Note: These DIP switches must be set correctly in order for the Controller to recognize the additional
zones.
4. Using a small standard screwdriver, make the following adjustments:
A. Adjust the Low Frequency Cut Off control to center position. This control cuts out the low frequency
bass so that horns and small speakers are not over-driven and distorted by excessive bass energy. Cut-
off frequency is continuously adjustable from 50Hz (full CCW rotation) to 400 Hz (full CW rotation). See
Figure 9.
B. Adjust Music Input level to the center position. Clockwise rotation will increase the level. Listen and
set to a comfortable level. (Make sure the music input is not too high check for the overload light on
amp).
C. Adjust Music Ducking level to the fully counterclockwise position. This feature allows music to
continue to be heard during a page, but at a reduced level. The range is less than –40dB (full CCW) to –
6dB (full CW). If music is not
D. Adjust the Page VOX (voiceactivated) sensitivity to the fully counterclockwise position.
E. Adjust page call to increase page volume or to lower page levels if overload light is on.
70V OUT
LOW FREQ
OUTPUT
5. Set Telephone Mode switch on Controller to match host telephone system interface port type.
F R O M T O
P R E V I O U S N E X T
C O N T R O L L E R C O N T R O L L E R
O N 2 n d Z O N E E X P A N S I O N U N I T S E T D I P S W I T C H T O
F R O M T O
P R E V I O U S N E X T
C O N T R O L L E R C O N T R O L L E R
O N 3 r d Z O N E E X P A N S I O N U N I T S E T D I P S W I T C H T O
F R O M T O
P R E V I O U S N E X T
C O N T R O L L E R C O N T R O L L E R
Figure 8. Setting Zone Expansion Unit DIP Switches
connected, set to full CCW.
PAGING IN
Figure 9. Sound Level Adjustments on AmpliCenter
5
MUSIC IN
1 2 3 4
E N A B L E S
Z O N E S 9 - 2 4
O N
1 2 3 4
E N A B L E S
Z O N E S 2 5 - 4 0
O N
1 2 3 4
E N A B L E S
Z O N E S 4 1 - 5 6
O N
