Item
Terminal Signals
Terminal Cabling
Cable Lengths
Memory Card Interface
Serial Line Speed
Maximum Sessions Per Port
Maximum Sessions Per Unit
Controls
1
The maximum sessions per unit/port depends on the amount of memory the unit has available.
This varies based on the software features that are enabled. Refer to the TCP/IP-LAT Software
Release Notes for more information.
0021
Model 723 I/O Module: Transmit Data, Receive Data,
Transmit Ground, Receive Ground, Data Set Ready/Data
Carrier Detect (DSR/DCD), Data Terminal Ready
(DTR),
Ring/Clear-to-Send (RNG/CTS), and Ready-to-Send
(RTS)
Model 721 and 724 I/O Modules: Transmit Data,
Receive Data, Ground, Data Carrier Detect (DCD), Data
Terminal Ready (DTR), and Ring (RNG/CTS)
Model 723 I/O Module: Modular RJ-45
Model 721 I/O Module: two 50-pin Telco
Serial Speed
19.2 Kbps or less
38.4 Kbps
57.6 Kbps
115.2 Kbps
Accepts industry standard JEIDA/PCMCIA
Memory cards.
75 to 115.2K bps
1
8
1
200
Reset push button switch
Appendix A
Technical Specifications
Description
Length
305 meters (1000 feet)
152 meters (500 feet)
60 meters (200 feet)
30 meters (100 feet)
A-1
