2. Wire the conductors: L1- RED; L2 - BLACK; N -WHITE. 3. Connect the AC branch circuit junction box to the point of utility interconnection. Figure 2 Step 4. Attach the APsystems microinverters to the racking or the PV module frame. Figure 3 APsystems YC500 Quick Design Guide...
Page 3
Step 6. Install a protective end cap on the open AC connector of the last microinverter in the AC branch circuit. Step 7. Ground the system. Figure 5 Step 8. Connect the APsystems microinverters to the PV modules. Figure 6 Step 9. Complete the APsystems installation map.
