2.1

Configuration

• Configure the Intuicom RTK Bridge–X to connect to GPS/GNSS Reference network
and obtain RTCM correction data stream from an appropriate single reference station,
such as a VRS.
• Configure the resulting RTK correction data to be output at a known baud rate (a
baud rate of 38400 is recommended).
• Confirm GPS and cellular antenna (typically a combined antenna with two coaxial
cables with TNC connectors) are connected and placed where they have good sky
view and good cellular signal.
2.2

AGI-4 cable pinout

• Verify the pinout on the Deutsch connector on the RTK Bridge–X to AGI-4
data/power cable to match the appropriate pin-out. See Pin-out Diagram 1
Deutsch
3
6
1
4
4
2.3

AGI-3 cable pinout

• Configure the pin-out on the Deutsch connector on the RTK Bridge-X to AGI-3
data/power cable to match the appropriate pin-out. See Pin-out Diagram 2
Pin-out Diagram 2 choose either Port A or D for AGI-3
Deutsch Cable Color
4 Brown
1 White
6 Green
Version 1.0
Pin-out Diagram 1
Cable Color
Red
Receive (from RTK Bridge-X to
Green
Xmit (to RTK Bridge-X from
White
Black
Brown
Signal GND
Xmit (to RTK Bridge from
remote device)
Receive (from RTK Bridge
to remote device)
Section 2: Installation Instructions
Signal
Power
remote device)
remote device)
Power Ground
Signal Ground
Signal AGI-3 Port A
14, 16, or 27
4
AGI-4 AUX
connector
2
11
10
9
12
AGI-3 Port D
14, 16, or 27
35 33
25 23
