General Data - Johnson Controls DOA096B21S Series Engineering Manual

DOAS

2.3 General Data

Indoor Unit Type
Model
Indoor Unit Power Supply
Outlet Air Temperature Control *1
Nominal Cooling Capacity
Nominal Heating Capacity
Indoor Temperature Control *2
Nominal Cooling Capacity
Nominal Heating Capacity
Sound Pressure Level *3
(Overall A Scale) (208/230V)
Outer Dimensions
Height
Width
Depth
Net Weight
Refrigerant
Indoor Fan
Airflow Rate
External Pressure (208/230V)
High Pressure
Standard
Motor Nominal Output
Min Circuit Amps
Maximum Fuse Amps
Connections
Refrigerant Piping
Liquid Line
Gas Line
Condensate Drain
OD
ID
NOTES:
*1. Outlet Air Temperature Control
A control system to bring the outlet temperature closer to the set point temperature of the wired controller, using an outlet
air thermistor of the unit.
Nominal capacity (outlet air temperature control) is based on combination with VRF system and following conditions:
Cooling Operation Conditions
Outdoor Temperature:
Discharge Set Temperature: 61°F DB (16.0°C DB)
Piping Length: 24.6 ft. (7.5m)
*2. Indoor Temperature Control
A control system to bring the room atmosphere temperature closer to the set point temperature of the wired controller,
using a temperature sensor (remote sensor or thermistor in wired controller) mounted to any place in the room.
Nominal capacity (indoor temperature control) is based on combination with VRF system and following conditions:
Cooling Operation Conditions
Outdoor Temperature:
Indoor Temperature:
Piping Length: 24.6 ft. (7.5m) Piping Lift: 0 ft. (0m)
*3. The sound pressure level is based on the following conditions.
4.9 ft. (1.5m) beneath the units.
The above data is measured in an anechoic chamber so that reflected sound should be taken into consideration in the
field.
2-2
Btu/h
(kW)
Btu/h
(kW)
Btu/h
(kW)
Btu/h
(kW)
dB
in. (mm)
in. (mm)
in. (mm)
lbs (kg)
cfm
3
(m /min)
in.W.G (Pa)
in.W.G (Pa)
W
A
A
in. (mm)
in. (mm)
in. (mm)
in. (mm)
91°F DB (33.0°C DB)
82°F WB (28.0°C WB)
Piping Lift: 0 ft. (0m)
91°F DB (33.0°C DB)
82°F WB (28.0°C WB)
81°F DB (27.0°C DB)
DOAS
(H,Y)DOA096B21S
AC 1Phase, 208/230V, 60Hz
96,000
(28.2)
60,000
(17.6)
96,000
(28.2)
83,600
(24.5)
50/51
19-1/8 (486)
50 (1270)
44-1/8 (1120)
247 (112)
R410A
1236
(35.0)
1.06/1.24 (265/310)
-
402 (201 x 2 pcs)
4.3
15
Brazed
3/8 (9.52)
7/8 (22.20)
VP25
1-1/4 (32)
1 (25)
Heating Operation Conditions
Outdoor Temperature:
Discharge Set Temperature: 72°F DB (22.0°C DB)
Heating Operation Conditions
Outdoor Temperature:
Indoor Temperature:
32°F DB (0°C DB)
27°F WB (-2.9°C WB)
32°F DB (0°C DB)
27°F WB (-2.9°C WB)
68°F DB (20.0°C DB)
TC-16005-rev.2
