6. The configuration menu prompts:
Select network interface segment (A,B,C) [A]:
Specify which Ethernet network interface segment to which the Terminal Server 720
shall be attached. Valid answers are A, B, or C. After you have selected a segment and
pressed the RETURN key, the menu will prompt:
(Type any key to continue)
Press any key; the unit returns you to the Modify Unit Configuration Menu (Figure C-5).
Modify Unit Configuration Menu - Choice M.
If you select choice M of the Modify Unit Configuration Menu, the menu prompts:
Display Load status messages (Y,N) [Y]:
It might be necessary to prevent the unit from generating status messages during the software loading
process, if a device such as a bar code reader, which cannot interpret status messages, is connected to a
serial port. To disable load status messages, enter 'N'. Otherwise, leave the default (Y) intact.
The configuration menu prompts:
Total installed memory in megabytes (2,4) [2]:
The prompt indicates the amount of installed memory for which the unit has been configured.
If you remove memory, you must change this value. (Preferably, you should change this value
before you remove the memory.) Also, if you have enabled more software features than the unit
can support with the reduced memory, you will not be able to re-initialize the unit after you
remove the SIMMs. If this happens, you must re-install the SIMMs and configure the TCP/IP-
LAT software image for fewer features.
SIMMs should only be installed or removed by qualified personnel. Refer to the Installation
Instructions supplied with your SIMM kit on how to install and remove SIMM memory
2
modules .
The unit automatically detects added memory. Therefore, you do not need to increase the
"installed memory" value when you install additional memory. If you choose to increase the
value anyway, do not do so before you install the additional memory. If you do, the unit will
generate the following warning message:
WARNING: After saving the new configuration, you must turn the
unit off and install the additional memory specified (x MB).
2
The order code for for a 2 MByte SIMM memory upgrade kit is MX-500-5744.
