Chapter 3: System Setup
7. Close the load plate. While closing the load plate, make sure the front
edge of the load plate slides under the retention knob.
Do not force the CPU into the socket. Forcing the CPU into
CAUTION!
CAUTION!
CAUTION!
the socket may bend the pins and damage the CPU.
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
Retention Knob
28
8. Push the load lever down and hook the load lever under the retention tab.
NViS 6308 Series User Manual
