CONGRATULATIONS . . .
on your purchase of an activTek INDUCT 750/2000 air
purification enhancement system. This unit is designed
to be installed into an existing HVAC system. Please
read and follow all service procedures outlined in this
manual. Use only genuine activTek replacement parts
available from your Distributor.
If you have any questions concerning this or any activTek
product, contact your Distributor.
Please record the name and phone number of your
activTek Distributor:
Name _________________________________________
Phone ________________________________________
Please record the serial number of your activTek INDUCT
750/2000:
Serial # ________________________________________

SPECIFICATIONS

Features:
Ozone Production:
• 0.00 ppm with ozone free replaceable
ActivePure® Cell.
• 0.40 ppm maximum with ozone replaceable
ActivePure® Cell.
Electrical:
• 100/240 V ~ 50/60 HZ
• 0.17A 17 watts (INDUCT 750)
• 0.17A 19 watts (INDUCT 2000)
Mechanical:
• Distribution via air handler.
Dimensions:
• INDUCT 2000: 9.62" x 9.62" x 11.25"
(24 cm x 24 cm x 28.5 cm.)
• INDUCT 750: 9.62" x 9.62" x 7.48"
(24 cm x 24 cm x 19 cm.)
• Weight: 3 pounds (1.2 kg.)
Operating Temperature:
• < 200˚F
Coverage:
• INDUCT 2000: up to 2000 sq. ft. (186 m
• INDUCT 750: up to 750 sq. ft (229 m
Warranty:
• Limited 3 year Warranty
2
CONTENTS
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
About activTek INDUCT 750/2000 . . . . . . . . . . . . . . . 2
Product Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation Hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Recommended Installation Tools. . . . . . . . . . . . . . . . 4
Installation Requirements. . . . . . . . . . . . . . . . . . . . . . . 4
Metal Ductwork Installation . . . . . . . . . . . . . . . . . . 5-6
Fiberglass Ductwork Installation . . . . . . . . . . . . . . 6-7
Changing the ActivePure® Cell . . . . . . . . . . . . . . . . . . 8
Changing the Ballast . . . . . . . . . . . . . . . . . . . . . . . . 9-10
Maintenance/UV Lamp Indicator. . . . . . . . . . . . . . . 10
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
This owner's manual is also available online at:
http://www.activTek.net.
activTek INDUCT 750/2000 is easily mounted into
the supply side of air conditioning and heating system
air ducts where many problems can start.
Optional ozone units are available with the
same basic components as ozone free INDUCT units
and an ozone cell.
NOTE: Ozone units and ozone cells are not available
)
2
)
2
to California.
WARNING: UV Light in operation.
Disconnect unit from power
supply before servicing.
Failure to follow warnings
may result in severe eye
damage and electrical shock.
Location for Protective Earth Line.
WARNING: To prevent damage to the
unit, operating environment
temperature must never
exceed 200˚F.
WARNING: This unit must be installed
by a licensed HVAC
contractor. Failure to do so
will void warranty of the
product.
WARNING: This unit must never be used
with an extension cord.
