2 OVERVIEW

EVALKIT provides all the necessary hardware, software, and documentation to effectively operate and
evaluate the performance and suitability of the MAMBO2-B6 unit. MAMBO2-B6 in the EVALKIT is
shipped pre-configured allowing system integrators and application developers to test the system and
see how does the MAMBO2-B6 device work. The only necessary to be added is a computer (PC client)
with internet enabled and a pre-installed web browser.
After completing the installation of the EVALKIT, using the factory pre-loaded configuration, without any
changes by the user, the MAMBO2-B6 connects itself automatically to the FALCOM application server
that provides two-way communication in real time. User-configuration can be accomplished locally via
USB and remotely via SMS or GPRS/Internet. To debug your MAMBO2-B6 locally, connect your
MAMBO2-B6 to your own PC via USB and with the help of the Workbench software you are able to send
commands to and get responses from your MAMBO2-B6 device.
For a complete description about the configuration commands set and how to develop application with
MAMBO2-B6, please download the corresponding manuals from the FALCOM web site
http://www.falcom.de/. A brief description for each document is given in chapter 1.2,
documents".

2.1 Scope of delivery

FALCOM MAMBO2-B6-EVALKIT consists of 1 box. Before you start up the MAMBO2-B6-EVALKIT,
make sure that your package includes the following items listed in table 1 below. If any item is
missing or damaged, please, contact your vendor immediately.
The list of the items included in the MAMBO2-B6-EVALKIT:
Article name
MAMBO2-B6
Leather belt pouch
Travel Power Plug Set
AC/DC
Charger
UK adaptor
US adaptor
USB Car Charger
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Quantity Description
Shipped with factory pre-loaded configuration and pre-installed
pre-paid SIM card
1 month
purposes. It is powered by a rechargeable 1300 mAh Li-Polymer
battery.
With its large magnetic flap and sturdy leather clip, is the perfect
to carry your MAMBO2-B6. The case is designed to perfectly fit the
1 outline of MAMBO2-B6, and features horizontal loading for easy
access with dual magnetic closure to keep your MAMBO2-B6
secure.
AC/DC Removable Adapter allows access to any European socket-
outlet and to any USB port on your computer.
(Input: AC 90V-240V 50/60 Hz; Output: +5 V DC +5%; MAX. = 750
mA)
AC/DC wall charger for accessing EU socket outlet – model
Wall
1 UMN711218. You can charge your MAMBO2-B6 at home, office,
etc.
1 UK adaptor for AC/DC wall plug – enables access to British outlets.
US adaptor for AC/DC wall plug - enables access to American
1
outlets.
1 With this USB Car charger, you can keep your MAMBO2-B6 device
fully charged while you drive. Simply plug it into the USB car
charger to charge, using your USB charging cable. Input: DC12V-
24V; Output: DC 5.0V Max: 0.4A
(not available for all countries) with 6
access to the FALCOM web server for evaluation
