2.7 Operation Space

Model: (H,Y)DOA096B21S
TC-16005-rev.2
Electrical Control Box
Min. 23-5/8 Min. 31-1/2
[600] [800]
Service Access Door
(Min. 23-5/8 [600]
5-7/8 to 7-7/8
[150 to 200]
If the ceiling board can not be detected
for servicing, prepare a service access door below
the indoor unit for removing the indoor unit.
DOAS
Unit: inch [mm]
