Log Set Assembly: LOGS-I35FB
Models: ESCAPE-I35FB, ESCAPE-I35-C, ESCAPE-I35-F, ESCAPE-35-IFT
CAUTION: Logs are fragile, handle with care.
5
1
3
Figure 1. Log Set Installed
FLAT SPOT
FOR LOG #5
1
REST LOG ON
BURNER LEDGE
Figure 3. Log #1
Log #1 (SRV2202-702): See Figure 2 for additional references. Position Log #1 as shown in Figure 3. Rest the left and
right ends of Log #1 on the burner ledge. The pilot bracket will support the center of the log. Pull the left end of the log
forward into position.
6
2
4
LOG RESTS ON
PILOT BRACKET
Heat & Glo • LOGS-I35FB Log Instructions • 2202-935 Rev. F • 5/18
LOG PLACEMENT INSTRUCTIONS
1
SRV2202-702
3
SRV2202-704
6
SRV2202-706
PILOT BRACKET
BURNER LEDGE
GRATE TINES
Figure 2. Reference Points
2
SRV2202-701
4
SRV2202-703
5
SRV2202-705
BURNER LEDGE
LIGHT TRAYS
LOG PINS
GRATE
BAR
