Loosen and remove the two screws from the guard
(Fig. B), align the guard mounting holes with the assembly
holes and then lock the guard onto the shaft base with the
two screws, together with two spring washers (Fig. C).
WARNING: Make sure the guard is fixed
according to Fig. B & C, any reverse fixing will cause
great danger!
MOUNTING AND ADJUSTING THE LOOP HANDLE
1. Stop the motor and unplug the battery connector
from the socket., if installed.
2.
Loosen the wing nut to separate the adjustable loop
handle (Fig. D).
NOTICE:
Install the safety barrier bar assembly onto
the loop handle with the two screws when the tool is
equipped with brushcutter head.
NOTICE:
There are two kinds of locking pole, the
shorter one is for trimmer head. The longer one is for
brushcutter head. Be carefully to choose the correct
locking pole when using the tool.
3. Push the loop handle onto the shaft at the front of
threshold ring. Never place it between the threshold
ring and rear handle area.(Fig. E).
NOTICE: Adjust the loop handle between the threshold
ring and the warning label when the tool is equipped
with brushcutter head (Fig. F).
4. Insert the clamping block into the handle slot
(Fig. G).
5. Mount the locking pole, and pre-tighten them with
the wing nut. Make sure that the loop handle is
upwards and points toward the top of the rear handle
(Fig. H).
6. Adjust the loop handle between the threshold ring
and the label until find the comfortable position when
using the trimmer. .
7. Lock the lever of the locking pole (Fig. I).
WARNING: Never operate the tool without the
loop handle firmly in place.
WARNING: Only fix the loop handle between the
threshold ring and the label.
REPLACE THE TRIMMER HEAD WITH THE 3-TEETH
BLADE
Know the trimmer head as Fig. J shown. Then
disassemble the trimmer head and mount the 3-teeth
blade on the brushcutter.
1. Press the release tabs on the spool retainer and
2. Rotate the upper housing assembly to align the slot
3.
4. Remove the guard accessory by loosening the three
NOTICE:
gloves prior to any operation with the 3-teeth blade.
5. Mount the inner flange and flange cover into its place
6. Mount the blade onto the motor shaft, ensuring
7. Position the gear case against a solid surface for
OPERATION
product to make you careless. Remember that a
careless fraction of a second is sufficient to inflict
serious injury.
with hearing protection. Failure to do so could result in
objects being thrown into your eyes and other possible
serious injuries.
accessories not recommended by the manufacturer of
this product. The use of attachments or accessories
not recommended can result in serious personal injury.
unplug the battery connector from the socket before
servicing, cleaning, changing attachments or removing
material from the unit.
You may use this product for the purposes listed below:
Trimming: used for removing grass and weeds up against
walls, fences, trees and borders.
56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER — STX3800
remove the spool retainer by pulling it straight out
(Fig. K1 & K2).
in the flange with the shaft-locking hole in the gear
case and insert a stabiliser into the hole (Fig. K3).
Rotate the socket wrench clockwise to remove the
nut and upper housing assembly (Fig. K4).
screws with washer (Fig. K5).
To protect against injury, you have to wear
(Fig. L1).
that the surface of the blade is flush with the
surface of the inner flange bulge. Mount the outer
flange and the nut (Fig. L2). Pre-tighten the nut in a
COUNTERCLOCKWISE direction by hand.
support. With one hand hold the brushcutter shaft
and the other hand grasp the multi-function wrench
to tighten the nut following the directional arrow icon
marked on the outer flange (Fig. L3).
WARNING: Do not allow familiarity with this
WARNING: Always wear eye protection, along
WARNING: Do not use any attachments or
WARNING: To prevent serious personal injury,
