OMS-1 Oil Separator Alarm Device
Installation and Operating Instructions
Normal situation
Alarm on
Fault alarm on
Copyright © 2019 Labkotec Oy
TEST FUNCTION
Test function provides an artificial alarm, which can be used to test the
function of the OMS-1 alarm device and the function of other
equipment, which are connected to OMS-1 via its relay.
Attention! Before pressing the Reset/Test button, make sure that the
change of relay status does not cause hazards elsewhere!
When pressing the Reset/Test push button:
Oil Alarm and Fault LED indicators are immediately on.
Buzzer is immediately on.
Relay de-energize after 2 sec of continuous pressing.
When the Reset/Test push button is released:
LED indicators and buzzer go immediately off.
Relay energize immediately.
When pressing the Reset/Test push button for the first time:
Buzzer will go off.
When pressing the Reset/Test push button after that:
Fault LED indicator is immediately on.
Oil Alarm LED indicator remains on.
Buzzer remains on. If it has been reset earlier, it will return to be on.
When the Reset/Test push button is released:
The device returns right away to the preceding status.
When pressing the Reset/Test push button:
The device does not react to the test at all.
