  • Page 1 P 5 WASH LIGHT P 5 WHITE P 5 TUNABLE WHITE...

  • Page 2: Series Dimensions

    P-5 series dimensions Measurements in millimetres and inches (in brackets). Drawing not to scale.

  • Page 3: User Manual

    The SGM logo, the SGM name and all other trademarks in this document pertaining to services or products by SGM or its affiliates and subsidiaries are trademarks owned or licensed by SGM or its affiliates or subsidiaries.

  • Page 4: Table Of Contents

    Contents P-5 series dimensions ......................2 Safety information ......................7 Overview ..........................10 Parts identification and terminology .................11 Preparing for installation ....................12 Installing the P-5 ......................13 Connecting AC Power ......................15 Configuring the fixture ......................16 Configuring the fixture using an Android telephone via RFID..................16 Master/Slave configuration ............................
  • Page 5 Configuring the fixture for DMX control ................22 About DMX ..................................22 Setting the DMX address............................... 22 Setting the DMX mode..............................23 Full Color Calibration and Color Temperature Correction (P-5 only) ................25 Fixture personality settings ....................26 Setting the dimming curve ............................. 26 Flipping the OLED display .............................
  • Page 6 Fixtures and accessories ....................57 Included items................................57 Ordering information ..............................57 User’s notes ........................59...

  • Page 7: Safety Information

    Read the safety precautions in this section before unpacking, installing, powering or operating this product. The P-5 series luminaries are multi-environmental fixtures with an IP-rating of 65, intended for professional use only. They are not suitable for household use. Impropre a l’usage domestique.
  • Page 8 Preventing burns and fire WARNING! Take measures to prevent burns and fire. • Install in a location that prevents accidental contact with the fixture. • Install only in a well-ventilated space. • Install at least 0.3 m (12 in.) away from objects to be illuminated. •...
  • Page 9 Avoid personal injury WARNING! Take measure to prevent personal injury. • Do not look directly at the light source from close range. • Take precautions to prevent injury due to falls when working at height. • For permanent installation, ensure that the fixture is securely fastened to a load-bearing surface with suitable corrosion-resistant hardware.

  • Page 10: Overview

    DMX support, stand-alone programs, dimming, and a lamp life expectancy of 50,000 hours*. The P-5’s also offer a variation of beam angles with 15°, 21° or 43° interchangeable lenses. This manual covers installation, use and maintenance of the P-5. All documentation is also available from the SGM web-site: http://www.sgmlight.com...

  • Page 11: Parts Identification And Terminology

    Parts identification and terminology 44 x 10 W LEDs Base Safety wire eyelet Cooling fans Tilt lock DMX in and out Wireless antenna socket OLED display Control panel Power connections Tilt lock...

  • Page 12: Preparing For Installation

    Preparing for installation Unpack the fixture and inspect it to ensure that it has not been damaged during transport. ™ The P-5 is shipped with two quarter-turn brackets, that can be used to mount the fixture at elevation, and a W-DMX wireless antenna.

  • Page 13: Installing The P-5

    Installing the P-5 The P-5 may be installed in any orientation, but if installed horizontally with a downward beam-angle, water can potentially pool in the fan wells. Under normal operation the moisture will evaporate. However, in locations with high rainfall, you may wish to fabricate a rain shield above the fixture, or modify the position and orientation of the fixture to minimize pooling.
  • Page 14 Two quarter-turn brackets are supplied with the fixture if it is to be flown above the ground. Remove the floor stand/base and rig the P-5 to a support truss or structure using the supplied brackets and suitable clamps. Fasten a safety cable (not shown) between the support structure and the attachment point on the fixture.

  • Page 15: Connecting Ac Power

    Connecting AC Power The P-5 can operate on any 208–240 V, 50/60 Hz AC mains power supply. It draws approximately 2 amps at full power. For permanent installation, have a qualified electrician wire the mains cable directly to a suitable branch circuit. The junction’s ingress protection (IP) rating must be suitable for the location.

  • Page 16: Configuring The Fixture

    Configuring the fixture using an Android telephone via RFID P-5 fixtures can also be configured wirelessly, via RFID, using the SGM Tool app installed on an Android smart phone that has NFC support (ISO 15693 and ISO 18000-3 mode 1 compatible, operating on 13.56 MHz ±7k Hz carrier frequency).

  • Page 17: Master/Slave Configuration

    Master/Slave configuration You can set a P-5 fixture to operate as master fixture to another P-5 fixture (which then becomes a slave fixture), or an entire group of P-5 fixtures (which then becomes slave fixtures). The assigned slave fixture(s) will mimic the settings of the master fixture.

  • Page 18: Setting A Static Color Manually

    Setting a static color manually The fixture can be configured to display a predefined and static color using the “Manual Quick color” menus (see “Control menu” on page 47). Note that whenever the “Manual Quick color” settings are changed, the fixture will be set by default to automatically start in quick color mode whenever it is powered on.

  • Page 19: Using Stand-Alone Operation

    Using stand-alone operation Stand-alone operation is where the fixture is not connected to a control device, but is preprogrammed with a series of up to 24 scenes, that play continuously in a loop. Up to three stand-alone programs can be defined and run from the menus, and one of the programs can be set to run by default whenever the fixture is started.

  • Page 20: Connecting To A Dmx Control Device

    Connecting to a DMX control device The fixture is controllable using a DMX control device and it can be connected using either a DMX cable or via the P-5’s built-in wireless receiver system. If using a cabled DMX system, connect the DMX in cable (with male 5-pin XLR plug) and out cable (with female 5-pin XLR plug) to the DMX data link.

  • Page 21: Attaching The W-Dmx™ G4 Wireless Receiver

    ™ Attaching the W-DMX G4 wireless receiver The W-DMX G4 wireless receiver is an included accessory and is recommended for long-range wireless operation. Before you connect the wireless receiver, ensure that there is no DMX cable connected to the fixture. Attach the supplied wireless DMX antenna to the connector on the back of the fixture.

  • Page 22: Configuring The Fixture For Dmx Control

    Configuring the fixture for DMX control About DMX The P-5 can be controlled using signals sent by a DMX controller on a number of channels (which varies depending on the DMX mode that has been set). The first channel used to receive data from a DMX control device is known as the DMX start address. Each P-5 must have a DMX start address set.

  • Page 23: Setting The Dmx Mode

    Setting the DMX mode Using the “DMX mode” menu available from the control panel, specify the DMX mode that provides the fixture controls that you require: P-5 DMX modes Function Individual control of color channels for red, green & blue. White is automatically mixed in. Individual control of color channels for red, green, blue and white (RGBW).
  • Page 24 P-5 TW DMX modes Function Intensity & white temperature control (2200k-5300K) White temperature control (2200K, 3000K, 4000K, and 5300K) Intensity, white temperature control (2200K, 3000K, 4000K, and 5300K), shutter, strobe, pulse and open shutter effects. Fine and coarse control of white temperatures (2200K, 3000K, 4000K, and 5300K) P-5 W DMX modes Function Intensity...

  • Page 25: Full Color Calibration And Color Temperature Correction (P-5 Only)

    Full Color Calibration and Color Temperature Correction (P-5 only) All channel modes except 3 Channel Mode RGB: Lets you choose between raw or white-calibrated color (6500K default) via the Control Menu (“Settings White Calibrated”) 3 Channel Mode RGB: Features full color calibration (irrespective of current color setting) when you mix 2 or 3 colors to ensure uniform color between products.

  • Page 26: Fixture Personality Settings

    Fixture personality settings Setting the dimming curve The setting of the dimming curve will determine the fixture’s behavior, when changing the light intensity between 0% - 100%. Linear control provides uniform adjustment throughout the control action, whereas gamma corrected dimming provides finer control at low light levels, where the eye is more sensitive to change.

  • Page 27: Setting The Fan Mode

    Setting the fan mode For operating environments where low-noise is a requirement or where the fixture will be operating in high temperatures, it is possible to adjust the default fan speed to low or high using the “Settings Fan mode” menu.

  • Page 28: Service

    Apart from the lens module, there are no user-serviceable components in the fixture. Do not open the P-5, as doing so is likely to damage the ingress protection. Consult your SGM dealer if the fixture operates abnormally, is defective or otherwise in need of service or repair.
  • Page 29 Dismantle the front and unscrew the highlighted front plugs with an Unbrako 6/HOP6 Allen key. Take out the lens module. Place the new lens on the PCB print spacers and carefully press the lens module in place.
  • Page 30 Screw in the highlighted front plugs with an Unbrako 6/HOP6 Allen key (Nm 1,0) and place three Silica Gel bags (not included in lens kit) as shown. Place the sealing frame (facing upwards - see below) on top of the lens module.

  • Page 31: Upgrading The Firmware

    The firmware installed on the fixture can be identified using the “Info Firmware version” menu. We recommend that you keep your fixture’s firmware up-to-date. Visit http://www.sgmlight.com to download the latest firmware. To perform firmware updates, you need a Windows-based personal computer and a SGM USB 5-Pin-XLR upload cable (available from your SGM distributor).

  • Page 32: Dmx Protocols

    DMX protocols Configuring DMX is described “Setting the DMX mode” on page 23. P-5 DMX Protocols 3 Channel Mode - RGB plus automatic White Default Channel Name DMX value Description Info Fader type percentage value No RED > 0,0% 100,0% 0 (0%) Fade Maximum RED...
  • Page 33 4 Channel Mode - RGBW (Raw mode) Default Channel Name DMX value Description Info Fader type percentage value No RED > 0,0% 100,0% 0 (0%) Fade Maximum RED No GREEN > GREEN 0,0% 100,0% 0 (0%) Fade Maximum GREEN No BLUE > BLUE 0,0% 100,0%...
  • Page 34 6 Channel Mode - RGBW plus Shutter (Raw mode) Default Channel Name DMX value Description Info Fader type percentage value 0,0% 2,7% Closed 3,1% 5,9% Open 6,3% 59,2% Strobe Fast > Slow Shutter 59,6% 68,6% Pulse - Open Slow > Fast 10 (3,9%) Snap 69,0%...
  • Page 35 Default Channel Name DMX value Description Info Fader type percentage value No BLUE > BLUE 0,0% 100,0% 0 (0%) Fade Maximum BLUE No WHITE > WHITE 0,0% 100,0% 0 (0%) Fade Maximum WHITE...
  • Page 36 8 Channel Mode (16 bit) - RGBW Default Channel Name DMX value Description Info Fader type percentage value No RED > 65535 0,0% 100,0% 0 (0%) Fade Maximum RED No GREEN > GREEN 65535 0,0% 100,0% 0 (0%) Fade Maximum GREEN No BLUE >...
  • Page 37 9 Channel Mode (16 bit) - Intensity & RGBW Default Channel Name DMX value Description Info Fader type percentage value No light > Intensity 0,0% 100,0% 0 (0%) Fade Maximum light No RED > 65535 0,0% 100,0% 0 (0%) Fade Maximum RED No GREEN >...
  • Page 38 10 Channel Mode (16 bit) - Intensity & RGBW Default Channel Name DMX value Description Info Fader type percentage value No light > Intensity 65535 0,0% 100,0% 0 (0%) Fade Maximum light No RED > 65535 0,0% 100,0% 0 (0%) Fade Maximum RED No GREEN >...

  • Page 39: P-5 W Dmx Protocols

    P-5 W DMX Protocols 1 Channel Mode - Intensity Default Channel Name DMX value Description Info Fader type percentage value No WHITE > WHITE 0,0% 100,0% 0 (0%) Fade Maximum WHITE...
  • Page 40 2 Channel Mode - Shutter & Intensity Default Channel Name DMX value Description Info Fader type percentage value 0,0% 2,7% Closed 3,1% 5,9% Open 6,3% 59,2% Strobe Fast > Slow Shutter 59,6% 68,6% Pulse - Open Slow > Fast Snap (3,9%) 69,0% 78,0%...
  • Page 41 2 Channel Mode (16 bit) - Intensity Default Channel Name DMX value Description Info Fader type percentage value No WHITE > WHITE 65535 0,0% 100,0% 0 (0%) Fade Maximum WHITE...

  • Page 42: P-5 Tw Dmx Protocols

    P-5 TW DMX Protocols 2 Channel Mode - Intensity with CTC Default Channel Name DMX value Description Info Fader type percentage value No light > Intensity 0,0% 100,0% 0 (0%) Fade Maximum light 0,0% 100,0% 2200K-5300K 0 (0%) Fade 4 Channel Mode - White control (Raw mode) Default Channel Name...
  • Page 43 Default Channel Name DMX value Description Info Fader type percentage value No WHITE > 4000K WHITE 0,0% 100,0% 0 (0%) Fade Maximum WHITE No WHITE > 5300K WHITE 0,0% 100,0% 0 (0%) Fade Maximum WHITE...
  • Page 44 6 Channel Mode - Shutter, Intensity & White control (Raw mode) Default Channel Name DMX value Description Info Fader type percentage value 0,0% 2,7% Closed (3,9%) 3,1% 5,9% Open 0 (0%) 6,3% 59,2% Strobe Fast > Slow 0 (0%) Shutter Snap 59,6% 68,6%...
  • Page 45 Default Channel Name DMX value Description Info Fader type percentage value No WHITE > 3000K WHITE 0,0% 100,0% 0 (0%) Fade Maximum WHITE No WHITE > 4000K WHITE 0,0% 100,0% 0 (0%) Fade Maximum WHITE No WHITE > 5300K WHITE 0,0% 100,0% 0 (0%)
  • Page 46 Default Channel Name DMX value Description Info Fader type percentage value No WHITE > 4000 WHITE 65535 0,0% 100,0% 0 (0%) Fade Maximum WHITE No WHITE > 5300 WHITE 65535 0,0% 100,0% 0 (0%) Fade Maximum WHITE...

  • Page 47: Control Menu

    Displays product type. Firmware Version Displays installed software version. Serial Number Displays serial number. RDM ID Displays RDM ID (for use with the SGM Tool App). DMX View Displays received DMX levels. Temperatures Displays fixture temperatures MB: LED: (Mainboard and LED panel)
  • Page 48 Level 1 Level 2 Level 3 Function Info LED On Time Displays LED on time (Red, Green, Blue, and White) (continued) R: G: B: W: LED On Time Resettable R: G: B: W: Displays recorded operating data and error codes. Debug Service use only.
  • Page 49 Level 1 Level 2 Level 3 Function Settings Wireless DMX Wireless DMX Disables wireless DMX out operation. (continued) (continued) out disable Startup Mode Select Startup Default operating mode when fixture is powered on: Mode 1. Quick Color 2. Stand-alone 3. DMX (factory default) Startup Program Stand-alone program 1, 2, or 3.
  • Page 50 Level 1 Level 2 Level 3 Function Settings Flip Display Enable Flips control panel display. (continued (continued) Display Saver Display Dim Dims the OLED display when the control panel is not in use. Display Off Turns off the OLED display when the control panel is not in use.
  • Page 51 Level 1 Level 2 Level 3 Function Settings Minimum values Min. White (P-5) (continued (continued) Min. Line 1 (P-5 W) Min. Line 2 (P-5 W) Min. Line 3 (P-5 W) Min. Line 4 (P-5 W) Min. 3000 (P-5 TW) Min. 2200 (P-5 TW)
  • Page 52 Level 1 Level 2 Level 3 Function Settings Minimum values Min. 4000 (continued (continued) (P-5 TW) Min. 5300 (P-5 TW) RFID Write Refresh Rate Factory Default Reset the fixture to factory default settings. Service Pin Service Menu Manual Quick Color Red (P-5) Static quick color - red mix (0-255).
  • Page 53 Level 1 Level 2 Level 3 Function Manual Quick Color Blue (P-5) Static quick color - blue mix (0-255). Sets fixture to quick color (continued) (continued) startup mode. White Static quick color - white mix (0-255). Sets fixture to quick (P-5/ P-5 W) color startup mode.
  • Page 54 Level 1 Level 2 Level 3 Function Manual Master/Slave Sets fixture to operate as Master or Slave fixture. (continued) Editor Program Currently selected program (1, 2, or 3). Scene Currently selected scene (1-24). Red (P-5) Red value in currently selected scene (0-255). Green (P-5) Green value in currently selected scene (0-255).
  • Page 55 Level 1 Level 2 Level 3 Function Manual Editor 5300 (P-5 TW) 5300K white temperature value in currently selected scene (continued) (continued) (0-255). Shutter Shutter setting in currently selected scene (0-255): Shutter Blackout (0-7) Shutter Open (8-15) Variable Strobe (16-151) Pulse Open (152-175) Pulse Close (176-199) Variable Random Strobe (200-244)
  • Page 56 Level 1 Level 2 Level 3 Function Manual Editor Wait Time (Sec.) Wait (static) time in current scene in sec. (0-59). (continued) (continued) Test Stops test sequence execution. Automated Test Initiates a self-test sequence. Burn-in Test Service use only. (30 min.) Display Test Service use only.

  • Page 57: Fixtures And Accessories

    Barn door 4-way ............................Order no: 83061120 Barn door 8-way ............................Order no: 83061121 Barn door color frame..........................Order no: 83061122 SGM USB uploader cable ......................... Order no: 83062011 Flight case (for 4 fixtures - P-5/Q-7/X-5) ....................Order no: 82051501...
  • Page 58 APPROVALS AND CERTIFICATIONS Certified to ............................CSA Std. C22.2 No. 166 Conforms to................................UL Std. 1573 Conforms to........................2006/95/EC: Low Voltage Directive Conforms to..........................2011/65/EU: RoHS2 Directive RoHS 4008543 The information in this document is subject to change without notice...

  • Page 59: User's Notes

    User’s notes...
