  • Page 1 IP to Relay Command Converter for Velocity Control System Atlona Manuals AT-VCC-RELAY Command Converter Velocity Accessory...
  • Page 2 Version Information Version Release Date Notes 11/19 Initial release AT-VCC-RELAY...
  • Page 3 Welcome to Atlona! Thank you for purchasing this Atlona product. We hope you enjoy it and will take a extra few moments to register your new purchase. Registration only takes a few minutes and protects this product against theft or loss. In addition, you will receive notifications of product updates and firmware.
  • Page 4 Atlona requires that products returned are properly packed, preferably in the original carton, for shipping. Cartons not bearing a return authorization or case number will be refused. Atlona, at its sole discretion, reserves the right to reject any products received without advanced authorization. Authorizations can be requested by calling 1-877-536-3976 (US toll free) or 1-408- 962-0515 (US/international) or via Atlona’s website at www.atlona.com.
  • Page 5 Damage, deterioration or malfunction resulting from the installation or removal of this product from any installation, any unauthorized tampering with this product, any repairs attempted by anyone unauthorized by Atlona to make such repairs, or any other cause which does not relate directly to a defect in materials and/or workmanship of this product.
  • Page 6: Important Safety Information

    Only use attachments/accessories specified by Atlona to avoid fire, shock, or other hazards. The information bubble is intended to alert the user to helpful or optional opera- tional instructions in the literature accompanying the product.
  • Page 7: Table Of Contents

    Table of Contents Introduction Features Package Contents Panel Description Connection Diagram Configuration Relay Sensor VHelp and webGUI Control Macros Event Macros Room Trigger Split Rooms Appendix Specifications AT-VCC-RELAY...
  • Page 8: Introduction

    • The AT-VCC-RELAY-KIT is PoE, to power the unit, simply plug it into a PoE compatible network switch. If the network switch is not PoE capable, a PoE injector (purchased separately) or USB can be used.
  • Page 9: Panel Description

    Connect the 3.5mm connector to the 3.5mm port of the VCC. Connection Diagram ETHER HDMI AT-VG W-25 AT-VGW-250 (redundancy) ETHER HDMI W-25 AT-VG AT-VGW-250 AT-VCC-IR Display AV LAN AT-VCC AT-VTP-550-BL AT-VCC-RS232 AT-VCC AT-VTP-800-WH AT-VCC-RELAY Projector AT-VCC Projector Screen AT-VTP-800-BL AT-VCC-IR Display AT-VCC AT-VCC-RELAY...
  • Page 10: Configuration

    Place the jumpers as shown below, this can be done to a single connector or to both to create up to 3 independent relays. SPDT SPST SPDT SPDT Single Pole, Double-Throw is best used when two circuits are going to one common, such as: switching between two input circuits or selecting two power sources. AT-VCC-RELAY...
  • Page 11: Sensor

    Connect the AT-VCC to a network switch (PoE is best if a PoE switch is not available, a power injector or mini USB to USB cable may be used). Download VHelp from the resource tab of https://atlona.com/product/at-vcc-relay-kit/. Unzip the file to the local PC Double-click the VHelp executable to open the program.
  • Page 12 11 Open any browser on the network and type in the IP address of Velocity. 12 Select the = button from the top left corner and select Sites. NOTE: Connecting the VCC to Velocity can only be done once Velocity has been set up. View the Velocity Manual for instructions. AT-VCC-RELAY...
  • Page 13 15 Select the + button located at the top right corner of the room. A new menu will open. 16 Press the scan network button. All Atlona devices found will appear in the unassigned list. 17 Select the Add button next to the VCC. A new pop up will appear.
  • Page 14 Select Relay/Sensor from the drop down menu. • Select the Relay/Sensor configurations. NOTE: Ensure to select the Relay type that matches how the connector was pinned. Refer to Relay Sensor sections if unsure how to set up the connector. AT-VCC-RELAY...
  • Page 15: Control

    Macros can be used to manually open and close the relay ports, this can be used to control projector screens, room dividers, and more. Select the Macros button. A new screen will take over the Room Control Options menu. Press the orange and white + button in the top right corner. New options will appear. AT-VCC-RELAY...
  • Page 16: Event Macros

    Select the Event Macros button. A new screen will take over the Room Control Options menu. Press the orange and white + button in the top right corner. New options will appear. AT-VCC-RELAY...
  • Page 17 NOTE: On1 and On2 are used when the VCC is set to Double Pole, Double-Throw. While in this mode, off will not be functional. NOTE: These are just general examples for control. The VCC-Relay can be used to control anything that use relay controls. AT-VCC-RELAY...
  • Page 18: Room Trigger

    In this example, the sensor being broken will trigger Velocity to set the VCC-Relay port 1 to open. This example will cause the VCC’s connected screen to close. It can also be used to trigger the events from the Event Triggers at the same time. AT-VCC-RELAY...
  • Page 19: Split Rooms

    Scroll down to the Control Page Layout section and Select the Enable Split Room slider. A new option will appear below. Enable the Is room currently split if the room is currently set up as split, this is not required for setting up the rest of the control. AT-VCC-RELAY...
  • Page 20 The room will now switch back and forth between Split and Open based on if the room divider is open or closed. With the optional steps it will also trigger the display screen open and closed at the same time. AT-VCC-RELAY...
  • Page 21: Appendix

    Contact Closure: Use for input from devices or feedback from external relays Power Micro-B 802.3af-compliant Dimensions Inches Millimeters H x W x D (AT-VCC-RELAY) 0.90 x 3.24 x 2.00 22.86 x 82.29 x 50.80 H x W x D (AT-VCC) 0.82 x 1.22 x 2.58 20.82 x 30.98 x 65.53 Weight...
