JA3 thru JA5ZT Unit Electrical Entry . . . . . . . . . . . . . . . . . . 12
10 JA3 thru JA5ZT Unit Side Duct Openings . . . . . . . . . . . . . . 12
11 JA3 thru JA5ZT Unit Left Duct Opening . . . . . . . . . . . . . . . . 13
12 JA3 thru JA5ZT Roof Curb . . . . . . . . . . . . . . . . . . . . . . . . . . 13
13 JA3 thru JA5ZT Transition Roof Curb . . . . . . . . . . . . . . . . . 14
14 JA3 thru JA5ZT Roof Curb Cutaway . . . . . . . . . . . . . . . . . . 14
15 Side Panels With Hole Plugs . . . . . . . . . . . . . . . . . . . . . . . . 15
16 Return Downflow Plenum With Panel . . . . . . . . . . . . . . . . . . 15
1 JA3 thru JA5ZT Unit Limitations . . . . . . . . . . . . . . . . . . . . . . . 7
2 Weights and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 JA3 thru JA5ZT Unit Accessory Weights . . . . . . . . . . . . . . . . 9
4 JA3 thru JA5ZT Unit Physical Dimensions . . . . . . . . . . . . . . 10
5 JA3 thru JA5ZT Unit Clearances . . . . . . . . . . . . . . . . . . . . . . 10
6 Side Duct Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7 Left/End Duct Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
8 Control Wire Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
9 Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
10 Physical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
11 Electric Heat Minimum Supply Air . . . . . . . . . . . . . . . . . . . . . 25
12 Gas Pipe Sizing - Capacity of Pipe . . . . . . . . . . . . . . . . . . . . 26
13 Gas Heat Minimum Supply Air . . . . . . . . . . . . . . . . . . . . . . . 27
14 Smart Equipment™ Economizer Board Details . . . . . . . . . . 32
15 Supply Air Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
16 Altitude/Temperature Correction Factors . . . . . . . . . . . . . . . 36
17 Airflow Performance - Side Duct Application . . . . . . . . . . . . . 39
TABLE OF CONTENTS
Free Cooling Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Power Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Airflow Performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Air Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Checking Air Quantity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Cooling Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Cooling Operation Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Electric Heating Sequence Of Operations. . . . . . . . . . . . . . . . 46
Electric Heat Operation Errors . . . . . . . . . . . . . . . . . . . . . . . 46
Gas Heating Sequence Of Operations . . . . . . . . . . . . . . . . . . 47
Ignition Control Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Gas Heating Operation Errors . . . . . . . . . . . . . . . . . . . . . . . 48
Start-Up (Cooling) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Start-Up (Gas Heat) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Checking Gas Heat Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Control Board Navigation Components . . . . . . . . . . . . . . . . . . . . 52
Charging The Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Start-Up Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
LIST OF TABLES
17 Discharge Panel In Place . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
18 Save Side Panels For Economizer Hood Tops . . . . . . . . . . 15
19 Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
20 Field Wiring Disconnect . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
21 Typical Control Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
22 Side Entry Gas Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
23 Bottom Entry Gas Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
24 Simplified VFD Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
25 SE-ECO1001-0 Economizer Controller . . . . . . . . . . . . . . . . 32
26 Belt Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
27 Altitude/Temperature Correction Factors . . . . . . . . . . . . . . . 37
28 Dry Coil Delta P . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
29 Typical Flame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
30 Typical Two Stage Gas Valve . . . . . . . . . . . . . . . . . . . . . . . 52
31 Unit Control Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
LIST OF FIGURES
18 Airflow Performance - Bottom Duct Application . . . . . . . . . . 40
19 RPM Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
20 Indoor Blower Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 41
21 Power Exhaust Specifications . . . . . . . . . . . . . . . . . . . . . . . . 41
22 Motor Sheave Datum Diameters . . . . . . . . . . . . . . . . . . . . . . 43
23 Additional Static Resistance . . . . . . . . . . . . . . . . . . . . . . . . . 44
24 Electric Heat Limit Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
25 Electric Heat Anticipator Setpoints . . . . . . . . . . . . . . . . . . . . 47
26 Gas Heat Anticipator Setpoints . . . . . . . . . . . . . . . . . . . . . . . 49
27 Gas Rate Cubic Feet Per Hour . . . . . . . . . . . . . . . . . . . . . . . 50
28 Gas Heat Stages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
29 Smart Equipment™ UCB Details . . . . . . . . . . . . . . . . . . . . . 53
31 Ignition Control Flash Codes . . . . . . . . . . . . . . . . . . . . . . . . . 58
32 JA3ZT Charging Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
33 JA4ZT Charging Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
34 JA5ZT Charging Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
5370597-JIM-D-1019
Advertisement
Table of Contents
Related Manuals for Johnson Controls J ZT Series
Summary of Contents for Johnson Controls J ZT Series
-
Page 1: Table Of Contents
R-410A J**ZT SERIES W/SMART EQUIPMENT™ 3 - 5 Ton 60 Hertz TABLE OF CONTENTS General ..........2 Free Cooling Operation . -
