Heat & Glo LOGS-350TRS-D Log Placement Instructions

Log Set Assembly: LOGS-350TRS-D

Models: SL-350TRS-D, SL350TRS-IPI

Note: Figure 1 illustrates the recommended gap between the
burner and the lava rock retainer.
Left rear log tab Left rear log tab
Shoulder screw Shoulder screw
Lava rock retainer Lava rock retainer
Figure 2 Figure 2
CAUTION: Logs are fragile. Log #1 (SRV2113-701): Locate the slot on the bottom right side of log 1. Mate the slot with the
right rear log tab. Pull the front left nose of log #1 forward until it touches the left rear log tab.
Mate log with groove on log # 1 Mate log with groove on log # 1
Groove used to locate log # 3 Groove used to locate log # 3
2 2
Mate log with tine Mate log with tine
Figure 4 Figure 4
Log #2 (SRV2113-702): Locate the notch at the left end of
log # 2. Mate the notch with the tine as shown above. The
top end of log #4 should rest on the groove that is located
on the top of log #1. Swing the center branch toward the
burner (see above).
Right rear log tab Right rear log tab
Grate tine (4) Grate tine (4)
Swing branch towards burner Swing branch towards burner
Heat & Glo • SL-350TRS-E Log instructions • 2113-935 Rev. D • 1/09
LOG PLACEMENT INSTRUCTIONS
3/8 in.
No lava rock
may be placed
past this edge.
Figure 1
Left rear log tab Left rear log tab
Figure 3 Figure 3
3 3
Mate "Y" with groove Mate "Y" with groove
Figure 5 Figure 5
Log #3 (SRV2113-704): Locate the "Y" end of log # 3. Mate
the "Y" end with the groove on log # 2 (see above illustration).
Log # 3 should rest on log # 1, as shown above. The tip of
log #3 should touch log # 2.
Burner
Lava rock
retainer
Groove used to locate log # 2 Groove used to locate log # 2
1 1
Mate slot with tab Mate slot with tab
Tip should touch log # 2 Tip should touch log # 2
Log # 3 should rest on log # 1 Log # 3 should rest on log # 1
1
