Order Codes
B.3

Model 721 I/O Module Cabling Order Codes

Product Name and Description
Distribution Panels and Adaptors
Modular Splitter, 8-Port (requires 1 50-Pin extension cable)
Modular Splitter, 24-Port (requires 3 50-Pin extension cables)
Modular Splitter, 8-Port, DEConnect Style, 36-Pin Female
(requires 1 36-Pin DEConnect Adaptor cable, MX-151-3111)
Modular Splitter, 24-Port, DEConnect Style, 36-Pin Female
(requires 3 36-Pin DEConnect Adaptor cables, MX-151-3111)
Distribution Panel, 16-Port, Male DB-25
(includes 2 six-foot Octopus cables)
Distribution Panel, 16-Port, Male DB-25 with 2 panel-mounted
50-pin connectors (requires 2 extension cables, MX-151-079)
Distribution Panel (Blank), 16-Port
(requires 2 six-foot Octopus cables)
Punch Down Block (66M Style)
(requires 2 50-Pin extension cables)
Gender Changer (Telco 50-Pin, Male-to-Male)
Extension Cables (Wired Straight Through)
3' Extension, 50-Pin Telco Male-to-Female
10' Extension, 50-Pin Telco Male-to-Female
25' Extension, 50-Pin Telco Male-to-Female
50' Extension, 50-Pin Telco Male-to-Female
10' Extension, 50-Pin Telco Male-to-Bottom-Entry Female
25' Extension, 50-Pin Telco Male-to-Bottom-Entry Female
25' Extension, 50-Pin Telco Male-to-Bottom-Entry Male
DECconnect Adaptor Cables
6' 50-Pin Telco to 36-Pin female
8' 50-Pin Telco to 36-Pin male
25' 50-Pin Telco Male to 36-Pin Bottom-Entry Female
B-58
Order Code
MX-151-3083
MX-151-3081
MX-151-3061
MX-151-3062
MX-151-3080
MX-151-3080
MX-151-3107
MX-151-3082
MX-151-3090
MX-151-3089
MX-151-3104
MX-151-3105
MX-151-3106
MX-151-3112
MX-151-3116
MX-151-3117
MX-151-3110
MX-151-3111
MX-151-3063
