6.3 Information menu

All status data and fault indications can be seen in the information
menu. The information menu can be seen in all operating modes
(ON-OFF-AUTO). To open the information menu, mark the
symbol using the button
through the menu by means of the buttons
desired menu item by pressing the button
In the information menu the following data can be read:
• fault indications
• operating hours
• number of starts
• max. measured motor current.
Information menu
Fig. 16 Menu structure for information menu
14
and press the button . Navigate
and . Select the
. See also fig. 16.
F_01 Fault LOG
R_01 Hour counter
R_02 Impulse counter
R_03 Measured max. motor current [A]
EXIT Back to main menu
20 faults from 01 to 20
20 F006 ...
01 F002
000020
007200
3.9
EXIT
