• Using the Intuicom RTK Bridge-X to AGI-3 data/power cable, connect the RTK
Bridge-X data port to the data port on the AGI-3 as shown in Diagram 2.
Example of how to connect the data power cable into the boot for the AGI-3 Data connector
• Please Note: Intuicom recommends sealing any and all connections to prevent
accidental water intrusion. Seal can be created by using silicone, heat/cold shrink,
etc.
2.4
Configuring the X30 to receive an RTK corrected position
• From the main menu select System -> GPS -> Correction
Version 1.0
Diagram 2
5
Section 2: Installation Instructions
Intuicom, Inc.
