Heat & Glo LOGS-Cerona36 Log Placement Instructions

Log Set Assembly:

Model:
Cerona-36
If the gas logs have been factory installed they should not need to be positioned. If the logs have been packaged separately,
refer to the following instructions.
STEP 1.
LOG #1 (SRV2106-701):
the right side of the pilot bracket (B). Move the right end of log #1 forward until it hits the stick on the burner (A). The closer
the log is to the burner the more glow you will get. Don't place the log too close to the burner or sooting may occur.
STEP 2.
LOG #2 (SRV2106-703):
top branch of log #1 (A). Rest the formed groove of the
lower part of the log on the grate. It may be necessary to tilt
Log #1 forward to properly engage with Log #2.
LOGS-Cerona36
6
1
CAUTION: Carefully remove the logs from the packaging.
Logs are fragile!
1
Place the notch on the left underside of log #1, over the log tab that is located on
A
2
FORMED
GROOVE
Fit log #2 on the
Heat & Glo • CERONA-36 • 2106-935 Rev. B • 7/06
5
3
4
2
STEP 3.
LOG #3 (SRV2106-705):
portion of the log in the grate tine and rest the log on the
formed portion of log #2.
LOG PLACEMENT
INSTRUCTIONS
1
B
A
3
Place the "Y"
