Heat & Glo LOGS-2128 Log Placement Instructions

Log Set Assembly: LOGS-2128
Models: ST-36TRB-IPI, PIER-36TRB-IPI
ST-36TVB-IPI, LCOR-36TRB-IPI, RCOR-36TRB-IPI
ST-36TRB-IFT, PIER-36TRB-IFT
CAUTION: DO NOT reposition logs that have been
factory installed! Follow these instructions to position
the logs that were packaged separately.
F igure 1. Log Assembly Location F igure 1. Log Assembly Location
STEP 1. CAUTION!
See Figure 1. Remove the microfoam and inspect the logs for damage. Inspect the four factory installed logs for damage.
Locate the pilot in order to verify your position in relation to the appliance. See Figure 2.
F F igure 3. Placement of Log #1 igure 3. Placement of Log #1
STEP 2. Log #1 (SRV2128-704):
end of Log #1 onto the smooth area on top of Log C.
Logs are fragile! Carefully remove the logs and cardboard tray from the inside of the fi replace.
NOTCH NOTCH
1 1
Mate the notch on the end of log # 1 with the hump on top of log A. Set the other
Heat & Glo • Log Placement Instructions • 2128-935 Rev. B • 2/17
LOG PLACEMENT
3 3
B B
D D
Figure 2. Factory Installed Logs Figure 2. Factory Installed Logs
C C
Figure 4. Placement of Log #1 Figure 4. Placement of Log #1
INSTRUCTIONS
2 2
1 1
PILOT PILOT
C C
A A
HUMP HUMP
1 1
A A
1
