Focus 500
15.2 SPARE PARTS FOCUS 500 (FIG. 26)
ORDER NO.
POS. DESIGNATION
1 2343 946 Cover of air filter compartment
2 2343 947 Air filter (3 pcs.)
3 2343 948 Fixture for shoulder strap (incl. screws)
4 2344 464 Carrying strap
5 0514 209 Cleaning brush
6 2324 745 Funnel (3 pcs.)
7 2344 041 Velcro to secure the power cable
8 2341 099 Transport case
9 2358 464 Spray gun rear part (including position 1-3)
15.3 SPARE PARTS MULTIFINISH SPRAY ATTACHMENT (RED) (FIG. 27)
ORDER NO.
POS. DESIGNATION
1 2335 658 MultiFinish spray attachment (red) (with 1000 ml container)
2 2333 179 Spray jet width adjusting lever
3 2314 591 Spray jet adjustment ring
4 2333 180 Union nut (red)
5 Air cap
2317 807
6 2314 585 Air screen
7 Nozzle (S 4.1)
2317 423
8 Nozzle seal
2323 934
9 2304 027 Ventilating hose, valve cover, diaphragm
10 O-ring of spray attachment
0417 308
11 2324 250 Body of gun (including position 8-10)
12 Container seal
2319 223
13 2319 222 Feed tube
2324 248
14 Fine feed tube filter (red, 5 pc.)
2324 249
Coarse feed tube filter (white, 5 pc.)
2322 451
15 Container with cover 1000 ml
2315 539
Lubricating grease
