Page 3: Table Of Contents
Table of Contents Contents  Task-Oriented Reference ....... 1 Decide According to Upper/Lower Thresholds (ABS Mode) ..........39 Measurement Flow......... 3 Confirming Faulty Measurements ..40 Introduction............. 4 Verifying Package Contents ......4 Safety Information .......... 6 Operating Precautions........8 Chapter 4 Customizing Mea- surement Settings Making Range-Specific Measurement Chapter 1 Overview...
Page 4 Table of Contents  Internal Circuitry ....... 102 Re-Enabling Key Operations  (Key-Lock Cancel) ........68 Electrical Specifications ......103  Setting the Comparator Judgment and Connection Examples ......104 Key Beepers ........69 Ext. I/O Settings ....... 105  Enabling or Disabling the Key Beeper ..69 ...
Page 5 Table of Contents  Create with Visual Basic 2005 ....175  Sample Programs (Visual Basic 2005) ...177 9.10 Device Compliance Documents..179 Chapter 10 Specifications Chapter 11 Maintenance and Service 11.1 Troubleshooting ....... 195  Inspection and Repair ......195 11.2 Cleaning ........... 196 11.3 Error Displays and Solutions ....
Page 6 Table of Contents...
Page 7: Task-Oriented Reference
Task-Oriented Reference Task-Oriented Reference Setting the Measurement Speed (p. 29) To minimize measurement error Setting the measurement speed integration time option (p. 48) Zero Adjustment (p. 34) Judging Measurement Values (Comparator Function) (p. 36) To judge measurement results Comparing the Measurement Settings of Two Instruments (Settings Monitor Function) (p.
Page 8: Appendix 2 Effect Of Thermal Emf
Task-Oriented Reference To enable auto-exporting measurement values to the Auto-Exporting Measurement Values (at End of Measurement) (Data computer Output Function) (p. 87) (Available only with RS-232C interface) Setting Measurement Start Conditions (Trigger Source) (p. 31) Internal trigger [INT] To check operation Calibration (p.
Page 9: Measurement Flow
Measurement Flow Measurement Flow Be sure to read the "Operating Precautions" (p. 8) before use. Installing, Connecting and Turning On Connecting the Power Cord (p. 22) Communicating with Installing (p. 8) the computer (p. 109) GP- IB RS-232C Printing (p. 89) Connecting (p.
Page 10: Introduction
When you receive the instrument, inspect it carefully to ensure that no damage occurred during ship- ping. In particular, check the accessories, panel switches, and connectors. If damage is evident, or if it fails to operate according to the specifications, contact your authorized Hioki distributor or reseller. Content confirmation Confirm that these contents are provided.
Page 11 Verifying Package Contents Options Contact your authorized Hioki distributor or reseller for details. Measurement Probes and Fixtures Interface Cables (connect to measurement jacks)  Model 9637 RS-232C Cable (9-pin to 9-pin/crossover cable/1.8  Model 9140-10 4-terminal Probe Alligator-clip-type measurement probes.
Page 12: Safety Information
Safety Information Safety Information This instrument is designed to conform to IEC 61010 Safety Standards, and has been thor- oughly tested for safety prior to shipment. However, using the instrument in a way not described in this manual may negate the provided safety features. Before using the instrument, be certain to carefully read the following safety notes: If persons unfamiliar with electricity measuring instrument are to use the instrument, another person familiar with such instruments must supervise operations.
Page 13 Safety Information Other Symbols Indicates the prohibited action. (p. ) Indicates the location of reference information. Indicates that descriptive information is provided below. Square brackets indicate instrument display labels (such as setting item names). Bold characters within the text indicate operating key labels. (Bold characters) Unless otherwise specified, Windows represents Windows 95, 98, Me, Windows NT4.0, Windows 2000, Windows XP, or Windows Vista.
Page 14: Operating Precautions
Before using the instrument for the first time, verify that it operates normally to ensure that no damage occurred during storage or shipping. If you find any damage, contact your authorized Hioki distributor or reseller. Instrument Installation Installing the instrument in inappropriate locations may cause a malfunction of instru- ment or may give rise to an accident.
Page 15 Operating Precautions Handling the Instrument To avoid damage to the instrument, protect it from physical shock when transporting and handling. Be especially careful to avoid physical shock from dropping. This instrument may cause interference if used in residential areas. Such use must be avoided unless the user takes special measures to reduce electromagnetic emissions to pre- vent interference to the reception of radio and television broadcasts.
Page 16: Appendix 5 Dimensional Diagram
• Battery internal resistance cannot be measured with this instrument. It will sustain damage. To measure the battery internal resistance, we recommend the Hioki 3554, 3555, BT3562, BT3563 and 3561 Battery HiTesters.
Page 17: Chapter 1 Overview
It is also suitable for measuring impe- Upper limit rial 008004 sized components with Lower limit small rated voltage (Applied Voltage Limit Function) (p. 64) Optional Hioki probes and fixtures are available to con- nect to the mea- surement jacks (BNC jacks (p. 5)).
Page 18 93). Fixtures for Component Measurements (p. 5) The BNC-type measurement jacks exhibit good noise immunity. Ready availability and easy assembly ensure a smooth system setup. Various test fixtures are available for Hioki LCR HiT- esters.
Page 19: Appendix 7 Adjustment
1.1 Product Overview and Features Features Reliable Contact Checks (p. 50) Minimize Human Error and Risk Contact checking (that was previously performed be- - Settings Monitor Function (p. 59) fore and after measuring) is now performed during If the settings are found to be different after comparing measurement, so probe bounce and contact resistance the setting conditions of two instruments, an alarm is fluctuations can be detected.
Page 20: Block Diagram
1.1 Product Overview and Features Block Diagram • A constant current (determined by the measurement range) is applied between the H and L terminals while voltage is measured between the H and L terminals. The resistance value is obtained by dividing the measured A, B voltage (B) by the constant current flow (A).
Page 21: Names And Functions Of The Parts
1.2 Names and Functions of the Parts 1.2 Names and Functions of the Parts Front Panel Viewing the Setting Turning the Power Measurement Values On and Off F1 - F4 key and Settings Judging the Measurement Values (F Key: General) POWER Button (p.
Page 22: Appendix 9 Zero Adjustment
1.2 Names and Functions of the Parts Rear Panel Connecting the Power Cord Serial Number Connect the supplied power cord (p. 22). Shows the serial number.Do not remove this See "Before Turning Power On" (p. 9) label, as it is required for product support. External Control RS-232C Communications Printer Output...
Page 23: Screen Organization
1.3 Screen Organization 1.3 Screen Organization The instrument has three general display screen types: Measurement, Basic Settings and Detailed Settings. See "11.3 Error Displays and Solutions" "Error Displays and Solutions" (p. 197) for error displays. The screen examples in this manual are reversed (black on white) for the best visibility on the printed page. However, the instrument screens can actually be displayed only with white characters on a black background.
Page 24 1.3 Screen Organization Normal display (measurement screen) This screen normally appears while measuring. View currently measurement values and measurement conditions. Some parts of the display depend on the comparator mode and other settings. To display the Basic Settings screen Settings Menu (corresponding to the F keys) Displayed contents depend on the current function settings.
Page 25 1.3 Screen Organization Detailed Settings Shows detailed settings for measurements. Measurement Settings screens Use when adjusting the measurement speed, stability and [MEAS SETTINGS] measurement fault detection functions. DELAY1 Adjust the delay between the probing and trigger input (p. 44). DELAY2 Adjust the target electrical response (p.
Page 26 1.3 Screen Organization...
Page 27: Chapter 2 Measurement Preparations
Measurement Chapter 2 Preparations Be sure to read the "Operating Precautions" (p.8) before installing and connecting this instrument. See "Appendix 4 Rack Mounting" (p. A8) for rack mounting. Rear Panel Front Panel Connect the external interface Installing this instrument (p. 8) (as needed) •...
Page 28: Connecting The Power Cord
• Before using the instrument, make sure that the insulation on the power cord is undamaged and that no bare conductors are exposed. Any damage can cause elec- tric shock, contact your dealer or Hioki representative. To avoid damaging the power cord, grasp the plug, not the cord, when unplugging it from the power outlet.
Page 29: Connecting Measurement Probes And Test Fixtures
2.2 Connecting Measurement Probes and Test Fixtures 2.2 Connecting Measurement Probes and Test Fixtures Connect your measurement probes, optional Hioki probes, or test fixtures to the measurement jacks. Refer to "Options" (p.5) for details of the Hioki option. See the instructions provided with the fixture for operating details.
Page 30: Making Your Own Measurement Probes
2.2 Connecting Measurement Probes and Test Fixtures Making Your Own Measurement Probes Recommended measurement probe specifications Conductor resistance 500 mΩ/m or less Capacitance 150 pF/m or less Cable dielectric material Polyethylene (PE), Teflon (TFE), Polyethylene foam (PEF) Insulation resistance 10 GΩ or more Connector insulating material Teflon (TFE), Polybutylene terephthalate (PBT)
Page 31: Turning The Power On And Off
2.3 Turning the Power On and Off 2.3 Turning the Power On and Off Turning Power On Press the POWER button (it lights up in green). After Power-On A self-test (instrument diagnostic routine) is performed. During the self-test, the following information is displayed while the hardware is verified. Self-test The following information is displayed during self- testing:...
Page 32 2.3 Turning the Power On and Off...
Page 33: Chapter 3 Measurement Set
Metal Exposed found, as electric shock or short-circuit Is the power cord insulation torn, or is any accidents could result. metal exposed? Contact your dealer or Hioki represen- tative. No Metal Exposed Metal Exposed If there is any damage, measurement...
Page 34: Measuring Object Types
3.2 Measuring Object Types 3.2 Measuring Object Types The instrument provides two measurement methods: resistance measurement, and low-power resistance measurement. Select the appropriate measurement method for the type of component to be measured. For general-purpose resistor measurements, use the factory defaults. The power applied to the measuring object = Resistance Value x (Measurement Current) See: "(6) The Sample Becomes Warm"...
Page 35: Setting The Measurement Speed
3.3 Setting the Measurement Speed 3.3 Setting the Measurement Speed The measurement speed can be set to FAST, MED (MEDIUM), or SLOW. A slower measurement speed provides greater measurement precision. A faster measurement speed results in greater susceptibility to environmental noise. Ensure that measurement probes and the sample are sufficiently shielded.
Page 36 3.3 Setting the Measurement Speed Relationship Between Measurement Range and Speed (factory defaults) LOW POWER: OFF LOW POWER: ON Measurement range FAST SLOW FAST SLOW Ω 100 m Integration time can be optionally 43 ms 3.8 ms 13 ms ‑ ‑...
Page 37: Setting Measurement Start Conditions (Trigger Source)
3.4 Setting Measurement Start Conditions (Trigger Source) 3.4 Setting Measurement Start Conditions (Trigger Source) Measurements can be started in two ways. Measure with internal [INT] triggering To measure automatically Trigger signals are automatically generated internally for contin- uous measurement. Measure with external [EXT] triggering Measurements are triggered by an external signal.
Page 38: Selecting The Measurement Range
3.5 Selecting the Measurement Range 3.5 Selecting the Measurement Range The measurement range can be set as follows. When the threshold values of the comparator are set with the panel keys, the measurement range is selected automatically according to the settings (reference values or upper/lower thresholds, refer to the following table).
Page 39 3.5 Selecting the Measurement Range Manual Range Selection Open the Basic Settings screen. The Basic Settings screen appears. Select the range. Increments the range. Selection Press the up/down Decrements cursor keys to change the range. the setting. Selectable ranges depend on the low-power resistance setting (p. 28). •...
Page 40: Zero Adjustment
3.6 Zero Adjustment 3.6 Zero Adjustment When four-terminal measurement (Kelvin connection) is not practical such as when measuring very small samples, the additional inherent resistance of the two-terminal wiring should be canceled out. The zero-adjustment function can cancel out up to 10 additional resistance.
Page 41 3.6 Zero Adjustment When Zero Adjustment Fails If zero adjustment fails, the following error message appears. Before attempting zero adjustment again, confirm the following: • When measuring with the 10 Ω range, confirm that the displayed value does not exceed 10 Ω.
Page 42: Judging Measurement Values (Comparator Function)
3.7 Judging Measurement Values (Comparator Function) 3.7 Judging Measurement Values (Comparator Function) Comparator results can be output to an external device (via EXT. I/O connector) when the comparator reference/toler- Measurement value>upper limit ance or upper/lower threshold values have been set. Upper limit≥Measurement value≥...
Page 43: Enabling And Disabling The Comparator Function
3.7 Judging Measurement Values (Comparator Function) Enabling and Disabling the Comparator Function The comparator function is enabled by default. When the function is disabled, comparator settings are ignored. Open the Basic Settings screen. The Basic Settings screen appears. Enable or disable the comparator function. Disables the function.
Page 44 3.7 Judging Measurement Values (Comparator Function) Set the reference value. Pressing an inoperative key during setting sounds a low-pitch beep (when the key beeper is enabled). To Reset Numerical Values Deletes entered digits. This key is enabled only when entering Selection numerical values.
Page 45: Decide According To Upper/Lower Thresholds (Abs Mode)
3.7 Judging Measurement Values (Comparator Function) Decide According to Upper/Lower Thresholds (ABS Mode) Setting example: Upper threshold 150 mΩ, lower threshold 50 mΩ To abort the setting process, press . Settings are abandoned and the display returns to the previous screen. Open the absolute value threshold setting screen.
Page 46: Confirming Faulty Measurements
3.8 Confirming Faulty Measurements 3.8 Confirming Faulty Measurements When a measurement is not performed correctly, a measurement fault indicator appears and a measurement fault signal is output at the ERR pin of the EXT. I/O connector (except for out-of-range detection). The instrument detects measurement faults by the following four methods.
Page 47 3.8 Confirming Faulty Measurements Measurement Fault Detection Order Measurement Fault Detection Display EXT.I/O PRB_SHORT output, ERR: 021 Probe short-circuit Measurement fault detection ERR output proceeds in the order shown at the left, ending with display ERR output, CE_HI C.E. Hi Hi Wiring Contact Error output of the first detected error.
Page 48 3.8 Confirming Faulty Measurements...
Page 49: Chapter 4 Customizing Mea
4.1 Making Range-Specific Measurement Settings Customizing Measurement Chapter 4 Settings (set as needed) Change measurement settings as appropriate for your application. Refer to "Detailed Settings Screen" (p. 19) for the available settings. 4.1 Making Range-Specific Measurement Settings The setting affects only the selected range (except for the DELAY1 setting). Open the Basic Settings screen.
Page 50: Setting Pre-Measurement Delay
4.2 Setting Pre-Measurement Delay 4.2 Setting Pre-Measurement Delay This setting specifies the delay between trigger signal input and the start of measurement. Adjust this setting to delay measurement until the measurement value has time to stabilize, so that even if the sample is connected after triggering, measurement starts only after the specified delay. The delay can be set by two methods, as follows.
Page 51 4.2 Setting Pre-Measurement Delay Estimated Delay time Set the delay so that inductance does not affect measurements. To fine tune the delay, begin with a longer delay than necessary, then gradually shorten it while watching the measurement value. Open the Basic Settings screen. The Basic Settings screen appears.
Page 52: Compensating Measured Values (Scaling Function)
4.3 Compensating Measured Values (Scaling Function) Compensating Measured Values (Scaling Function) When measuring the resistance of current sensing resistors, there may be a discrepancy between the resistance value at the time of mounting on the board being used and the resistance value obtained when measuring the component alone (due to the effects of the probing location and other factors).
Page 53 4.3 Compensating Measured Values (Scaling Function) Set the compensation coefficient. Numeric keys Selection Setting range: 0.50000 to 2.00000 (default: 1.00000) Set the offset. Numeric keys Selection Setting range: ±0.0000 mΩ to ±99.9999 MΩ (default: +0.0000 mΩ) Return to the Measurement screen. The confirmation screen Returns to the setting screen.
Page 54: Setting The Measurement Integration Time Option
4.4 Setting the Measurement Integration Time Option 4.4 Setting the Measurement Integration Time Option The integration time can be optionally set for each range by selecting FAST, MED, or SLOW mea- surement speed. Integration time can be set in ms or PLC units.
Page 55 4.4 Setting the Measurement Integration Time Option Select the integration setting units. Sets in units of time. Sets in units of power line cycles. Selection The setting is specific to the selected range (p. 43). Select the integration time. Selection Setting range: •...
Page 56: Checking For Poor Or Improper Contact (Contact Check Function)
4.5 Checking for Poor or Improper Contact (Contact Check Function) 4.5 Checking for Poor or Improper Contact (Contact Check Function) This function detects poor contact between the probes and measuring object, and broken measure- ment probes. The instrument continually monitors the resistance between the H and H probes and the and L...
Page 57 4.5 Checking for Poor or Improper Contact (Contact Check Function) Return to the Measurement screen. The confirmation screen appears. Returns to the setting screen. Saves and return to previous screen. Discards setting and return to previ- ous screen.
Page 58: Improving Probe Contact (Contact Improver Function)
4.6 Improving Probe Contact (Contact Improver Function) 4.6 Improving Probe Contact (Contact Improver Function) Probe contacts can be improved by applying current from the POT to the CUR probes before mea- suring. The Contact Improver function applies voltage to the sample. Be careful when measuring samples with characteristics that may be affected.
Page 59 4.6 Improving Probe Contact (Contact Improver Function) Setting Timing chart (Contact Improver Function) Probe Stable Contact Contact Condition PULSE Approx. Start μ Internal TRIG When both applied voltage delay * limiter and low-power resis- tance measurement func- Measurement Measuring tion are disabled. Contact Improver current...
Page 60 4.6 Improving Probe Contact (Contact Improver Function) Set the Contact Improver current timing to disabled (OFF), enabled (ON), or PULSE. Disables probe contact improvement (go to step 4). Enables probe contact improvement. Contacts improvement current is ap- plied immediately before measuring on- Selection The setting is specific to the selected range (p.
Page 61: Detecting Measurement Voltage Faults (Voltage Level Monitor Function)
4.7 Detecting Measurement Voltage Faults (Voltage Level Monitor Function) 4.7 Detecting Measurement Voltage Faults (Voltage Level Monitor Function) When a measurement voltage fault occurs due to probe chattering, the C.E. Volt error message appears on the measurement screen and an signal is output.
Page 62: Applying Current Only When Measuring (Current Mode Setting)
4.8 Applying Current Only When Measuring (Current Mode Setting) 4.8 Applying Current Only When Measuring (Current Mode Setting) When the Contact Improver function is set to Pulse or disabled (CONT IMP: PULSE or OFF) and measurement current is set for pulse output, open-circuit voltage when not measuring does not exceed 20 mV.
Page 63: Test For Short-Circuited Probe (Probe Short-Circuit Detection Function)
4.9 Test for Short-Circuited Probe (Probe Short-Circuit Detection Function) 4.9 Test for Short-Circuited Probe (Probe Short-Circuit Detection Function) Four-terminal measurements are not possible when a conductive for- eign object is present between the POT and CUR probe tips. To detect electrode short-circuited probes, this function measures the resistance between the CUR and POT terminals after a specific time (initially 5 ms) follow-...
Page 64: 4.9 Test For Short-Circuited Probe
4.9 Test for Short-Circuited Probe (Probe Short-Circuit Detection Function) • Even while the probe short-circuit detection function is set to be disabled, short-circuit detection is performed when the EXT. I/O PRB_CHECK signal is asserted. • When the internal trigger [TRG: INT] source is selected, short-circuit detection is not performed after the end of mea- surement.
Page 65: Comparing The Measurement Settings Of Two Instruments (Settings Monitor Function)
Connect the SET MONITOR connectors of the two instruments using a Hioki 9637 RS- 232C cable. The SET MONITOR connectors are identical to RS-232C connectors.
Page 66 4.10 Comparing the Measurement Settings of Two Instruments (Settings Monitor Function) Select the instrument to serve as the 1st stage, and set its tolerance range. Selects this instrument as the 1st stage. Selects this instrument as the 2nd stage. Selection Example: If the 1st stage is set to measure 12 Ω...
Page 67 4.10 Comparing the Measurement Settings of Two Instruments (Settings Monitor Function) Practical Example SET MONITOR: ON 1st 0.300% (on the SET MONITOR: ON 2nd (on the System screen) 1st Stage 2nd Stage TRIG Input Accepted When changing the reference value 1st Stage 2nd Stage TRIG Input Inhibited...
Page 68: Retrying Measurement After A Fault (Retry Function)
4.11 Retrying Measurement After a Fault (Retry Function) 4.11 Retrying Measurement After a Fault (Retry Function) The Retry function enables measurement to be Chatter automatically retried when a measurement fault Probe Contact occurs due to probe chatter. Condition During Retry, all measurement operations including Con- Start tact Improvement and DELAY2 (but excluding DELAY1) Retry...
Page 69 4.11 Retrying Measurement After a Fault (Retry Function) Set a continuous retry interval. Selection Setting range: 1 to 50 ms (default: 2 ms) Return to the Measurement screen. The confirmation screen appears. Returns to the setting screen. Saves and return to previous screen. Discards setting and return to previ- ous screen.
Page 70: Limiting Measurement Voltage (Applied Voltage Limiter Function)
4.12 Limiting Measurement Voltage (Applied Voltage Limiter Function) 4.12 Limiting Measurement Voltage (Applied Voltage Limiter Function) Applied voltage used for measurements can be limited to 5 V or lower. When [ON] is selected, an adequate measurement range in which the "measured current ×...
Page 71: Maintaining Measurement Precision (Self-Calibration Function)
4.13 Maintaining Measurement Precision (Self-Calibration Function) 4.13 Maintaining Measurement Precision (Self-Calibration Function) To maintain measurement precision, the instrument self-calibrates every ten minutes to compen- sate for internal circuit offset voltage and gain drift. This function cannot be disabled. During self-calibration, the subsequent measurement is delayed for about 6 PLC + 10 ms (PLC = Power Line Cycles) for internal circuit compensation.
Page 72 4.14 Compensating for Thermal EMF Offset (Offset Voltage Compensation - OVC)
Page 73: Chapter 5 System Settings
5.1 Disabling and Enabling Key Operations Chapter 5 System Settings 5.1 Disabling and Enabling Key Operations Disabling Key Operations (Key-Lock Function) Activate the key-lock function to disable the instrument's front panel key operations. Three key-lock levels are available to suit specific purposes. Disabling All Except Comparator Settings Only comparator Key operations other than comparator settings (REF%, ABS, units and numeric...
Page 74: Re-Enabling Key Operations (Key-Lock Cancel)
5.1 Disabling and Enabling Key Operations Re-Enabling Key Operations (Key-Lock Cancel) Key-lock can be canceled only when [UNLOCK] is displayed. Press and hold F1 [UNLOCK] for one second. If key operations are disabled by the signal, de-assert (High) the signal to unlock the KEY_LOCK keys.
Page 75: Setting The Comparator Judgment And Key Beepers
5.2 Setting the Comparator Judgment and Key Beepers 5.2 Setting the Comparator Judgment and Key Beepers Enabling or Disabling the Key Beeper The key beeper sound can be enabled and disabled. The key beeper is enabled (ON) by default. Open the Basic Settings screen. The Basic Settings screen appears.
Page 76: Setting The Comparator Judgment Beeper
5.2 Setting the Comparator Judgment and Key Beepers Setting the Comparator Judgment Beeper The comparator judgment beeper can be enabled and disabled. The judgment beeper is disabled (OFF) by default. Open the Basic Settings screen. The Basic Settings screen appears. Open the System screen.
Page 77: Power Line Frequency Manual Setting
5.3 Power Line Frequency Manual Setting 5.3 Power Line Frequency Manual Setting For proper electrical noise suppression, the instrument needs to be set to match the power line fre- quency. With the default setting (AUTO), the instrument attempts to automatically detect the line frequency, but manual setting is also available.
Page 78: Setting The Clock
5.4 Setting the Clock 5.4 Setting the Clock To record and print the correct time when using statistical calculations (p. 84), the clock needs to be set correctly. The time of printing is also output when printing statistical calculation results. Open the Basic Settings screen.
Page 79: Adjusting Screen Contrast
5.5 Adjusting Screen Contrast 5.5 Adjusting Screen Contrast The screen may become hard to see when ambient temperature changes. In this case, adjust the contrast. Open the Basic Settings screen. The Basic Settings screen appears. Open the System screen. Selection The System screen appears.
Page 80: Adjusting The Backlight
5.6 Adjusting the Backlight 5.6 Adjusting the Backlight Adjust backlight brightness to suit ambient illumination. • When external triggering [TRG: EXT] is selected, backlight brightness is automatically reduced after non- operation for one minute. • Be aware that the display may be hard to see when brightness is set too low (near 0%). Open the Basic Settings screen.
Page 81: Initializing (Reset)
5.7 Initializing (Reset) 5.7 Initializing (Reset) The instrument can be reset by following three methods. • System reset from the System screen: Returns all settings (except the clock) to factory defaults. • Turn the instrument on while simultaneously holding the REF% and ABS keys: Returns all settings (except the clock) to factory defaults.
Page 82: Default Settings
5.7 Initializing (Reset) Default Settings Display Setting value Default value Settings Trigger setting function MENU INT/ EXT/ MANU (p. 31) ↑/ ↓ [When low-power resistance mea- surement is set to OFF] 100 mΩ/ 1000 mΩ/ 3 Ω/ 10 Ω/ 100 Ω/ 300 Ω/ 1000 Ω/ 10 kΩ/ 30 kΩ/ 100 kΩ/ Range switching function RANGE...
Page 83 5.7 Initializing (Reset) Display Setting value Default value Settings OFF/ ON, SYSTEM SET MONITOR Settings Monitor function (p. 59) OFF, 1st, 0.000% 1st/ 2nd, 0.000% to 9.999% Probe short-circuit detection function PROBE CHECK OFF/ ON, 0 to 100 ms OFF, 5 ms (p.
Page 84 5.7 Initializing (Reset)
Page 85: Chapter 6 Storing And Exporting Data
Storing and Chapter 6 Exporting Data Measurement values can be stored or automatically exported, according to application. Stored data can be output to a printer, RS-232C or GP-IB. Also, statistical calculations can be applied to inter- nally stored data. Stored measurement data are lost when the instrument is turned off. Therefore, be sure to print out or export important data to a PC.
Page 86: Storing Data At Specified Timing (Data Memory Function)
6.1 Storing Data at Specified Timing (Data Memory Function) 6.1 Storing Data at Specified Timing (Data Memory Function) Measurement values are stored in the instrument's internal memory at the following timings (up to 30,000 points). • All measurements performed by external (EXT) triggering •...
Page 87: Store As Soon As Measurement Is Stable (Auto-Memory Function)
6.2 Store as soon as Measurement is Stable (Auto-Memory Function) 6.2 Store as soon as Measurement is Stable (Auto-Memory Function) This function automatically stores the measurement value each time the probes contact the sample with internal triggering. When the specified number of values have been acquired, auto-storage operation stops. Statistical calculations are applied to the stored data, with results output to the screen or printer (RS-232C).
Page 88 6.2 Store as soon as Measurement is Stable (Auto-Memory Function) Open the Data Memory Settings screen. Selection The Data Settings screen appears. [DATA SETTINGS] Enable or disable the function. Auto-Memory function is not used (default). Auto-Memory function is used. Selection Return to the Measurement screen.
Page 89 6.2 Store as soon as Measurement is Stable (Auto-Memory Function) Acquiring Measurement Values Automatically Momentarily disconnect (open-circuit) the probes. Connect the probes to the measuring object. When the measurement is stable, the value is automatically stored and the count is incremented. When the count reaches the specified number of values, a long beep sounds, and subsequent mea- surements are not stored.
Page 90: Performing Statistical Calculations On Measurement Values
6.3 Performing Statistical Calculations on Measurement Values 6.3 Performing Statistical Calculations on Measurement Values Statistical calculations can be performed and results displayed for up to 30,000 measurement val- ues. Printing is also available (p. 93). Calculation types: average, maximum and minimum values, population standard deviation, sample standard deviation, and process compatibility indices = MAX (x , .., x...
Page 91: Using Statistical Calculations
6.3 Performing Statistical Calculations on Measurement Values Using Statistical Calculations When statistical calculation is set to ON and an EXT. I/O trigger signal is applied, operation will be performed as follows depending on the trigger source setting: • With external [EXT] triggering: One measurement is performed and subject to statistical calculation. •...
Page 92: Confirming, Printing, And Erasing Statistical Calculation Results
6.3 Performing Statistical Calculations on Measurement Values Confirming, Printing, and Erasing Statistical Calculation Results Statistical calculation results are displayed on the screen. Printing is available using commercially available printers having a serial interface. Statistical calcu- lation results are automatically erased after printing. Before printing, select the [PRINT] interface setting.
Page 93: Auto-Exporting Measurement Values (At End Of Measurement) (Data Output Function)
6.4 Auto-Exporting Measurement Values (at End of Measurement) (Data Output Function) 6.4 Auto-Exporting Measurement Values (at End of Measurement) (Data Output Function) At the end of measurement, the measurement value is exported to a computer via RS-232C. See: "Chapter 9 Communications (RS-232C/ GP-IB Interface)" (p. 109) •...
Page 94 6.4 Auto-Exporting Measurement Values (at End of Measurement) (Data Output Function)
Page 95: Chapter 7 Printing
7.1 Connecting the Printer Chapter 7 Printing Printing (p. 93) Make printer Connecting the printer Setting the • Measurement values and settings to the instrument Instrument (p. 91) comparator judgments • Statistical calculation results 7.1 Connecting the Printer Before connecting the printer Because electric shock and instrument damage hazards are present, always follow the steps below when connecting the printer.
Page 96: Connecting The Printer To The Instrument
7.1 Connecting the Printer Connecting the Printer to the Instrument Connection Methods Printer (Example) Confirm that the instrument and the printer are turned off. Connect the AC adapter to the printer, and insert the power plug into an outlet. Connect the RS-232C cable to the RS-232C connectors on the instrument and printer.
Page 97: Setting The Instrument
7.2 Setting the Instrument 7.2 Setting the Instrument Open the Basic Settings screen. The Basic Settings screen appears. Open the System screen. Selection The System screen appears. [SYSTEM] Select print as the interface type. Using the printer. Selection Select the printing method. Normal printing method (default) (go to step 8).
Page 98 7.2 Setting the Instrument Select the number of data sets per line. Prints one data set per line (default). Selection Prints three data sets per line. Return to the Measurement screen. The confirmation screen appears. Returns to the setting screen. Saves setting and return to previous screen.
Page 99: Printing
7.3 Printing 7.3 Printing Before Printing Verify that the instrument and printer settings (p. 91) are correct. Printing Measurement Values and Comparator Judgments Printing by key operation Press the key to print the measurement value currently displayed on the Measurement PRINT screen.
Page 100: Resistance Measurements
0.50 0.42 Example Printouts (PRINT MODE: SAMPL) Resistance measurement values Auto-memory data and statistical calculation results *********** HIOKI RM3542A *********** Date(Y-M-D): 3/1/2016 Time: 1:45:50 PM Date: 09-02-01 Time: 06:18:00 Ref: 10.00000 Ohm Upp: +10.00% Low: -10.00% Ref: 1000.000 Ohm Upp: +1.000% Low: -1.500% -91.2750/Lo-95.1600/Lo +9.9998/IN...
Page 101: Chapter 8 External Control
8.1 Ext. I/O Connectors and Signals Chapter 8 External Control The EXT. I/O connector on the rear of the instrument supports the external control by providing sig- nals for the end-of-measurements and comparator judgment signals, and by accepting the input of the measurement trigger and key-lock signals.
Page 102: Connector Type And Signal Pinouts
8.1 Ext. I/O Connectors and Signals Connector Type and Signal Pinouts Connector: (Instrument Side) • 37-pin D-sub female with #4-40 inch screws Mating Connectors: • DC-37P-ULR (solder type) • DCSP-JB37PR (pressure weld type) Japan Aviation Electronics Industry Ltd. EXT. I/O Connector (Instrument Side) Signal name Functions Logic...
Page 103: Signal Descriptions
8.1 Ext. I/O Connectors and Signals Signal Descriptions Input Signals TRIG When external triggering [EXT] is enabled, one measurement is performed at the falling (ON) (p. 106) or rising (OFF) edge of the TRIG signal. Falling (ON) or rising (OFF) edge triggering can be selected on the Settings screen.
Page 104 8.1 Ext. I/O Connectors and Signals This signal indicates the end of a measurement. At this time, the states of the comparator (p. 105) judgment outputs and ERR, CE_HI, CE_LO and PRB_SHORT are all determined. HI, IN, LO These are the comparator judgment output signals. •...
Page 105: Timing Chart
8.2 Timing Chart 8.2 Timing Chart Each signal level indicates a corresponding voltage level. Contact Improver Measurement currents Checking Contact check Measurement processing • This shows the operations when the trigger source setting is [EXT] and the EOM output setting is Pulse. •...
Page 106 8.2 Timing Chart Output Signal State at Power-On When the power is turned on, all signals are asserted ON. All output signals become OFF (de-asserted active-low) when changing from the initial screen to the Mea- surement screen. The INDEX signal and the EOM signal are asserted ON. Power-On Initial Screen Measurement Screen...
Page 107 8.2 Timing Chart Internal Delay Range Internal Delay LOW POWER: OFF LOW POWER: ON − 100 mΩ 1.4 ms 1000 mΩ 0.7 ms 0.6 ms 3 Ω 0.5 ms 0.6 ms 10 Ω 0.6 ms 0.6 ms 100 Ω 0.6 ms 0.5 ms 300 Ω...
Page 108: Internal Circuitry
8.3 Internal Circuitry 8.3 Internal Circuitry Input Circuit Pins 8 and 37 should not be connected to any external power supply. This instrument PLC, etc. (Controller) Internally Isolated 12 V Internally Isolated 5 V Output Common Internally insulated common (Isolated from the protective ground of this instrument.) Output Do not apply external power Circuit...
Page 109: Electrical Specifications
8.3 Internal Circuitry Electrical Specifications Input Signals Input type Optocoupler-isolated, non-voltage contact inputs (compatible with current sink output, active-low) (negative logic) Input ON voltage 1 V or less Input OFF voltage OPEN or 5 to 30 V Input asserted (ON) current 3 mA/ch Maximum applied voltage 30 V...
Page 110: Connection Examples
8.3 Internal Circuitry Connection Examples Input Circuit Connection Examples Input Input Switch Connections Relay Connections Common Input Output Input Output Common PLC Output (Sink Output) Connections PLC Output (Source Output) Connections Output Circuit Connection Output Output Examples LED Connection Relay Connections Output Output Output...
Page 111: Ext. I/O Settings
8.4 Ext. I/O Settings 8.4 Ext. I/O Settings These settings affect the logic of the end-of-measurement and trigger signals. Setting the End-of-Measurement Signal Output (EOM Signal Setting) Select whether the EOM (End-of-Measurement Signal) output level is retained until the next trigger input, or set for the specified pulse width.
Page 112: Setting The Trigger Signal (Trig) Logic
8.4 Ext. I/O Settings Setting the Trigger Signal (TRIG) Logic Select whether triggering occurs on the falling (ON) or rising (OFF) edge. Open the Basic Settings screen. The Basic Settings screen appears. Open the System screen. Selection The System screen appears. [SYSTEM] Select the triggering logic edge.
Page 113: Q&A Regarding External Control
8.5 Q&A Regarding External Control 8.5 Q&A Regarding External Control Common Questions Answers Short-circuit the TRIG input pin to an ISO_COM pin using a switch or How do I connect external trigger input? open-collector output. Which pins are common ground for The ISO_COM pins.
Page 114: Supplied Connector Assembly
8.6 Supplied Connector Assembly 8.6 Supplied Connector Assembly The EXT. I/O connector and cover are supplied with the instrument. Assemble as shown below. • Use shielded cables to connect a PLC to the EXT. I/O connector. Using non-shielded conductors may result in system errors from electrical noise. •...
Page 115: Chapter 9 Communications (Rs-232C/ Gp-Ib Interface)
9.1 Overview and Features of Interfaces Communications (RS-232C/ GP-IB Chapter 9 Interface) The symbols shown below indicate that the following instructions are specific to theRS-232C or GP- IB interface. Instructions without these symbols are for both the RS-232C and GP-IB interfaces. : RS-232C only : GP-IB only Before communication...
Page 116: Specifications
9.2 Specifications 9.2 Specifications Precautions for use RS-232C and GP-IB communications cannot be used simultaneously. RS-232C Specifications Transfer method Communication method: Full duplex Synchronization: Start-stop synchronization Transmission speed 9600 bps/ 19200 bps/ 38400 bps Data length 8 bit Parity none Stop bit 1 bit Message terminator...
Page 117: Connecting
9.3 Connecting 9.3 Connecting Always turn both devices OFF when connecting and disconnecting an interface con- nector. Otherwise, an electric shock accident may occur. • To avoid damage to the instrument, do not short-circuit the terminal and do not input volt- age to the terminal.
Page 118: Using The Gp-Ib Interface (Rm3542-51 Only)
Request to Send Clear to Send Clear to Send Recommended cables: Hioki Model 9637 RS-232C Cable (1.8 m) Connecting a controller with a 25-pin D-sub female port Use a crossover cable with a female 9-pin D-sub and a male 25-pin D-sub connector.
Page 119: Configuring The Communications Protocol
9.4 Configuring the Communications Protocol 9.4 Configuring the Communications Protocol Configuring RS-232C Interface Communications Protocol Configure the interface on the System screen. External command operation is undetermined when the Printer is selected as the interface type. In this case, commands should not be sent. Make these instrument settings.
Page 120: Configuring The Gp-Ib Interface Communication Protocol (Rm3542-51 Only)
9.4 Configuring the Communications Protocol Configuring the GP-IB Interface Communication Protocol (RM3542-51 only) Set the GP-IB address and message terminator on the System screen. Open the Basic Settings screen. The Basic Settings screen appears. Open the System screen. Selection The System screen appears. [SYSTEM] Select the interface type.
Page 121: Set The Measurement Value Transmission Format (Common For Rs-232C And Gp-Ib)
9.4 Configuring the Communications Protocol Set the Measurement Value Transmission format (common for RS-232C and GP-IB) Use the communications commands to set the measurement value transmission format to text or binary. See: ":SYSTem:FORMat <ASCii/ BINary>" (p. 150) This setting applies only to the data to be sent in response to the following query messages. •...
Page 122: Communication Methods
9.5 Communication Methods 9.5 Communication Methods Various messages are available for controlling the instrument through the interfaces. Messages can be either program messages sent from the controllers such as PC's, to the instru- ment, or response messages sent from the instrument to the controllers. Program message Message types are further categorized as follows Command Message...
Page 123: Message Format
9.5 Communication Methods Message Format  Program Messages Program messages can be either Command Messages or Query Messages. (1) Command Message Instructions to control the instrument, such as to change settings or reset Example: instructions to set the measurement range :RESISTANCE:RANGE 100E3 Header portion...
Page 124 9.5 Communication Methods  Headers Headers must always be added to program messages. (1) Command Program Headers There are three types of commands: Simple, Compound and Standard. • Headers for Simple Commands This header is a single word starting with an English alphabet. :ESE 0 •...
Page 125 9.5 Communication Methods Separators  (1) Message Unit Separator Multiple message can be written in one line by separating them with semicolons ";" :SYSTEM:LFREQUENCY 60;*IDN? • When messages are combined in this way and if one command contains an error, all sub- sequent messages up to the next terminator will be ignored.
Page 126: Output Queue And Input Buffer
9.5 Communication Methods  Compound Command Header Omission When several commands having a common header are combined to form a compound com- mand (e.g., :CALCulate:LIMit:REFerence :CALCulate:LIMit:PERCent if they are written together in sequence, the common portion (here, :CALCulate:LIMit: can be omitted after its initial occurrence. This common portion is called the "current path"...
Page 127 9.5 Communication Methods Status Byte Register This instrument implements the status model defined in IEEE 488.2 for the serial poll function using the service request line. The term "event" refers to any occurrence that generates a service request. Standard Event Register Description Service Request Output Queue data information SRQ occurrence...
Page 128 9.5 Communication Methods  Status Byte Register (STB) During serial polling, the contents of the 8-bit Status Byte Register are sent from the instru- ment to the controller. When any Status Byte Register bit enabled by the Service Request Enable Register has switched from 0 to 1, the MSS bit becomes 1.
Page 129: Event Registers
9.5 Communication Methods Event Registers  Standard Event Status Register (SESR) The Standard Event Status Register is an 8-bit register. If any bit in the Standard Event Status Register is set to 1 (after masking by the Standard Event Status Enable Register), bit 5 (ESB) of the Status Byte Register is set to 1. See: "Standard Event Status Register (SESR) and Standard Event Status Enable Register (SESER)"...
Page 130 9.5 Communication Methods  Standard Event Status Enable Register (SESER) Setting any bit of the Standard Event Status Enable Register to 1 enables access to the cor- responding bit of the Standard Event Status Register. Standard Event Status Register (SESR) and Standard Event Status Enable Register (SESER) bit 6 bit 5 bit 4...
Page 131 9.5 Communication Methods Event Status Register 0 (ESR0) − Bit 7 unused Bit 6 OvrRng Out-of-Range Detection Fault Bit 5 Measurement faults Bit 4 High Comparator Result Bit 3 IN Comparator Result Bit 2 Low Comparator Result Bit 1 INDEX A/D Conversion Finished Bit 0 End of Measurement...
Page 132: Initialization Items
9.5 Communication Methods  Register Reading and Writing Register Read Write Status Byte Register ∗ STB? Service Request Enable Register ∗ ∗ SRE? Standard Event Status Register ∗ ESR? Standard Event Status Enable Register ∗ ∗ ESE? Event Status Register 0 :ESR0? Event Status Enable Register 0 :ESE0?
Page 133: Command Execution Time
9.5 Communication Methods Command Execution Time Command execution time indicates the time for analyzing and processing long form com- mands. However, the command execution time for commands with data is the time described accord- ing to the data format specified in the <data portion>, and for query commands it is the time when the header is ON.
Page 134: Message List
9.6 Message List 9.6 Message List Commands specific to RS-232C or GP-IB are identified by respectively. Shared Commands Message Data Formats Description page ∗CLS Clears the event registers and the Status Byte Register. ∗ESE 0 to 255 Sets the contents of the Standard Event Status Enable Register. ∗ESE? [0 to 255] Queries the Standard Event Status Enable Register.
Page 135 9.6 Message List Data Formats Message Description [ ]: Response data. page Event registers 0 to 255 :ESE0 Sets and queries Event Status Enable Register 0. [0 to 255] :ESE0? Reads Device-Specific Event Status [0 to 255] :ESR0? Register ESR 0. 0 to 255 :ESE1 Sets and queries Event Status...
Page 136: Device-Specific Commands
9.6 Message List Device-Specific Commands Data Formats Message Description [ ]: Response data. page Delimiter (Terminator) 0/ 1 :SYSTem:TERMinator Sets and queries the GP-IB command delimiter. :SYSTem:TERMinator? [0/ 1] System <Year>,< Month>,< Day> :SYSTem:DATE Sets and queries the system date. [<Year>,<...
Page 137 9.6 Message List Data Formats Message Description [ ]: Response data. page Trigger 1/ 0/ ON/ OFF :INITiate:CONTinuous Sets and queries continuous measurement. [ON/ OFF] :INITiate:CONTinuous? Trigger Wait Setting :INITiate[:IMMediate] IMMediate/ EXTernal :TRIGger:SOURce Sets and queries the trigger source. [IMMEDIATE/ EXTERNAL] :TRIGger:SOURce? 0 to 0.100 :TRIGger:DELay1...
Page 138 9.6 Message List Data Formats Message Description [ ]: Response data. page Reading Measurement Values Reads the most recent measurement. [<Measurement value>] :FETCh? Waits for trigger and reads [<Measurement value>] :READ? the measurement value. Memory Function OFF/ MEMory/ AUTO :MEMory:MODE Sets and queries the memory mode.
Page 139 9.6 Message List Data Formats Message Description [ ]: Response data. page <Range>,<Level> :RESistance:CONTactcheck:LEVel Sets and queries contact check <Range> threshold. :RESistance:CONTactcheck:LEVel? [L1/ L2/ L3/ L4/ L5/ L6/ L7] <Range>,<1/ 0/ ON/ OFF> :RESistance:VMONitor Sets and queries voltage level monitor <Range>...
Page 140: Message Reference
9.7 Message Reference 9.7 Message Reference Messages specific to the RS-232C or GP-IB interface are denoted by Message Reference Interpretation < >: Indicates the contents (character or numeric parameters) of the data portion of a message. Character parameters are returned as all capital letters. Numeric Parameters: •...
Page 141: Shared Commands
Syntax Query ∗ IDN? Response <Manufacturer's name>, <Model name>, <0>, <Software version> Example HIOKI,RM3542A,0,V1.00 The Device ID is HIOKI RM3542A, 0, software version: 1.00. Note The response message has no header. (2) Internal Operation Command Initialize Device Syntax Command ∗...
Page 142 9.7 Message Reference (3) Synchronization Commands Set the OPC bit of SESR When Finished All Pending Operations Syntax Command ∗ Description Sets the OPC (bit 0) of the Standard Event Status Register (SESR) when the commands ∗ transmitted prior to the commands of all the commands have finished processing.
Page 143 9.7 Message Reference Read/Write the Standard Event Status Enable Register (SESER) Syntax Command ∗ <0 to 255 (NR1)> Query ∗ ESE? Response <0 to 255 (NR1)> Description Command The SESER mask is set to the numerical value 0 to 255. The initial value (at power-on) is 0.
Page 144 9.7 Message Reference Write and Read the Service Request Enable Register (SRER) Syntax Command ∗ <0 to 255 (NR1)> Query ∗ SRE? Response <0 to 255 (NR1)> Description Command The SRER mask is set to the numerical value 0 to 255. Although NRf numerical values are accepted, values to the right of the decimal are rounded to the nearest integer.
Page 145: Device-Specific Commands
9.7 Message Reference Device-Specific Commands (1) Event Status Register Set and Query Device-Specific Event Status Enable Register ESER0 Syntax Command <0 to 255 (NR1)> :ESE0 Query :ESE0? Response <0 to 255 (NR1)> Description Command Sets the mask pattern in Event Status Enable Register 0 (ESER0) for the Event Status Register.
Page 146 9.7 Message Reference (2) Measurement-Related Set and Query the resistance measurement method Syntax Command <RESistance/ LPResistance> [:SENSe:]FUNCtion Query [:SENSe:]FUNCtion? Response <RESISTANCE/ LPRESISTANCE> <RESISTANCE> = Normal Resistance measurement <LPRESISTANCE> = Low-Power Resistance measurement Example FUNC LPR Selects the Low-Power Resistance measurement. FUNC? RESISTANCE The Resistance measurement has been selected.
Page 147 9.7 Message Reference Execute and Clear Zero-Adjustment Clear Zero-Adjustment Syntax Command :ADJust:CLEar Description Command Clears any zero-adjustment. Execute Zero-Adjustment Syntax Query :ADJust? Response <0/ 1> 0 = Indicates that zero-adjustment has succeeded. 1 = Indicates that the offset resistance value exceeded 10 Ω during zero-adjustment. (3) Sampling Set and Query Measurement Speed Syntax...
Page 148 9.7 Message Reference (4) Calculation Clear and Query the Statistical Calculation • A data sample can be taken by the following methods: 1. Press the F4 [MANU] key on the [MENU]-[TRG] selection screen (p. 80). 2. Apply a TRIG signal from EXT. I/O connector. 3.
Page 149 9.7 Message Reference Query Comparator results Syntax Query :CALCulate:STATistics:LIMit? Response <Number of Hi (NR1)>,< number of IN (NR1)>,<number of Lo (NR1)>, < number of measurement faults (NR1)>,<number of Out-of-Range measurements (NR1)> Example :CALC:STAT:LIM? 1516,9310,737,16,5 Query Standard Deviation Syntax Query :CALCulate:STATistics:DEViation? σ...
Page 150 9.7 Message Reference Set and Query Judgment Mode Syntax Command <ABS/ REF> :CALCulate:LIMit:MODE Query :CALCulate:LIMit:MODE? Response <ABS/ REF> <ABS> = Upper limit value/Lower limit value comparison <REF> = Reference value/range comparison Example :CALC:LIM:MODE REF Set and Query ABS Mode Upper/Lower Comparator Threshold Values Syntax Command <Upper threshold>,<Lower threshold>...
Page 151 9.7 Message Reference Set and Query Scaling Function Syntax Command <1/ 0/ ON/ OFF> :CALCulate:SCALing Query :CALCulate:SCALing? Response <ON/ OFF> Note Enables or disables scaling function. Set and Query Coefficient Syntax Command <coefficient> :CALCulate:SCALing:PARameterA Query :CALCulate:SCALing:PARameterA? Response <coefficient> <coefficient> = 0.50000 to 2.00000 (NR2) Note Sets coefficient for the scaling function.
Page 152 9.7 Message Reference (6) System Self-Calibration State and Setting Execute Self-Calibration Syntax Command :SYSTem:CALibration Description Executes self-calibration. Note If this command is received while measuring, self-calibration executes after measurement is finished. Set and Query Self-Calibration Execution State Syntax Command <1/ 0/ ON/ OFF> :SYSTem:CALibration:AUTO Query :SYSTem:CALibration:AUTO?
Page 153 9.7 Message Reference Set and Query the Key-Lock State Syntax Command <1/ 0/ ON/ OFF> :SYSTem:KLOCk Query :SYSTem:KLOCk? Response <ON/ OFF> Description Sets the FULL key-lock state (all settings, including the comparator settings, are disabled). Example :SYST:KLOC ON :SYST:KLOC? Set and Query the Header Present Setting Syntax Command <1/ 0/ ON/ OFF>...
Page 154 9.7 Message Reference Delimiter Setting Syntax Command <0/ 1> :SYSTem:TERMinator Query :SYSTem:TERMinator? Response <0/ 1> <0> = LF+EOI <1> = CR, LF+EOI Example :SYST:TERM 1 :SYST:TERM? • Note At power-on, this is set to 0 (LF+EOI). • The RS-232C terminator is fixed as CR+ LF. Set and Query the system date Syntax Command...
Page 155 9.7 Message Reference Back up measurement settings Syntax Command :SYSTem:BACKup Description Stores current measurement settings in non-volatile memory. The measurement condition setting using communication commands are not backed up. (The settings will be lost when the main power is turned off.) Use this command to store the settings as occasion demands.
Page 156 9.7 Message Reference Set and Query Measurement-Synchronized Data Output Description ON: The measurement value is automatically sent each time an externally triggered measurement is finished. During internal triggering, the measurement values are sent automatically whenever the TRIG signal is applied. OFF: The measurement values are not automatically sent.
Page 157 9.7 Message Reference Set and Query the Applied Voltage Limit Function Enables/Disables Applied Voltage Limit Function Syntax Command <0/ 1/ ON/ OFF> :SYSTem:VOLTLimit Query :SYSTem:VOLTLimit? Response <ON/ OFF> Example :SYST:VOLTL ON System Reset Syntax Command :SYSTem:RESet Description Initializes all except communications and clock settings. After initialization, settings are stored in non-volatile memory for backup.
Page 158 9.7 Message Reference (7) Trigger Relationship Between Trigger Source and Continuous Measurement Operation Operates as follows with the continuous Measurement setting ( ) (p. 153) and trigger :INITIATE:CONTINUOUS source setting ( ) (p. 153). :TRIGGER:SOURCE See: "9.8 Data exporting methods" (p. 163) Measurement Continuous Measurement Command setting only flow...
Page 159 9.7 Message Reference Set and Query the Continuous Measurement Setting Syntax Command <1/ 0/ ON/ OFF> :INITiate:CONTinuous Query :INITiate:CONTinuous? Response <ON/ OFF> <ON> = Continuous Measurement Enabled <OFF> = Continuous Measurement Disabled • Description Continuous Measurement Enabled: After measurement, enters the Trigger Wait State. When the trigger source setting is IMMediate, the next trigger occurs immediately (the Free-Run State).
Page 160 9.7 Message Reference Set and query Trigger Delay 1 time Syntax Command <Delay1 time> :TRIGger:DELay1 Query :TRIGger:DELay1? Response <Delay1 time> <Delay1 time> = 0.000 sec to 0.100 (NR2) sec Example :TRIG:DEL1? 0.0100 Set and Query the Trigger Signal Logic Syntax Command <RISE/FALL>...
Page 161 9.7 Message Reference The timing at which the measurement values are received is different for the :FETCh? and :READ? com- mands. See: "9.8 Data exporting methods" (p. 163) Reading the Most Recent Measurement Syntax Query :FETCh? Description Reads the most recent measurement. No trigger occurs. See: "Measurement Value Format"...
Page 162 9.7 Message Reference (9) Memory Function You can save and load up to 30000 measurement data entries. Set and Query the Retry Function Memory Function Execution Mode Syntax Command <OFF/ MEMory/ AUTO> :MEMory:MODE Query :MEMory:MODE? Response <OFF/ MEMORY/ AUTO> <OFF> = Memory function OFF <MEMORY>...
Page 163 9.7 Message Reference Read Memory Data Syntax Query :MEMory:DATA? Response <Measurement value (NR3)>,< Measurement value (NR3)>,..., < Measurement value (NR3)> Description Measurement values transferred from memory are separated by commas (,). The number of stored measurement values to be exported can also be acquired with the :MEMory:COUNt? query.
Page 164 9.7 Message Reference (10) Print method setting Set and Query the Print Method Setting Syntax Command <NORMal / SAMPle> :PRINter:MODE Query :PRINter:MODE? Response <NORMAL / SAMPLE> <NORMAL> = Standard printing <SAMPLE> = Sample printing Example :PRIN:MODE SAMP :PRIN:MODE? SAMPLE Set and Query of the Number of Samples for Sample Printing Syntax Command <1 to 999>...
Page 165 9.7 Message Reference (11)Measurement Conditions Set and Query Delay 2 (Delay time after the measurement current has been applied) Syntax Command <Range> < Delay 2 time> :RESistance:DELay2 Query <Range> :RESistance:DELay2? Response <Delay 2 time> Command <Range> < Delay 2 time> :LPResistance:DELay2 Query <Range>...
Page 166 9.7 Message Reference Set and Query Integration Time (in seconds) Syntax Command <Range> <Speed> < Integration time :RESistance:APERture (seconds)> Query <Range> <Speed> :RESistance:APERture? Response <Integration time (seconds)> Command <Range> <Speed> <Integration :LPResistance:APERture Time (seconds)> Query <Range> <Speed> :LPResistance:APERture? Response <Integration time (seconds)> <Range>...
Page 167 9.7 Message Reference Set and Query Measurement Current Mode Syntax Command <Range> <PULSe/ CONTinuous> :RESistance:CURRent Query <Range> :RESistance:CURRent? Response <PULSE/ CONTINUOUS> Command <Range> <PULSe/ CONTinuous> :LPResistance:CURRent Query <Range> :LPResistance:CURRent? Response <PULSE/ CONTINUOUS> <Range> = (:RESistance ) RNG100MIL/ RNG1000MIL/ RNG3/ RNG10/ RNG100/ RNG300/ RNG1000/ RNG10K/ RNG30K/ RNG100K/ RNG300K/ RNG1000K/ RNG3MEG/ RNG10MEG/ RNG30MEG/ RNG100MEG (:LPResistance ) RNG1000MIL/ RNG3/ RNG10/ RNG100/ RNG300/...
Page 168 9.7 Message Reference Set and Query contact check threshold Syntax Command <Range> <Level> :RESistance:CONTactcheck:LEVel Query <Range> :RESistance:CONTactcheck:LEVel? Response <Level> Command :LPResistance:CONTactcheck:LEVel <Range> <Level> Query <Range> :LPResistance:CONTactcheck:LEVel? Response <Level> <Range> = (:RESistance ) RNG100MIL/ RNG1000MIL/ RNG3/ RNG10/ RNG100/ RNG300/ RNG1000/ RNG10K/ RNG30K/ RNG100K/ RNG300K/ RNG1000K/ RNG3MEG/ RNG10MEG/ RNG30MEG/ RNG100MEG (:LPResistance ) RNG1000MIL/ RNG3/ RNG10/ RNG100/ RNG300/ RNG1000...
Page 169: Data Exporting Methods
9.8 Data exporting methods 9.8 Data exporting methods Basic Data Exporting Methods Flexible data exporting is available depending on the application. Free-Run Data Exporting Default setting (continuous measurement enabled) :INITiate:CONTinuous ON (internal trigger) :TRIGger:SOURce IMMediate Exporting :FETCh? Exports the most recent measurement. Data Export by Host Trigger Default setting (continuous measurement disabled)
Page 170 9.8 Data exporting methods The :FETCh? command is used with continuous measurement and inter- nal trigger enabled Measurement Measuring Measuring Measuring Measuring Measuring Processing Measured Measurement Measurement Measurement Measurement Measurement Value Update value value value value value Command Processing Returns the last measured Response value to the PC This is the simplest method for exporting measurement values.
Page 171: Sample Programs
9.9 Sample Programs 9.9 Sample Programs The method to write these programs using Visual Basic 5.0, 6.0 or Visual Basic 2005 are explained below (p. 175). Visual Basic is a registered trademark of Microsoft Corporation. Using Visual Basic 5.0 or 6.0 These sample programs are created with Microsoft Visual Basic 5.0 and 6.0.
Page 172 9.9 Sample Programs  Measure Resistance by PC Key Measures and imports by key input on the PC, and saves measurements in a text file. Private Sub MeasureReadSubRS() Dim recvstr As String ' Receiving char string Dim i As Integer MSComm1.Settings = "9600,n,8,1"...
Page 173 9.9 Sample Programs External Trigger Measurement 1  Measure and import according to the external triggering of the instrument (F4 [MANU] key or TRIG signal input), and save the measurements in a text file. Private Sub MeasureTrigSubRS() Dim recvstr As String ' Receiving char string Dim i As Integer MSComm1.Settings = "9600,n,8,1"...
Page 174 9.9 Sample Programs  External Trigger Measurement 2 Import according to the external triggering of the instrument (F4 [MANU] key or TRIG signal input), and save the measurements in a text file. (The instrument imports the most recent measurement at the trigger input timing in the continuous measure- ment state.) Private Sub MeasureTrig2SubRS() Dim recvstr As String...
Page 175 9.9 Sample Programs Set Measurement Conditions  Sets the measurement conditions. 'Setting measurement conditions 'Setting instrument measurement conditions ' Function: Resistance Measurement 'Range: 1Ω ' Sampling: FAST ' Trigger: External trigger ' Comparator enabled, REF% mode, reference value 1Ω, tolerance +1.0% to -1.5%, beeper sounds when High or Low Private Sub SettingsSubRS() MSComm1.Settings = "9600,n,8,1"...
Page 176 9.9 Sample Programs GP-IB Communications (Using GP-IB Board of National Instruments)  Simple Resistance Measurement Imports measurement values 10 times, and saves measurements in a text file. Private Sub MeasureSub() Dim buffer As String ∗ 20 ' Receiving buffer Dim recvstr As String ' Receiving char string Dim pad As Integer ' Controller address...
Page 177 9.9 Sample Programs Measure Resistance by PC Key  Measures and imports by key input on the PC, and saves measurements in a text file. Private Sub MeasureReadSub() Dim buffer As String ∗ 20 ' Receiving buffer Dim recvstr As String ' Receiving char string Dim pad As Integer ' Controller address...
Page 178 9.9 Sample Programs  External Trigger Measurement 1 Measure and import according to the external triggering of the RM3542A (F4 [MANU] key or the TRIG signal input), and save the measurements in a text file. Private Sub MeasureTrigSub() Dim buffer As String ∗ 20 ' Receiving buffer Dim recvstr As String ' Receiving char string...
Page 179 9.9 Sample Programs External Trigger Measurement 2  Import according to the external triggering of the RM3542A (F4 [MANU] key or the TRIG signal input), and save the measurements in a text file. (The instrument imports the most recent measurement at the trigger input timing in the continuous measurement state.) Private Sub MeasureTrig2Sub() Dim buffer As String ∗...
Page 180 9.9 Sample Programs  Set Measurement State Sets up the measurement setting state. 'Setting measurement conditions 'Setting instrument measurement conditions ' Function: Resistance Measurement ' Range: 1Ω ' Sampling: FAST ' Trigger: External trigger ' Comparator enabled, REF% mode, reference value 1 Ω, tolerance +1.0% to -1.5%, beeper sounds when High or Low Private Sub SettingsSub() Dim pad As Integer ' Controller address...
Page 181 9.9 Sample Programs Create with Visual Basic 2005 This section describes an example of how to use the Windows development language, Visual Basic 2005 Express Edition to operate the instrument from a PC via RS-232C, to incorporate measure- ment values and save measurement values to a file. Visual Basic 2005 is referred to as VB2005 below.
Page 182 9.9 Sample Programs Use the method in step 2 to create another button, and edit the Text in the property win- dow of each button to appear as shown in the diagram. Right-click [Form1] in the solution explorer, and select [View Code]. Right Click Click Follow the procedure below so that the VB2005 window becomes as shown in the diagram below.
Page 183: Create With Visual Basic 2005
9.9 Sample Programs Sample Programs (Visual Basic 2005) Shown below is a sample program which can be used to enact RS-232C communication with VB2005, set the RM3542A measurement conditions, read measurement results and then save them to file. The sample program will be written in the following manner. Creation Procedure (Visual Basic 2005) description Write using sample program Button created to begin measurement...
Page 184 9.9 Sample Programs (a) This disables the "Measure" and "End" buttons such that they cannot be pressed during communication. (b) Matches the RM3542A communication conditions and the computer usage conditions. The port to be used on the computer: 1 Transmission speed: 9600 bps Parity: none Data length: 8 bit Stop bit: 1 bit...
Page 185: Device Compliance Documents
9.10 Device Compliance Documents 9.10 Device Compliance Documents "Information on compliance to standards" based on the IEEE488.2 standard Item Description 1. IEEE 488.1 interface functions See: "GP-IB Specifications (Interface Functions) (RM3542- 51 only)" (p. 110) 2. Operation with a device address other than 0 A setting outside the 0 to 30 range cannot be performed.
Page 186 9.10 Device Compliance Documents Item Description 8. The summary of the program data elements Sub-expressions are not used. Character data and decimal data are the only program data elements used. used in the <expressions> and the deepest nesting level allowable in the sub-expressions (including syntax restrictions imposed by the device) 9.
Page 187: Chapter 10 Specifications
Chapter 10 Specifications Chapter 10 Specifications Measurement Specifications LOW POWER: OFF 0.0000 mΩ (100 mΩ range) to 120.0000 MΩ (total 16 ranges) (Four-terminal resistance measurement) 0.000 mΩ (1000 mΩ range) to 1200.000 Ω (total 6 ranges) LOW POWER: ON (Low-power four-terminal resistance measurement) Measurement method...
Page 188 Chapter 10 Specifications REF% Mode Reference value range 0.00 mΩ to 120.00 MΩ (LOW POWER: OFF) 0.0 mΩ to 1200.0 Ω (LOW POWER: ON) Upper/Lower limit ranges -9.999% to +9.999% (when |Upper limit value| and |Lower limit value| are less than 10%) -99.99% to +99.99% (when |Upper limit value| or |Lower limit value| is 10% or greater) ABS Mode...
Page 189 Chapter 10 Specifications (4) Delay Setting DELAY1 Operation Adjusts the mechanical delay of trigger input and probing (setting affects all ranges) Default setting 0.0 ms Setting range 0.0 ms to 100.0 ms DELAY2 Operation Adjusts measuring object response (for each range) Default setting 0.0 ms Setting range...
Page 190 Chapter 10 Specifications (7) Faulty Measurement Detection Out-of-Range Detection Function Operation Indicates under- or over-range values in the following conditions: • Measurement value is outside of the measurement range • The relative calculation value is outside of the display range •...
Page 191 Chapter 10 Specifications (8) Probe Short-Circuit Detection Function Operation An error is detected after a certain period following the output of EOM signal output if a connection between H and H or L and L terminals lasting more than 1 ms is found. Default setting OFF, 5 ms Setting...
Page 192 Chapter 10 Specifications (13) Measurement-Start Logic Setting Function Operation Sets TRIG signal logic for EXT. I/O Default setting ON edge Setting OFF edge/ ON edge (14) EOM Pulse Width Setting Function Default setting PULSE Pulse width 5 ms Setting Mode: HOLD/ PULSE Pulse width: 1 ms to 100 ms (15) Data Output Function Operation...
Page 193 Chapter 10 Specifications (21) Reset Functions Reset Operation Resets settings (except the clock) to factory defaults ∗RST (Remote command) Operation Resets settings (except the clock and interface) to factory defaults When power is restored, reverts to the settings before ∗RST was sent (22) Self-Calibration Function Operation Compensates for offset voltage and gain of measurement circuit...
Page 194 Chapter 10 Specifications (26) Settings Monitor Function Operation Measurement settings of two instruments are compared, and if different, an alarm sounds and TRIG signal input is blocked. However, the comparator thresholds of the 1st instrument can be smaller than those of the 2nd.
Page 195 Chapter 10 Specifications (33) Remote Function Operation During REMOTE operation by RS-232C or GP-IB, all front panel operations are dis- abled. Cancellation methods F1 [LOCAL] key By RS-232C :SYSTem:LOCal command By GP-IB GTL command Reset At power-on...
Page 196 Chapter 10 Specifications Interface Specification (1) Display LCD type Monochrome graphical LCD, 240 x 64 Backlight White LED Brightness adjustment range 0 to 100% When using EXT trigger source, brightness is automatically reduced when keys are not used. Brightness recovers upon front panel key operation. Contrast Adjustment range 0 to 100% (2) Keys...
Page 197 Chapter 10 Specifications Printer Printing Contents Measured data (PRINT signal input), Total data count, Mean, Minimum value (sample No.), Maximum value (sample No.), Standard deviation of sample, Population standard deviation, and Process capability indices, IN count, Hi count, Lo count, OvrRng count, No. of Measurement faults Printing method Default setting NORMAL, (100), (ALL), (3/L)
Page 198 Guaranteed accuracy peri- 1 year od from adjustment made by Hioki Temperature variation after self-calibration is within ±2°C. From 0°C to 18°C and from 28°C to 40°C, add the following value as temperature coefficient: ± 1/10th of measurement accuracy/°C. LOW POWER: OFF Measurement accuracy (% rdg.
Page 199 Chapter 10 Specifications *1. Negative values can be up to 10% of positive full scale. *2. Measurement current accuracy is ±5%. *3. 20 mV or less when not measuring, with Pulse current mode and Contact Improver set to OFF or Pulse (by 10 MΩ input- impedance voltmeter) *4.
Page 200: General Specifications
Chapter 10 Specifications General Specifications Operating environment Indoors, Pollution degree 2, up to 2000 m (6562-ft.) Storage temperature and -10°C to 50°C (14°F to 122°F), 80% RH or less (no condensation) humidity Operating temperature and 0°C to 40°C (32°F to 104°F), 80% RH or less (no condensation) humidity Dielectric strength 1.69 kV AC, 1 min (Cutoff current 10 mA)
Page 201: Chapter 11 Maintenance And Service
The instrument contains a built-in backup lithium battery. If the date and time deviate substantially when the instrument is switched on, it is the time to replace that battery. Contact your authorized Hioki distributor or reseller. If no measurement value is displayed even when the probes are shorted together, internal...
Page 202: Cleaning
11.2 Cleaning Before Returning for Repair If abnormal operation occurs, check the following items. Symptom Check Items • Nothing is shown on the Is the power cord disconnected? Check that the power cord is • screen when the power Are the connections made correctly? connected properly.
Page 203: Error Displays And Solutions
11.3 Error Displays and Solutions 11.3 Error Displays and Solutions The following messages are displayed on the screen when the instrument malfunctions or encounters an abnormal measurement state. If repair is necessary, contact your authorized Hioki distributor or reseller. Display Description Remedy +OvrRng/-OvrRng Out-of-Range (p.
Page 204 11.3 Error Displays and Solutions Display Description Remedy Hardware error Repair is required. Hardware failure (back-up data is ERR:105 (Backup data) Press F1[OK] to reset the instru- corrupted) Reset? Press F1 Key. ment. Hardware error ERR:106 Hardware error Repair is required. (Meas CPU communication) Hardware error ERR:107...
Page 205: Disposing Of The Instrument
11.4 Disposing of the Instrument 11.4 Disposing of the Instrument The instrument uses a lithium battery for back-up power to the clock. When disposing of this instrument, remove the lithium battery and dispose of battery and instrument in accordance with local regulations. Removing the Lithium Battery To avoid electric shock, turn off the power button and disconnect the power cord and measurement probes before removing the lithium battery.
Page 206 11.4 Disposing of the Instrument...
Page 207: Appendix
Appendix 1 Four-Terminal (Voltage-Drop) Method Appendix Appendix 1 Four-Terminal (Voltage-Drop) Method The Four-Terminal method is essential for measuring very small resistance values. With two-terminal measurements (Fig. 1), the resistance of the test leads is included in the measured resis- tance, resulting in measurement errors. The Four-Terminal method (Fig.
Page 208: Appendix 2 Effect Of Thermal Emf 2
Appendix 2 Effect of Thermal emf Appendix 2 Effect of Thermal emf Thermal emf is the potential difference that occurs at Metal A Thermal emf Metal B the junction of two dissimilar metals, which if suffi- ciently large, can cause erroneous measurements. Because this instrument functions by measuring RM3542A potential difference while applying a constant direct...
Page 209 Appendix 3 Unstable Measurement Values Appendix 3 Unstable Measurement Values If the measurement value is unstable, verify the following. (1) Effect of Noise from Power Supply Lines Noise from power supply lines arises from commer- Noise from Power Supply Lines cial power, and not only from power lines or outlets, Combined with the Measurement but also as radiated emissions from fluorescent lights...
Page 210 Figure 4. Ideal Four-Terminal Method H CUR , (L CUR ) (Current generation) To facilitate measurement, the tips of the Model Hioki 9140-10 4-Terminal Probe are jagged. As shown in Fig.5 (enlarged view of probe tip contact area), the measurement current flows from multiple points, and the voltages are detected at multiple points.
Page 211 Try to measure after the temperature of the measured object becomes close to that of room temperature. Use an instrument with a temperature-compen- sation function such as the Hioki RM3544, RM3545 and RM3548 to minimize temperature dependence of copper etc.
Page 212 Appendix 3 Unstable Measurement Values (6) The Sample Becomes Warm The maximum applied power to a measuring object by this instrument is determined as follows. The resistance of samples with small thermal capacity can change due to heating. In such cases, set the low- power resistance measurement to ON.
Page 213 To obtain stability in a constant-current source with a large inductance, response time is sacrificed. If you find that resistance values are scattered when measuring large transformers or motors, please consider the above or contact your local Hioki distributor for further assistance.
Page 214: Appendix 4 Rack Mounting
Appendix 4 Rack Mounting Appendix 4 Rack Mounting Rack-mounting hardware can be attached to the instrument after removing the screws on the sides. Observe the following precautions regarding the mounting screws to avoid instru- ment damage and electric shock accidents. •...
Page 215 Appendix 4 Rack Mounting M3 x 6 mm Remove the feet from the bottom of the instrument, and the screws from the sides (four near the front). M4 x 6 mm Rack Mounting Bracket (EIA) M4 x 10 mm Insert the spacers on both sides of the instrument, attach the Rack Mounting Blackets with the M4 x 10 mm screws.
Page 216 Appendix 5 Dimensional diagram Appendix 5 Dimensional diagram (Unit = mm)
Page 217 Appendix 6 Calibration Appendix 6 Calibration Calibration Conditions • Ambient temperature and humidity 23°C±5°C, 80% RH or less • Warm-up time 30 minutes • Power source From 100 V to 240 V±10%, 50 Hz/60 Hz • Measurement speed SLOW • Integration time Default setting •...
Page 218 Appendix 6 Calibration Connection Methods RM3542, RM3542A 2 m or less Calibration using Fluke 5700A at 100 MΩ RM3542, RM3542A 2 m or less Calibration using Fluke 5700A at 10 Ω to 10 MΩ Standard resistance (Four-terminal configuration) RM3542, RM3542A 2 m or less Calibration using standard resistance RM3542, RM3542A...
Page 219 Appendix 7 Adjustment Appendix 7 Adjustment The System screen includes an adjustment screen. The Adjustment screen is used by Hioki for repair and adjustment purposes. It is not for customer use.
Page 220 Appendix 8 Table of Comparison Commands ADEX AX-162D / for this instrument Appendix 8 Table of Comparison Commands ADEX AX-162D / for this instrument Description Model AX-162D (Original mode) Model RM3542A Command Query Data Command Query Data Measure- m = REF% :CALCulate:LIMit:MODE m = 0/ ment mode...
Page 221 Appendix 8 Table of Comparison Commands ADEX AX-162D / for this instrument Example 1 Measurement function: R mode Measurement ranges: 10 Ω Upper limit: 1.900 Ω Lower limit: 1.100 Ω Measurement speed: SLOW Trigger after the above settings AX-162D (Original mode) RM3542A :CALCulate:LIMit:MODE ABS RNG2...
Page 222 Appendix 9 Zero Adjustment Appendix 9 Zero Adjustment Zero adjustment is a function which adjusts the zero point by deducting the residual value obtained during 0 Ω measurement. For this reason, zero adjustment must be performed when the connection is made to 0 Ω. However, connecting a sample with no resistance is difficult and therefore is not practical.
Page 223 Appendix 9 Zero Adjustment To perform zero adjustment appropriately Table 1 shows the correct and incorrect connections. The resistances in the figure indicate lead resistances; there will be no problem if they are less than a few Ω respectively. As in (a), when H and L , and H and L...
Page 224 Appendix 9 Zero Adjustment To perform zero adjustment using a probe When you actually perform zero adjustment using a probe, you may unexpectedly create the connection shown in Table 1 (b). Therefore, when performing zero adjustment, you need to pay sufficient attention to the connection state of each terminal. 9287-10 Clip Type Lead Here, is used as an example for the explaining the connection.
Page 225 Appendix 9 Zero Adjustment To perform zero adjustment using 9454 Zero Adjustment Board When performing zero adjustment, you cannot use a metal board or similar object to replace 9454 Zero Adjustment Board. 9454 Zero Adjustment Board is not just a metal board. Its structure consists of two metal boards screwed together at one point.
Page 226 Then, you need to make the connection as shown in Table 1 (a) and perform zero adjustment. However, when a Hioki product is used, even in the AC resistance measurement, if the μ...
Page 227: Index Index 1
Index Index Index Number Continuous measurement ......31, 152 Crossover wiring ..........112 0ADJ ..............97 Current Mode Setting Function ......56 Current Monitor Fault ......... 40 Current Monitor Function ........41 ..............36 Absolute value judgment ........36 Accuracy ............192 Data exporting methods ........
Page 228 Index Index Four-Terminal ............ A 1 Measurement flow ..........152 Free-run ..........31, 107, 152 Measuring object ..........28 Frequency ............71 Measurement Probes ......... 23 When extending ..........24 FULL ..............67 Measurement range ....... 30, 32, 43, 181 Normal display (measurement screen) ....
Page 229 Index Index Printing ............89, 93 Probe short-circuit detection ......57 Probe Short-Circuit Detection ......57 Tolerance range ..........36 Process capability index Transmission speed ......... 110 bias ..............84 ............85, 138 Variation ............84 TRIG ............97, 106 Program message ..........117 Trigger Source ...........
Page 230 Index Index...
Page 231 HIOKI E.E. CORPORATION...

This manual is also suitable for:

Rm3542a series Rm3542-51

Hioki RM3542-50 Instruction Manual

Appendix 1 Four-Terminal (Voltage-Drop) Method

Appendix 2 Effect of Thermal Emf

Appendix 3 Unstable Measurement Values.a 3 Appendix 4 Rack Mounting

Appendix 5 Dimensional Diagram

Chapter 1 Overview

Appendix 6 Calibration

Appendix 7 Adjustment

Appendix 8 Table of Comparison Commands ADEX AX-162D / for this Instrument

Appendix 9 Zero Adjustment

Chapter 2 Measurement Preparations

Chapter 3 Measurement Set

Tings (Basic Measurements)

Chapter 4 Customizing Mea

Surement Settings

Chapter 5 System Settings

Chapter 6 Storing and Exporting Data

Chapter 7 Printing

Chapter 8 External Control

Chapter 9 Communications (RS-232C/ GP-IB Interface)

Chapter 10 Specifications

Chapter 11 Maintenance and Service

Appendix 1 Four-Terminal (Voltage-Drop)

Appendix

Appendix 2 Effect of Thermal Emf 2

Appendix 4 Rack Mounting

Quick Links

Related Manuals for Hioki RM3542-50

Summary of Contents for Hioki RM3542-50

This manual is also suitable for:

Table of Contents
