Program 98 to program zone number to enable connection to door speaker.
Answering the Doorbell
The person inside the building, having heard the door chime, can simply dial the proper extension and establish
two-way communications with the door speaker.
If the input zone (door bell) has been optioned for Audio Enable, then the user's telephone access (or attendant
access, depending on the option chosen in Audio Enable) connects via the paging system to the door speaker,
for a period of 1 0 seconds. If the user doesn't pick up the phone until after the 1 0 seconds has passed, he
must dial the Door Speaker zone code to talk.
D O O R S P E A K E R
P U S H B U T T O N C O N N E C T IO N
C O N T A C T
C L O S U R E O U T P U T
C O N T A C T
C L O S U R E IN P U T
7 0 V A U D IO O U T P U T
M O M E N T A R Y C O N T A C T C L O S U R E
IN P U T F R O M D O O R
S P E A K E R P U S H B U T T O N
Z O N E E X P A N S IO N U N IT
If the doorbell input has a higher priority than T/A (i.e., is Input #1), and is activated while T/A paging is in
progress, or during a dial tone, then the user will hear the door chime tone and be automatically routed to the
door speaker for two-way communication.
Required Programming: Type of Zone, Program 6 2 (interface the door speaker- phone as an output zone),
Output Zone Type, Program 7 0 , (configure output for Audio to the door speaker-phone), Page Enable, step 22,
(enables page to the door speaker), Talkback Enable, Program 7 6 (enable talk-back for the door speaker), and
Audio Routing, Program 9 8 (route the telephone access audio to the door speaker-phone).
Door Unlock
The person inside the building can also remotely unlock the door, by entering a numeric code (Door Code) on
the telephone's keypad.
Required Programming: Type of Zone, program 6 2, (set the door lock device as an output zone), and Output
Zone Type, program 7 0 (momentary, normally-open switch).
Note: The door ajar switch, if any, should be programmed similarly to a doorbell as an input zone,
resulting in a tone.
D O O R S P E A K E R
A U D IO C O N N E C T IO N
C O N T A C T
C L O S U R E O U T P U T
C O N T A C T
C L O S U R E IN P U T
7 0 V A U D IO O U T P U T
7 0 V O L T A U D IO O U T P U T
S H E IL D E D F O R T A L K B A C K
Z O N E 1 5
F R O M T O
P R E V IO U S N E X T
C O N T R O L L E R C O N T R O L L E R
gure 21. Door Speaker and Control Interfaces
43
C O N T A C T C L O S U R E
O U T P U T S E T T IN G
C O N T A C T
C L O S U R E O U T P U T
C O N T A C T
C L O S U R E IN P U T
7 0 V A U D IO O U T P U T
D O O R
E N T R A N C E
O U T P U T
Z O N E 1 9
C O N T A C T
C L O S U R E
(M O M E N T A R Y )
