Result
The HMI device must be logged on at the effective range.
The "Effective range name" object is displayed in green.
Example:
6.2.4.3

Log off at the effective range

Starting situation
The "Effective range name" object is displayed in green.
The HMI device must be logged on at the effective range.
Example:
Action
The operator touches the "Effective range name" object.
If the "Effective range name" object is protected with a password, the operator has to enter his user
name and password. See also Check list: Data security (Page 50)
After a query the HMI device is logged off from the effective range.
Result
The "Effective range name" object is displayed in white.
Example:
The HMI device must be logged off from the effective range.
