Important Note When Wiring for Common Type (Continued)
JK Type
Model : JKHX0752N/JKHX0952N/JKHX1252N
Clamping
strap
Power wiring
(field supplied)
Conduit
(field supplied)
Model : JKHX1862N
Clamping
strap
Power wiring
(field supplied)
Earth screw
Conduit
(field supplied)
165
Connection for Solenoid
Valve Kit (for 3WAY)
Power wiring
(field supplied)
Remote control wiring
and Inter-unit control
wiring (field supplied)
Connection for Solenoid
Valve Kit (for 3WAY)
Remote control wiring
and Inter-unit control
wiring (field supplied)
Model: JKHX2452N
Clamping
strap
Conduit
(field supplied)
FORM 121.00-EG1
ISSUE DATE: 5/31/2012
Connection for Solenoid
Valve Kit (for 3WAY)
Remote control wiring
and Inter-unit control
wiring (field supplied)
JOHNSON CONTROLS
