INSTALLATION AND OPERATION MANUAL
OUTDOOR DECORATIVE GAS APPLIANCE
WARNING:
DANGER
f i r e - p a r t s . c o m
DANGER
IF YOU SMELL GAS:
Shut off gas to the appliance.
Extinguish any open flame.
If odor continues, keep away from the appliance and immediately call your gas supplier or fire de-
partment.
WARNING:
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.
WARNING:
Improper installation, adjustment, alteration, service or maintenance can cause injury or property
damage. Read the installation, operating, and maintenance instructions thoroughly before installing
or servicing this equipment.
For Outdoor Use Only
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a camper, tent, car, or
home.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
HUSSONG MANUFACTURING CO., INC.
204 INDUSTRIAL PARK DR.
LAKEFIELD, MN. 56150
P.O. BOX 577
Report No. 216-O-40-6.5
SEPT 2013
PFT-40-REV-02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for kozy heat Northern Firelights PFT-40
Summary of Contents for kozy heat Northern Firelights PFT-40
- Page 1 INSTALLATION AND OPERATION MANUAL OUTDOOR DECORATIVE GAS APPLIANCE WARNING: For Outdoor Use Only DANGER CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. f i r e - p a r t s . c o m Never use this appliance in an enclosed space such as a camper, tent, car, or home.
-
Page 2: Table Of Contents
TABLE OF CONTENTS CONTENTS Table of Contents SAFETY INFORMATION Safety Information GENERAL INFORMATION General Information ADDITIONAL COMPONENTS REQUIRED Additional Components Required OPTIONAL ACCESSORIES Optional Accessories Installation Overview DIMENSIONS Dimensions SPECIFICATIONS Determining Outdoor Location Clearances to Combustibles ASSEMBLY Assembly 6-16 Propane Cylinder f i r e - p a r t s . -
Page 3: Safety Information
SAFETY INFORMATION THIS APPLIANCE IS HOT WHEN OPERATING AND CAN CAUSE SEVERE BURNS IF CONTACTED. Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to operating instructions could cause fire or injury. Installation and repair should be done only by a qualified service person. The appliance should be inspected before use and at least annually by a qualified service person. -
Page 4: General Information
GENERAL INFORMATION This fireplace has been tested by OMNI-Test Laboratories, Portland, Oregon and complies with: ANSI Z21.97-2012 • CSA 2.41-2012, “Standard for Outdoor Decorative Gas Appliances.” CAN/CGA 2.17-M91 (R2009), “Gas-Fired Appliance for Use at High Altitudes.” CODE AND SUPPLY REQUIREMENTS: When an appliance is for connection to a fixed piping system, the installation must conform with local codes, or in the absence of local codes with the National Fuel Gas Code, ANSI Z223.1/NFPA 54;... -
Page 5: Dimensions
DIMENSIONS TABLE TOP " [1221mm] " [1221mm] " [1221mm] 36 1 4 " [920mm] 12 7 " [328mm] 36 1 4 " [920mm] 12 7 " [328mm] 11 5 36 1 4 " [920mm] 12 7 " [296mm] 11 5 "... -
Page 6: Specifications
SPECIFICATIONS DETERMINING OUTDOOR LOCATION When selecting a location, ensure all clearances are met as specified below. Other clearances may apply. This appliance must be installed in an open-air situation with natural ventilation, without stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural convection. Typically an outdoor space is not enclosed but, any enclosure in which the appliance is used shall comply with one of the following: An enclosure with walls on all sides, but at least one permanent opening at ground level and no overhead cover. -
Page 7: Assembly
ASSEMBLY MAIN ASSEMBLY PARTS LIST HARDWARE Code Description Qty. Description Burner / Valve Train Assembly Screws Tile Kit (purchased separately) 1/4-20 flange nuts Tile Alignment Brackets Tile Tray Trim Kit TOOLS REQUIRED Tile Tray 7/16 nut driver Tile Tray Brackets 1/4 nut driver Legs Back Side Panel... -
Page 8: Assembly
ASSEMBLY STEP 1. Secure tile tray sections together with (4) screws. f i r e - p a r t s . c o m Figure 7a STEP 2. Position tile tray brackets over mounting studs. Do not secure at this time. Figure 7b... -
Page 9: Assembly
ASSEMBLY STEP 3. Position legs over mounting studs / tile tray brackets as shown. Secure tile tray brackets and legs with flange nuts (4 ea. leg/ tile bracket). f i r e - p a r t s . c o m X 16 Figure 8a STEP 4. -
Page 10: Assembly
ASSEMBLY STEP 5. Locate left panel. Secure to legs using (6) screws, making sure flange end with no holes is positioned next to tile tray as shown. 3 screw holes f i r e - p a r t s . c o m X 6 for 23”... -
Page 11: Assembly
ASSEMBLY STEP 7. Install cylinder pedestal as shown with retention bolt facing out. Secure with (4) screws. Install leveling bolts into leg base mounting holes. Retention Bolt f i r e - p a r t s . c o m Figure 10a STEP 8. -
Page 12: Assembly
ASSEMBLY STEP 9. Using (4) screws, secure tile tray to front and back panels. f i r e - p a r t s . c o m Figure 11a STEP 10. Install tile alignment brackets as shown, making sure flanges face away from center. -
Page 13: Assembly
ASSEMBLY STEP 11. NOTE If installing Optional Color Changing LED Light Kit, do so now. Follow instructions on pages 21-22. With valve train facing front of table (side with valve key assembly hole), install burner/valve train assembly, setting assembly over previously installed tile alignment brackets. -
Page 14: Assembly
ASSEMBLY STEP 13. Thread floor plate through valve key assembly hole a n d in to va l ve . Ti gh t e n, ma ki n g s u r e wh e n completed that writing on floor plate is aligned as shown. - Page 15 ASSEMBLY STEP 15. Evenly spread glass media across burner media tray. D O N O T O P E R A T E T H I S A P P L I A N C E W I T H O U T G L A S S B U R N E R M E D I A I N P L A C E . Use ONLY #PF40-G4PC-GR Glass Media in this appliance.
-
Page 16: Propane Cylinder
PROPANE CYLINDER WARNING If these instructions are not followed exactly, a fire causing death or serious injury may occur. PROPANE CYLINDER SPECIFICATIONS This appliance is designed for use with a 20 lb. (9.1 kg) size propane cylinder only (not supplied). Inspect the fuel supply co nnection for signs of leakage (including the hose) before e ach use of the appliance. - Page 17 ASSEMBLY STEP 18. Install access panel by aligning hooks on panel with slots at bottom of left side leg sections. Lift up slightly to insert access panel upper hooks into slots at top of leg sections. Remove by lifting up and out. f i r e - p a r t s .
-
Page 18: Fuel Gas Conversion
FUEL GAS CONVERSION This appliance is factory equipped for use with LP (propane) gas. Converting to Natural Gas requires Natural Gas Burner Orifice #41 (purchased separately). This appliance must be connected to a 7 inch WC (1.74 kPa) gas pressure regulator if using Natural Gas. THE CONVERSIO N SH ALL BE CARRIED O UT BY A LICENSCE D PLUMBER OR GAS FITTE R, IN ACCORDANCE WITH THE REQUIREMENTS OF THE MANUFACTURER, PROVENCIAL OR TERRITORIAL WARNING... -
Page 19: Lighting And Shutdown
LIGHTING AND SHUTDOWN FOR YOUR SAFETY - READ BEFORE LIGHTING IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT, CAUSING WARNING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. A. This appliance is lit by a match or hand fire starter. BEFORE LIGHTING, smell all around the appliance area for gas. -
Page 20: Maintenance
MAINTENANCE FLAME APPEARANCE: Flame appearance is affected by several factors including altitude and fuel quality. Although the venturi setting has been factory set, adjustments may be necessary for optimal performance and visual aesthetics. When appliance is first lit, the flames will be blue. Flames will gradually turn yellowish-orange during first 15 minutes of operation. -
Page 21: Optional Glass Wind Guard
OPTIONAL GLASS WIND GUARD Kit includes: (4) Glass Panes (8) Corner Brackets (16) Corner Bracket Screws (4) Mounting Legs (4) Attachment Screws NOTE Assemble on a protective surface to prevent damage and scratches. 1. TOP: Position (4) corner brackets on work surface. Insert corners of glass panes into channels. Secure with (8) corner bracket screws. Figure 20a 2. -
Page 22: Optional Color Changing Led Light Kit
OPTIONAL COLOR CHANGING LED LIGHT KIT Electrical power source must be in accordance with all applicable local codes and ordinances and with the National IMPORTANT Electrical Code, ANSI/NFPA 70; or the Canadian Electrical Code, CSA C22.1. Total Electrical Requirements: 120Vac, 60Hz, less than 1 amps. NOTE For optional light kit (Part # P40-LKT) Kit includes: (1) Color Changing LED Light Assembly... - Page 23 OPTIONAL COLOR CHANGING LED LIGHT KIT REMOTE CONTROL OPERATION Brightness Level Increase or decrease static color brightness. Figure 22a ON / OFF Turns light kit on or off. Note: Light will turn on to previous setting. f i r e - p a r t s . c o m Figure 22b Static Colors Chosen color remains constant.
-
Page 24: Replacement Parts List
REPLACEMENT PARTS LIST MAIN ASSEMBLY Code Description Part Number Complete Burner / Valve Train Assembly PF40-401 Burner Tray PF40-135 ---- Burner Tube PF40-035 ---- LP Gas Burner Orifice #50 700-250 ---- NAT. Gas Burner Orifice #41 700-241 Tile Kit (purchased separately) ---------- Tile Alignment Brackets PF40-TAB... -
Page 25: Warranty
WARRANTY Limited 2 Year Warranty Hussong Manufacturing Company, Inc. (“Hussong Mfg.”) warrants this appliance from the date of purchase to the original purchaser, that it is free of defects in materials and workmanship at the time of manufacture. Warranty registration is not necessary. Please retain your proof of purchase invoice with model and serial number to file with the warranty claim.
