Valcom PagePac Plus V-5323100 Manual page 7

7. Connect two wires from the night bell analog station port on the host telephone system to Controller night
bell (N.B.) input. See Figure 12. (Analog station port needs to provide 90 VAC ring voltage)
8. Set the Zone Option switches on the Controller and Zone Expansion Units, if any.
Note: For each zone used, no matter what its function, this switch needs to be set to one of three set-
tings for proper zone operation.
The Controller has eight switches for zones 1-8. Each subsequent Zone Expansion Unit has switches for zones
9-24, 25-40, and 41-56.
TO POWER
TO Z.E.U. 0dBm 0dBu N.B. AA
AMP
CONNECTION TO HOST
TELEPHONE SYSTEM
Figure 11. Connecting Host Telephone System to Controller
Figure 12. Night Bell Connection to Controller
7
CONTROLLER
CONNECT GREEN WIRE TO SYSTEM TIP T
TO AMP TELE MODE TO TEL
SELECT SYSTEM
CONNECT RED WIRE TO SYSTEM RING R
D.L. S.A. G.L. L.S.
CONNECT BLACK WIRE TO THE DRY CONTACT CONTROL LEAD GROUND
CONNECT YELLOW WIRE TO THE DRY CONTACT CONTROL LEAD C1
1 2 3 4 5 6
BLACK
GREEN
RED
YELLOW
T O P O W E R
T O Z .E .U . 0 d B m 0 d B u N .B . A A
A M P
TO HOST TELEPHONE
SYSTEM INTERFACE
PORT
C O N T R O L L E R
T O A M P T E L E M O D E T O T E L
S E L E C T S Y S T E M
D .L . S .A .G .L . L .S .
N IG H T B E L L C O N N E C T IO N
F R O M H O S T T E L E P H O N E
S Y S T E M A N A L O G S T A T IO N
P O R T .
