Configuration Menu
C.3.1 Option 1 - Display Configuration
To select this option, answer 1 to the "Enter menu selection" prompt of the Terminal Server
Configuration Menu. The dialog displays a Display Unit Configuration Menu, which is
shown in Figure C-2:
Display Unit Configuration Menu
1. Load/dump configuration #1 (Enabled)
2. Load/dump configuration #2 (Disabled)
3. Load/dump configuration #3 (Disabled)
M. Miscellaneous unit configuration
X. Exit to main menu
Enter menu selection [X]:
Display Unit Configuration Menu - Choices 1, 2, and 3.
If you select choices 1, 2, or 3 of the Display Unit Configuration Menu, the menu will display a
list of currently stored configuration values and the new configuration values for the specified
load/dump configuration. This display is similar to the list shown in Figure C-3.
Status:
Image load method:
Parameter load method:
Dump method:
CARD/XMOP/MOP filename:
Default unit IP addr:
DTFTP host IP addr:
DTFTP gateway IP addr:
DTFTP filename:
Network interface:
(Type any key to continue)
Figure C-3 (part 1 of 2). Sample Unit Configuration Display
C-66
Figure C-2. The Display Unit Configuration Menu.
Stored Configuration
Enabled
CARD XMOP MOP BOOTP RARP
CARD XMOP MOP BOOTP RARP
XMOP MOP BOOTP RARP
XPCSRV20
0.0.0.0
N/A
N/A
N/A
Segment A
New Configuration
Enabled
CARD XMOP MOP BOOTP RARP
CARD XMOP MOP BOOTP RARP
XMOP MOP BOOTP RARP
XPCSRV20
0.0.0.0
N/A
N/A
N/A
Segment A
