Battery Status LED Indicator
The Power/Function LED on the top
panel will mirror the keypad LED un-
less the programmable switch is set
to Mute, and the switch is turned on.
Alkaline, lithium or rechargeable
batteries can be used to power the
transmitter. The type of batteries in
use are selectable in a menu on the
LCD.
When alkaline or lithium batteries
are being used, the LED labeled
BATT on the keypad glows green
when the batteries are good. The
color changes to red at a mid-point
of the runtime. When the LED be-
gins to blink red, there will be only a
few minutes of operation remaining.
The exact point at which the LEDs
turn red will vary with battery brand
and condition, temperature and
power consumption. The LEDs are
intended to simply catch your atten-
tion, not to be an exact indicator of
remaining time.
A weak battery will sometimes
cause the Power LED to glow green
immediately after the transmitter is
turned on, but it will soon discharge
to the point where it will turn red or
the unit will turn off completely.
Rechargeable batteries give little or
no warning when they are depleted.
If you wish to use these batteries in
the transmitter, the most accurate
way to determine runtime status is
by testing the time provided by a
particular battery brand and type,
then using the BatTime function to
determine remaining runtime.
www.lectrosonics.com
Belt Clips
The wire belt clip may be removed
by pulling the ends out of the holes
in the sides of the case. Be sure to
have a firm grip to avoid scratching
the surface of the housing.
An optional spring-loaded, hinged
belt clip (model number BCSLEBN)
is also available. This clip is at-
tached by removing the plastic hole
cap on the back of the housing and
mounting the clip with the supplied
screw.
IR (infrared) Port
The IR port is available on the top of
the transmitter for quick setup using
a receiver with this function avail-
able. IR Sync will transfer the set-
tings for frequency from the receiver
to the transmitter.
Status LED
Blue LED indicates ready status.
Remote Function
In the Setup Menu, choose to turn
remote function on/off. The "dweedle
tone" remote control is turned on or
off with the Remote Menu, setting
the transmitter to react to tones
received (Enable) or to Ignore the
tones.
Setup...
AutoOn?
ProgSw
Remote
NOTE: Remote control of
settings is enabled using
a third party smart phone
app named DCHTRemote,
published by New Endian,
LLC.
Remote
Enable
Ignore
3
