MULTIMIG 200
Start-up
Press key secondary parameter 46 or 51 to
open the secondary parameter menu.
Select the required secondary parameter by
turning operation knob 52.
Confirm
set
secondary
pressing operation knob 52.
Set parameter value 72 as required by
turning operation knob 52.
Fig. 24:
Secondary parameters
70 Symbol secondary parameter
71 Factory setting
72 Parameter value
Confirm parameter value 72 by pressing
operation knob 52.
Press key 46, 50 or 51 to exit menu and
return to standard display.
13.9 Tiptronic
The Tiptronic function provides 10 separate
jobs. All settings and adjustments made on the
control panel are stored in each job.
The Tiptronic function also gives the user
certain advantages, e.g. frequently recurring
welding jobs can be assigned to specific job
numbers, or different welders can save their
individual settings in „their" job.
Factory setting for Tiptronic function is de-
activated.
18
parameter
by
Activate Tiptronic
Press key menu 48.
Select menu option „Tiptronic" by turning
operation knob 52.
Confirm menu option „Tiptronic" by pressing
operation knob 52.
Set menu option „Tiptronic on/off" by turning
operation knob 52.
Confirm menu option „Tiptronic on/off" by
pressing operation 52.
Set and confirm option „on" with operation
knob 52.
Fig. 25:
activate Tiptronic
Press key 46, 50 or 51 to exit menu and
return to standard display.
Save job
Press key Tiptronic 50.
Set menu option „Job save" by turning op-
eration knob 52.
Confirm menu option „Job save" by pressing
operation knob 52.
Select
the
required
(J00 ... J09) by turning operation knob 52.
Confirm the job by pressing operation knob
52.
If the job to be saved is already existent / al-
located; a safety question before overwriting
appears.
saving
position
