M O D EL S :
# P R C - 3 6 / # P R C - 3 6 - R F
'P R I N C ETO N '
D i r e c t V e n t G a s F i r e p l a c e
INSTALLATION AND
OPERATING MANUAL
US Patent #6004493
INSTALL THIS FIREPLACE CORRECTLY CAN CAUSE SERIOUS STRUCTURAL
Report No. 216-F-10-5
READ INSTRUCTIONS CAREFULLY BEFORE INSTALLATION. FAILURE TO
AND FIRE HAZARDS AND MAY VOID YOUR WARRANTY
www.kozyheat.com
WARNING: If the information in these instructions
is not followed exactly, a fire or explosion may
result, causing property damage, personal injury
or loss of life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch electrical switches; do not use the
phone in your building.
Immediately call your gas supplier from a
neighbor's phone. Follow your gas supplier's
instructions.
If you cannot reach your gas supplier, call the fire
department.
Installation & service must be performed by a qualified
installer, service agency, or the gas supplier.
This appliance is only for use with the type(s) of gas
indicated on the rating plate and may be installed in an
aftermarket permanently located, manufactured (mobile)
home, where not prohibited by local codes. See owner's
manual for details. This appliance is supplied with a
conversion kit.
IMPORTANT:
:
.
May 2007
