Johnson Controls JX Series Engineering Manual page 105

Ceiling Mounted Exposed Horizontal (JT Type)
Major Component Specifications
Indoor unit (A)
MODEL No.
Power source
Controller P.C.B. Ass'y
Fan...(Number diameter / length in. (mm))
Fan motor
Model...Nominal output
Power source
No. of pole...r.p.m. (230V, High)
Coil resistance
(Ambient temperature 68°F)
Run capacitor
Safety device
Operating temperature
Electronic expansion valve
Coil
Coil resistance (at 68°F)
Valve body
Heat exchanger
Coil
Rows...fi n pitch
Face area
105
W
rpm
Ÿ
VAC, μF
Open °F (°C)
ORG – GRY : 46
Ÿ
RED – GRY : 46
in. (mm)
2 2
ft (m )
FORM 121.00-EG1
ISSUE DATE: 5/31/2012
JTHX1252N
208 - 230 V / 1ø / 60 Hz
CR-UMHX0762 (Microprocessor)
Centrifugal (2 ... ø5-1/2 (ø140))
DK8-63C280HB...60W
340 VDC
8P...920
RED – WHT : 53.0
WHT – BLU : 53.0
BLU – RED : 53.0
–
fuse
+4 +2
285 (141 )
–5 –3
UKV-U030E
YEL – GRY : 46
BLK – GRY : 46
UKV-25D32
Aluminum plate fi n / Copper tube
3...7/128 (1.4)
1.66 (0.154)
JOHNSON CONTROLS
5
6
7
8
