DCHT
Digital Transmitter
DCHT, DCHT/E01
Fill in for your records:
Serial Number:
Purchase Date:
INSTRUCTION MANUAL
Quick Start Steps
1) Install good batteries and turn power on (see
pages 5 and 7).
2) Set compatibility mode to match the receiver (see
page 11).
3) Connect signal source, select input type and adjust
input gain for optimum modulation level (see page
10).
4) Set or sync frequency to match receiver (see page
11, 12). Also see receiver manual for scanning pro-
cedure.
5) Set encryption key type and sync with receiver (see
page 13).
6) Set programmable switch to desired function (see
page 13).
7) Verify RF and audio signals are present at the re-
ceiver (see receiver manual).
WARNING: Moisture, including talent's sweat,
will damage the transmitter. Wrap the DCHT
in a plastic baggie, our silicone cover (order
part # DCHTCVR) or other protection to avoid
damage.
