Chapter 2: Jumpers and Connectors
RS422/485 Terminator
Connector type: 1x2 2-pin header
Connector location: J1, J2, J3 and J4
J3
1
2
J1
1
2
1
2
J2
J4
1
2
Pin
J1, J2, J3, J4 all off
J1, J2, J3, J4 all on
J1, J2, J3, J4 All Off: default
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
Settings
Terminator Disable
Terminator Enable
11
NViS 6308 Series User Manual
