USERʼS MANUAL
Model No. SFTL18910.1
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts are
damaged or missing, DO NOT CON-
TACT THE STORE; please contact
Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
1-866-362-4490
CALL TOLL-FREE:
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.iconservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XTR 90 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Freemotion XTR 90

Summary of Contents for Freemotion XTR 90

  • Page 1 All manuals and user guides at all-guides.com www.iconfitness.com USERʼS MANUAL Model No. SFTL18910.1 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CON- TACT THE STORE;...

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decals may not be shown at actual size. FREEMOTION is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    13. To purchase a surge suppressor, see informed of all warnings and precautions. your local FREEMOTION dealer or call the telephone number on the front cover of this 3. Use the treadmill only as described.
  • Page 4 All manuals and user guides at all-guides.com 20. Never leave the treadmill unattended while it 24. Inspect and properly tighten all parts of the is running. Always remove the key, unplug treadmill regularly. DANGER: the power cord, and press the power switch into the off position when the treadmill is not Always unplug the power in use.

  • Page 5: Before You Begin

    Thank you for selecting the revolutionary ing this manual, please see the front cover of this man- FREEMOTION XTR 90 treadmill. The XTR 90 tread- ual. To help us assist you, please note the product ® mill offers an impressive selection of features designed model number and serial number before contacting us.

  • Page 6: Assembly

    All manuals and user guides at all-guides.com ASSEMBLY To watch an assembly video, go to www.freemotionfitness.com/assembly or use your mobile phone or smartphone to read the QR code at the right. A reader appli- cation such as ShopSavvy must be installed on your mobile phone or smartphone. To download ShopSavvy, go to www.shopsavvy.mobi.
  • Page 7 All manuals and user guides at all-guides.com 1. Make sure that the power cord is unplugged. Attach the Right Wheel Cap (90) to the Base (94) with two #8 x 3/4" Screws (2). Attach the Left Wheel Cap (not shown) to the left side of the Base (94) in the same way.
  • Page 8 All manuals and user guides at all-guides.com 3. Hold the Upright (86) against the Base (94). Be careful not to pinch the Upright Wire (79). Insert three 3/8" x 2 3/4" Patch Bolts (7) with three 3/8" Star Washers (11) into the Upright. Partially tighten the 3/8"...
  • Page 9 All manuals and user guides at all-guides.com 5. Set the console assembly face down on a soft surface to avoid scratching the console assem- Console bly. Remove the Screw (A) and lift off the Assembly Crossbar (80). Discard the Screw. 6.
  • Page 10 All manuals and user guides at all-guides.com 7. Attach the Left Tray (101) and the Right Tray (102) to the console assembly with six #8 x 1/2" Screws (1). Console Assembly 8. With the help of a second person, hold the con- Console sole assembly near the Upright (86).
  • Page 11 All manuals and user guides at all-guides.com 9. Set the console assembly on the Handrails (81, 82) and the Upright (86). Be careful not to Console pinch any wires. Insert the excess Upright Wire Assembly (not shown) into the Upright. Attach the console assembly to the Crossbar (not shown) with three #8 x 1/2"...
  • Page 12 All manuals and user guides at all-guides.com 11. Firmly tighten the four 3/8" x 1" Patch Bolts (4) (only one side is shown). Then, firmly tighten the three 3/8" x 2 3/4" Patch Bolts (7). Slide the Upright Cover (87) down against the Base (94).

  • Page 13: Operation And Adjustment

    All manuals and user guides at all-guides.com OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT that is properly installed and grounded in accor- dance with all local codes and ordinances. IMPORTANT: The treadmill is not compatible with Your treadmill features a walking belt coated with high- performance lubricant.
  • Page 14 All manuals and user guides at all-guides.com CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the consoleʼs stereo sound system The treadmill console offers an impressive array of while you exercise. features designed to make your workouts more effec- To turn on the power, see page 15.
  • Page 15 All manuals and user guides at all-guides.com HOW TO TURN ON THE POWER 2. Select the manual mode. IMPORTANT: If the treadmill has been exposed to Press the Manual Control button on the console. If cold temperatures, allow it to warm to room tem- you are not connected to iFit Live, the manual perature before turning on the power.
  • Page 16 All manuals and user guides at all-guides.com 5. Follow your progress with the displays. When an iFit Live mod- ule is connected to The matrix—When www.iFit.com, the iFit you select the manual Live symbol will light in mode, the matrix will the center display.
  • Page 17 All manuals and user guides at all-guides.com HOW TO USE AN ONBOARD WORKOUT grammed for the next segment, the new speed and/or incline setting will appear in the displays for 1. Insert the key into the console. a few seconds and the treadmill will automatically adjust to the new speed and/or incline setting.
  • Page 18 All manuals and user guides at all-guides.com HOW TO USE AN IFIT LIVE WORKOUT When you select an iFit Live workout, the display will show the duration of the workout, the distance Note: To use an iFit Live workout, you must have an you will walk or run, the approximate number of optional iFit Live module.
  • Page 19 All manuals and user guides at all-guides.com THE INFORMATION MODE Press the decrease button next to the Enter button to view the next screen. The display will show the con- The console features an information mode that keeps trast level of the displays. Press the Incline increase track of treadmill information and allows you to person- and decrease buttons to adjust the contrast.
  • Page 20 All manuals and user guides at all-guides.com HOW TO USE THE STEREO SOUND SYSTEM HOW TO ADJUST THE CUSHIONING SYSTEM Remove the key from the console and unplug the To play music or audio books through the consoleʼs power cord. The treadmill features a cushioning sys- stereo speakers, you must connect your MP3 player, CD player, or other personal audio player to the con- tem that reduces the impact as you walk or run on the...

  • Page 21: How To Fold And Move The Treadmill

    All manuals and user guides at all-guides.com HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to the lowest position and slide the adjustable cush- left.

  • Page 22: Troubleshooting

    All manuals and user guides at all-guides.com TROUBLESHOOTING Most treadmill problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 23 All manuals and user guides at all-guides.com Locate the Reed Switch (57) and the Magnet (55) on the left side of the Pulley (56). Turn the Pulley until the Magnet is aligned with the Reed Switch. Make sure that the gap between the Magnet and the Reed Switch is about 1/8 in.
  • Page 24 All manuals and user guides at all-guides.com PROBLEM: The walking belt is off-center or slips when walked on SOLUTION: a. If the walking belt is off-center, first remove the key and UNPLUG THE POWER CORD. If the walking belt has shifted to the left, use the hex key to turn the left idler roller bolt clockwise 1/2 of a turn;...

  • Page 25: Exercise Guidelines

    All manuals and user guides at all-guides.com EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 26: Part List

    All manuals and user guides at all-guides.com PART LIST—Model No. SFTL18910.1 R1110A To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual. Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw Belt Guide #8 x 3/4"...
  • Page 27 All manuals and user guides at all-guides.com Key No. Qty. Description Key No. Qty. Description Left Tray #8 Star Washer Right Tray 3/8" x 2" Incline Motor Bolt Cable Tie Incline Stop Bracket Module Housing – Userʼs Manual Hex Key Note: Specifications are subject to change without notice.

  • Page 28: Exploded Drawing

    All manuals and user guides at all-guides.com EXPLODED DRAWING A—Model No. SFTL18910.1 R1110A...
  • Page 29 All manuals and user guides at all-guides.com EXPLODED DRAWING B—Model No. SFTL18910.1 R1110A...
  • Page 30 All manuals and user guides at all-guides.com EXPLODED DRAWING C—Model No. SFTL18910.1 R1110A...
  • Page 31 All manuals and user guides at all-guides.com EXPLODED DRAWING D—Model No. SFTL18910.1 R1110A...

  • Page 32: Ordering Replacement Parts

    All manuals and user guides at all-guides.com ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
