Front Panel Light Activity
Ethernet A, B, or C LED ON
CARD LED ON
RUN and Ethernet (A, B, or C) LEDs blink
simultaneously
Port lights go ON, sequentially from right (Port 8
status light) to left (Port 1 status light). Then,
lights go OFF from left to right.
RUN LED flashes slowly
Ethernet (A, B, or C) LED flashes when Ethernet
packets are received
If the LEDs do not behave as indicated, refer to the Appendix D.
0021
Meaning
Terminal server detects network
activity on Ethernet segment to which it
is attached..
Unit is loading from a Memory card
(light ON for approximately 15 seconds).
The Terminal Server 720 is
accessing the Memory card. Do
not remove the card while the
CARD light is ON.
Software load in progress.
Unit has finished loading the software
image, and is decompressing it.
Software loading has completed.
Terminal server is in normal operating
state.
