D.1

Overview

Refer to this chapter if you experience a problem with your terminal server. This chapter
describes:
•

Normal terminal server operations

• How the terminal server indicates errors
• How to reset the terminal server
• What to do if the Ethernet (A, B, or C) light on the front panel goes out
• How to Troubleshoot Internet Software Loading Problems
D.2 Normal Terminal Server Operations
The terminal server automatically runs self tests when you apply power to the unit or use the
RESET button to initialize the unit. Upon successful completion of the self tests, the terminal
server loads software from a memory card, or over the network from a load server.
During the self test and software loading, the lights (LEDs) on the front panel flash to
reflect various types of activity. During self-test, you should observe the following light
activity:
Front Panel Light Activity
All lights ON
CARD, RUN, CON, A, B, and C
(Ethernet) lights OFF
Lights ON, from right (8 status light) to
left (1 status light)
RUN flashes rapidly
When the Self Test completes, the terminal server begins loading software.
0021
Troubleshooting
Meaning
Testing lights (approximately 1
second).
Self Test begins.
Self Test is running.
Successful completion of Self Test.
Appendix D
D-1
