Introduction

2 Introduction

2.1 System Overview

1
2
ISD Power Supply Module
Run/Err
U
ZK
24V
5V
Safe
CAN Warn
Failure
Warning
Output (300V) OK
Output (90V) OK
Stand-By
Safety I
Fuse L I CAN 1.In CAN 2.In
X11 X12
90V OK
Fuse L II CAN 1.Out CAN 2.Out
300V OK Signal Outputs
Error
Enable
300V Signal Inputs
X21 X22
10A
12 11
Illustration 2.1 ISD Servo System with 3 Servomotors
Number Description
1 Ethernet
2 Power supply module
3 Connection box
4 Master
5 CAN line
6 Encoder box
Table 2.1 Legend to Illustration 2.1
The servomotors are self-contained distributed drives,
which means that the drive electronics is housed together
with the motor in the same casing. The motion control
software also runs independently in the servomotor; which
reduces the load on the higher-level control system.
A master system controls the servomotors. In this system
servomotors operated in a DC group are controlled by a
master system.
®
VLT ISD Power Supply Module Operating Instructions
3
CAN-ID
4 6
2 8
RS232
0
Service
Set
Err
Safety II
CAN 3.In CAN 4.In CAN 5.In
X13 X14 X15
CAN 3.Out CAN 4.Out CAN 5.Out
X23 X24 X25
10
Number
7
8
9
10
11
12
®
MG75H102 - VLT is a registered Danfoss trademark
4
5
9
Description
Master encoder
Terminating resistor
ISD servomotor
Hybrid cable (DC & CAN)
DC line
AC line
6
7
8
5
