Fig. 4
THE MAINS SUPPLY CONNECT POINT MUST BE WITHIN THE ZONES SHOWN
Fig. 4A

MAINS CABLE ROUTING - AGA DC3G

MAINS CABLE FED FROM
CONTROL TRAY LEFT OR
RIGHT EXIT THROUGH
DUCTING DEPENDENT UPON
POSITION OF SUPPLY
SOCKET
9
DESN 516643
DESN 516105
