Entering PAdr, SubMas, DHCP, MAC
ID and D-Gate
9.4.7

Device reset (Reset) parameter

Performing reset
© SICK AG • Advanced Industrial Sensors • Subject to change without notice • 8018916
DHCP Factory setting: deactivated.
MAC ID Individual address
Table 7: "Ethern" parameter - the default values are shown
The "IPAdr", "SubMas" and "D-Gate" parameters are entered in the same
way. The entry is described here for the IP address.
1. Select the "IPAdr" parameter under "Ethern".
2. Press the pushbutton. The current value for the "most significant
byte" is displayed. The first digit on the left flashes.
3. Press the pushbutton to increase the digit. Press the
ton to decrease the digit.
4. Press the pushbutton to save the digit entered.
The next digit flashes.
5. Repeat steps 3 and 4 until the last digit is saved. The value of the next
byte is displayed.
6. Repeat steps 3 to 5 for the second, third and fourth byte (least signifi-
cant byte).
7. After you have confirmed your entry for the value of the fourth byte with
the pushbutton, the "IPAdr" parameter is displayed.
Parameter Description
Reset Perform a reset.
Options
• Yes: perform a reset.
• No
Factory setting
• No
1. Select the "Reset" parameter in the "Setting" menu.
→ See page 34, chapter 9.4.
2. Press the pushbutton.
3. Select the "Yes" option.
4. Press the pushbutton to reset the device to its initial state. Press
the pushbutton to cancel the process.
Operating instructions Pattern sensors PS30
Operating the sensor
