AGA DUAL CONTROL
Model No's: DC3G
Installation
Guide
REMEMBER: when replacing a part on this appliance, use only replacement parts
that you can be assured conform to the safety and performance specification that
we require. Do not use reconditioned or copy parts that have not been clearly
authorized by AGA.
PLEASE READ THESE INSTRUCTIONS BEFORE COMMENCING SITE SURVEY
OR INSTALLING THIS APPLIANCE.
IMPORTANT :
SAVE INSTRUCTIONS FOR FUTURE REFERENCE
For use in USA/Canada
1
02/16 EINS 516911

Advertisement

Table of Contents
loading

Related Manuals for AGA DC3G

Summary of Contents for AGA DC3G

  • Page 1 AGA DUAL CONTROL Model No’s: DC3G Installation Guide REMEMBER: when replacing a part on this appliance, use only replacement parts that you can be assured conform to the safety and performance specification that we require. Do not use reconditioned or copy parts that have not been clearly authorized by AGA.

  • Page 2: Table Of Contents

    GENERAL INSTALLATION REQUIREMENTS APPLIANCE DIMENSIONS - AGA DC3G TECHNICAL DATA INSTALLATION 6 - 9 CONNECTION TO THE POWER SUPPLY - AGA DC3G MAINS CABLE ROUTING - AGA DC3G FLUE SYSTEM 12 - 15 WIRING DIAGRAM - AGA DC3G GAS SUPPLY - U.S. PIPE THREADS...

  • Page 3: Product Safety

    PRODUCT SAFETY MEANING/DESCRIPTION SYMBOL SIGNIFICATION/DESCRIPTION WARNING/CAUTION AVERTISSEMENT Une consigne de sécurité An appropriate safety instruction appropriée doivent être suivies ou should be followed or caution to a garde d’un danger potentiel potential hazard exists. exists. TENSION DANGEREUSE DANGEROUS VOLTAGE Pour indiquer les dangers To indicate hazards arising from résultant des tensions dangerous voltages.

  • Page 4: General Notes

    ” (740mm) could be used to check if the AGA Dual Control fully built appliance is able to fit through the property grounds and doors into its installation position in the kitchen. It must also be considered that the height of the appliance is ”...

  • Page 5: Appliance Dimensions - Aga Dc3G

    In particular the width across the appliance recess could be critical. APPLIANCE WEIGHT (Excludes Packaging) Model: AGA Dual Control (DC3G) - 996lb (452kg) GAS CONNECTION - AGA DC3G ONLY 1/4” NPT MALE AT LEFT REAR OF APPLIANCE...

  • Page 6: Technical Data

    It is essential that the base or hearth on which the range stands should be level and be capable of supporting the total weight of the range. The base of the built-in AGA plinth must be level and sit above the finished height for service access.
  • Page 7 Tiling When the range is to stand in a recess or against a wall which is to be tiled, under no circumstances should the tiles overlap the range top plate, access to remove the hotplate must be allowed for servicing at a later date.
  • Page 8 Fig. 2 DESN 516668...
  • Page 9 Top Plate Adjustment - AGA DC3 (See Fig. 4) In general, adjustment of the top plate is to be avoided. However minimum use of the top plate adjusters can be used to improve the alignment of the top plate. Fig. 3...

  • Page 10: Connection To The Power Supply - Aga Dc3G

    CONNECTION TO THE POWER SUPPLY - AGA DC3G Electric Shock Hazard Rating Plate is located behind removable plinth, see Fig. 4A, Page 11 Electrical Grounding is required on this appliance. DO NOT connect to the electrical supply until the appliance is permanently grounded.

  • Page 11: Mains Cable Routing - Aga Dc3G

    MAINS CABLE ROUTING - AGA DC3G MAINS CABLE FED FROM CONTROL TRAY LEFT OR RIGHT EXIT THROUGH DUCTING DEPENDENT UPON POSITION OF SUPPLY SOCKET Fig. 4 DESN 516643 RATING LABEL LOCATED BEHIND PLINTH, PULL TO REMOVE THE MAINS SUPPLY CONNECTION AND ISOLATION POINT MUST BE WITHIN THE ZONE SHOWN Fig.

  • Page 12: Flue System

    SEE FIGS. 5, 6, 7, 8 & 9 The flue system must be installed in accordance with the federal, state and local codes. Only genuine AGA approved flue pipe is to be used. Maximum permitted flue length run including bends is 13 ft.
  • Page 13 Minimum siting dimensions for flue terminals Minimum Position Spacing inch/mm A Directly below an openable window, air vent, or any other ”/300 ventilation opening B Below gutter, drain/soil pipe 3”/75 C Below eaves ”/200 D Below a balcony or car port roof ”/200 AROUND THE HOUSE DESN 511052...
  • Page 14 Fig. 8 DESN 516850...
  • Page 15 ” (300mm) MIN. ” (300mm) MIN. ” (800mm) MAX. ” (800mm) MAX. ” ” (4m) MAX. (4m) MAX. DOWNWARD RUNS UP TO 11 ”(300mm) BELOW THE APPLIANCE ARE ALLOWED, PROVIDED ONLY ONE BEND IS USED. DOWNWARD RUNS USING 2 BENDS ARE NOT ALLOWED. MAXIMUM VERTICAL RISE = 59 ”...

  • Page 16: Wiring Diagram - Aga Dc3G

    WIRING DIAGRAM - AGA DC3G Fig. 10...

  • Page 17: Gas Supply - U.s. Pipe Threads

    GAS SUPPLY - U.S. PIPE THREADS NOTE: A MANUAL SHUT-OFF VALVE MUST BE INSTALLED IN AN ACCESSIBLE LOCATION IN THE GAS PIPE EXTERNAL TO THE APPLIANCE FOR THE PURPOSE OF TURNING ON OR SHUTTING OF GAS TO THE APPLIANCE. ALL GAS CONTROLS MUST BE U.S. PIPE THREADS. Maximum Heat Input 2 kW (6,800 Btu/h).

  • Page 18: Aga Dc3G P/F Handrail Connection

    AGA DC3G P/F HANDRAIL CONNECTION 1. Fit the handrail bracket over the fixing stud located on the top plate. Lock into position by tightening the grub screw nearest the appliance. (See Fig. 12). Fig. 12 DESN 516883 Next the handrail, endcaps and handrail require assembly.
  • Page 19 Finally, fit the plinth facia to the magnets on the front of the plinth. Make sure that the plinth facia is centrally located and does not overhang the range. Commission the AGA Dual Control, as stated in the relevant Installation Instructions and carry out functional test on each of the features of the AGA Dual Control.

  • Page 20: Commissioning

    COMMISSIONING Fig. 14 DESN 516966 Inlet Pressure Testing 1. Turn off control knob (A) and turn off electrical supply to range. 2. Remove facia by pulling off hotplate control knob and removing four fixing screws. 3. Remove inlet pressure test nipple sealing screw (D) and fit rubber tube over the nipple. 4.

  • Page 21: Yearly Service

    CAUTION: BEFORE LIGHTING: ENSURE KNOB (A) IS IN THE OFF POSITION (SEE FIG. 27). ALSO ENSURE GAS SUPPLY TO RANGE IS ON, AND THE GAS SERVICE COCK (C) IS IN THE ON POSITION (SEE FIG. 31), AND THE ELECTRICAL SUPPLY TO THE AGA IS SWITCHED ON. LIGHTING PROCEDURE - SEE FIGS 15 - 23 1.

  • Page 22: Replacement Parts

    MAIN BURNER DESN 516967 REPLACEMENT PARTS In the event of a component failure which requires replacement, contact your local AGA distributor who will advise and supply the necessary replacement. INSTRUCTIONS Hand these instructions to the user for retention, and instruct in the safe operation of the appliance.

  • Page 23: Burner Controls

    OFF POSITION IGNITION POSITION Fig. 15 Fig. 16 MAIN BURNER FLAME SUPERVISION ON POSITION BURNER POSITION Fig. 17 Fig. 18 NORMAL RUNNING LOW FIRE Fig. 19 Fig. 20...

  • Page 24: Contents List (Loose Items)

    GRILL RACK - SMALL AG4M210269 WIRE BRUSH EACS23230 TOASTER EACS47380 MEAT TRAY - SMALL EMTY530217 MEAT TRAY - LARGE EMTY530218 AGA RECIPE BOOK (2 & 4 OVEN) EACS40640 PLINTH FACIA ASSY AE1M231475 PLATE - OUTLET BLANKING AG2M210568 HANDRAIL AE4M231411 HANDRAIL MOUNTING BRACKET AE4M212288 ‘O’...
  • Page 28 For further advice or information contact your local AGA Ambassador With AGA Marvel’s policy of continuous product improvement, the Company reserves the right to change specifications and make modifications to the appliance described and illustrated at any time Supplied by AGA Marvel 1260 E.
