LED-90 Series
Installation Instructions
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations,
if applicable.
• Do not mount near gas or electrical heaters.
• Do not use outdoors.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering
by unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
• Allow battery to charge for 24 hours before first use.
10070145 REV 2 - 08/2020
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS!
Technical Support
■ (623) 580-8943 ■ technicalsupport@barronltg.com
1
800-533-3948 www.barronltg.com
Advertisement
Related Manuals for BARRON Exitronix LED-90 Series
Summary of Contents for BARRON Exitronix LED-90 Series
- Page 1 LED-90 Series Installation Instructions IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS. When using electrical equipment, basic safety precautions should always be followed including the following: • DISCONNECT AC POWER SUPPLY BEFORE SERVICING. • Installation and servicing of this equipment should be performed by qualified service personnel only. •...
- Page 2 LED-90 Series Installation Instructions Wall/Ceiling Mount - Back Power Feed Fig. 1 1. Insert a flat screwdriver underneath both of the locking tabs on the Conduit Entry bottom of the fixture to loosen and separate the enclosure from Knockout the backplate. (Fig. 1) Backplate 2.
- Page 3 LED-90 Series Installation Instructions Electrical Connections All electrical connections should be made inside the J-box. Make electrical connection as follows: 120VAC 277VAC White - Common White - Common Black - 120VAC Orange - 277VAC Red (277VAC) Green - Ground Green - Ground Backplate Black (120VAC) Power...
- Page 4 LED-90 Series Installation Instructions Self-Test/Self-Diagnostics (G2) Operation The purpose of this option is to provide Self-testing and Self-diagnostic capabilities to the emergency unit. At predetermined intervals, the emergency unit will automatically switch into battery mode. Refer to the Self-Test Feature section below for timing details.
