Chapter 4: BIOS Setup
[*Active*] Serial Port 1
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Advanced
Serial Port 1 Configuration
Use This Device [Enabled]
Logical Device Settings:
Current: IO=3F8h; IRQ=4;
Possible: [Use Automatic Settings]
Mode : [RS232]
WARNING: Disabling SIO Logical Devices may have unwanted
side effects.
PROCEED WITH CAUTION.
Version 2.18.1263. Copyright (C) 2019 American Megatrends, Inc.
Use This Device
Enables or disables the serial port.
Possible:
Configures the base address for the serial port.
Mode
Configures the serial port mode to RS232, RS422 or RS485.
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
[*Active*] Serial Port 2
Enable or Disable this Logical
Device.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Use This Device
Enables or disables the serial port.
Possible:
Configures the base address for the serial port.
50
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Advanced
Serial Port 2 Configuration
Use This Device [Enabled]
Logical Device Settings:
Current: IO=2F8h; IRQ=3;
Possible: [Use Automatic Settings]
WARNING: Disabling SIO Logical Devices may have unwanted
side effects.
PROCEED WITH CAUTION.
Version 2.18.1263. Copyright (C) 2019 American Megatrends, Inc.
Enable or Disable this Logical
Device.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
